Summary of Contents for ProsKit MT-7603
- Page 1 Optical Power Meter MT-7603 English English...
- Page 3 USER'S GUIDE Optical Power Meter English English...
-
Page 4: Warning And Note
WARNING WARNING You are cautioned that changes or modifications not espressly approved in this document could void yout authority to operate this equipment. To reduce the risk of fire or electric shock,do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet. -
Page 5: Table Of Contents
Contents 1. Warning and Note 2. Accessories 3. Product presentation 3.1 Description 3.2 Set batteries 3.2 Power on/off, auto power off 3.3 Backlight 3.4 Wavelength select 3.5 Wavelength calibrate 3.6 Unit select 3.7 Reference 3.8 Data Storage 3.9 Communication and data processing 3.10 Visual Fault Locator 3.10 Battery energy detect 3.10 Battery charge... -
Page 6: Accessories
Standard MT-7603 Fiber Optical Power Meter >2s PERM Save Unit Host Optical Power Meter MT-7603 English FC Fiber Adapter Manual Optional 2x AA LR6 1.5V or rechargeable battery charger/ output 5V 500mA... -
Page 7: Product Presentation
Description MT-7603 Fiber Optical Power Meter >2s PERM Save Unit 1-VFL connector 2-OPM connector 3-LCD 4-OPM wavelength shift key 5-VFL on/off key 6-Reference set/check key 7-Unit shift key 8-USB Power key Backlight key 10-Data Save/Recall key... -
Page 8: Set Batteries
Set batteries 1.Press and push down 2.Open the lid 3.Place the batteries 4.Place the batteries... -
Page 9: Power On/Off, Auto Power Off
Power on/off, auto power off PERM MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Press the Power key to turn on the device with auto power off. After 10 minutes no key pressed, it will auto power off. -
Page 10: Backlight
Backlight MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM >2s PERM Save Unit When the device power on, press the power key to turn on or turn off the backlight. -
Page 11: Wavelength Select
Wavelength select MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit When testing, you must select the right wavelength. Press the key for shifting the wavelength from: 850nm,1300nm,1310nm,1490nm,1550nm,1625nm. -
Page 12: Wavelength Calibrate
Wavelength calibrate MT-7603 Fiber Optical Power Meter >2s PERM Save Unit The device has wavelength calibration function. During the device is booting on , press Save key to enter this function. Press key to select wavelength, and press key or key to select the calibration value, which range is -3dB~+3dB. -
Page 13: Unit Select
Unit select MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Unit Press the key for shifting the unit from: Unit dBm, mW/uW/nW. mW/uW/nW: 1mW=1000uW, 1uW=1000nW dBm: (dBm)=10*log(mW) -
Page 14: Reference
Reference MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Press key to check the reference value you set last time. And if keep pressing for 2 seconds, you can store the current dBm as a new reference value. Then it automatically shift to dB. -
Page 15: Data Storage
Data Storage Save MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Save When in testing interface, user can press Save to the History interface . And press the Save key for 2 seconds to save current value... -
Page 16: Communication And Data Processing
Communication and data processing Feature 1.The data collection can save as ".xls" file. 2.Collecting real-time data automatically(0.2 seconds to 10 minutes), and save as ".xls" file. 3.Saving real-time data automatically(every 10 minutes). Basic Operation A. Read the recorded data 1. Turn on the device, and connect with PC. 2. - Page 17 Communication and data processing Collect real-time data 1 Connect the device with PC, and turn it on. 2. Click "Connect Device" button to identify the device. 3.Click "Collect RT Data" button to collect real-time data. You should set parameters before collecting, including real-time cycle and acquisition time.
-
Page 18: Visual Fault Locator
Visual Fault Locator (optional) MT-7603 PERM 1KHz GLINT Save GLINT Fiber Optical Power Meter >2s PERM Save Unit The device can build in a optional VFL module, press the VFL key to shift the conditions: on-> glint->off... -
Page 19: Battery Energy Detect
Battery energy detect MT-7603 PERM 1KHz Save GLINT Fiber Optical Power Meter >2s PERM Save Unit Remain80%---100% Remain40%---80% Remain20%---40% Remain less than20% If the energy is too low, the beep will be on and device will auto power off. -
Page 20: Battery Charge
The rechargeable batteries must be in device when you use the AC/DC adaptor for charging. And do not charge the non-rechargeable batteries, or the device will be destroyed and also lose the guarantee. MT-7603 5V_500mA Fiber Optical Power Meter >2s PERM... -
Page 21: Detailed
Detailed MT-7603 Measurement range -70~+8dBm Measurement 850nm,1300nm,1310nm,1490nm,1550nm,1625nm wavelengths Resolution 0.01dB Accuracy 0.2dB Linearity 2.0% Detector type InGaAs Optical Connector FC & 2.5mm UPP Display Resolution +8~ -60dBm: 0.01dB ; -60~ -70dBm: 0.1dB Power Display Units dBm, mW, uW, nW, Communication...
