Nu-Way MULTIPLEX MP series Installation And Maintenance Manual

Blown gas burner

Advertisement

Quick Links

Installation - Maintenance
SERIES
MULTIPLEX
blown gas burner
MP
The MP burner range of compact industrial packaged gas burners covers outputs up to 150 therms, using a
very stable "nozzle-mixing" combustion head and is suitable for use on Natural, LPG or Towns Gas (type must
be specified at time of ordering). They are suitable for firing a wide range of industrial applications.
The control system and components used in conjunction with the MULTIPLEX burner should be in accordance
with BS5885 and recommendations and codes of practice set out by BRITISH GAS where the equipment is for
use in the UK, and to the relevant authority in other countries.
The instructions given by NU-WAY assume that these conditions have been met by the plant manufacturers
and/or installers. For general data see Multiplex Data Sheet.

BURNER MOUNTING AND COMBUSTION TUNNEL RECOMMENDATIONS

The MULTIPLEX burner would normally be provided with one of three tunnel options.
The mounting
requirements external to the combustion chamber would hold for all three options. The internal requirements
will however vary and guidance for mounting is given. Nu-way will advise on any mounting problems you may
have and make recommendations on choice of tunnel materials if required.

External Mounting

All burners are provided with a mounting flange which is pre-drilled to dimensions given on the data sheet.
Combustion chamber fire hole should be required dimensions (See dimensions in Data Sheet).
Screwed studs or alternative fixings should be provided on burner flange holes centres.
Burner may be mounted to chamber in any one of the four available mounting positions provided by the
mounting flange.
When the burner is mounted to the furnace front withdrawal distance equal to the overall length of the burner
including combustion tunnel should always be allowed at the rear of the burner unit.
Gas pipework into the burner should be such as to include an elbow and union connection to ensure freedom of
removal of internal parts of the burner for service. Care should be exercised in assembly of the gas pipework to
ensure electrode extensions are not damaged. Care should be taken to ensure that it seats evenly and
squarely to the chamber. A gasket, gasket rope or furnace cement should be used to prevent leakage.
page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MULTIPLEX MP series and is the answer not in the manual?

Questions and answers

Summary of Contents for Nu-Way MULTIPLEX MP series

  • Page 1 The internal requirements will however vary and guidance for mounting is given. Nu-way will advise on any mounting problems you may have and make recommendations on choice of tunnel materials if required.
  • Page 2 Customer to provide burner combustion zone in the wall of the combustion chamber. The dimensions of this zone to be in line with the dimensions shown on the Nu-way MULTIPLEX Data Sheet. Care must be taken to ensure that the zone is cut or formed at right angles to the burner mounting flange and is concentric.
  • Page 3 GAS AND ELECTRICAL CONNECTIONS When connecting a gas supply it is desirable to install a manual shut-off valve together with a suitable pipe union at or near the burner. The burner assembly should not be used to support the incoming gas supply, suitable brackets or hangers should be used for this purpose.
  • Page 4 9. LOW FIRE (PILOT START GAS AND AIR SETTINGS) (Minimum Input Rate) Set air butterfly valve to give approximately 15mm (0.6”) wg air pressure at inlet to burner (above combustion chamber pressure/suction). Slightly ‘crack’ open gas flow control valve. Initiate start sequence, if burner fails to ignite, slightly increase gas flow at butterfly valve and reset sequence controller and initiate a new start sequence repeating as many items as necessary to give a smooth start.
  • Page 5 TO STOP (Either Manual or Automatic System) 1. Close MAIN and PILOT GAS COCK. 2. Allow burner to continue operating until flame goes out (as seen through observation port on rear of burner). 3. De-energise system control panel and BURNER FAN BLOWER MOTOR. 4.
  • Page 6 ELECTRODE GAPS Spark Electrode These are pre-bent at the factory and should be set with the internals of the burner removed (withdraw the burner by removing four or eight screws in the back plate casting), after disconnecting the gas supply at the burner union.
  • Page 7 Spark and flame failure electrodes are built up as follows:- 1. Back Insulator 2. Compression Fitting 3. Brass Connector Sleeve 4. Washer 5. Internal Insulator (Ignition) 6. Internal Insulator (Flame Probe) 7. Kanthol Ignition & Flame Probes. Note: All enquiries should quote details off burner nameplate.
  • Page 8 Enertech Limited, P O Box 1, Vines Lane Droitwich, Worcestershire, WR9 8NA Tel: +44 (0) 1905 794331 Fax: +44 (0) 1905 794017 Email: info@nu-way.co.uk Web: www.nu-way.co.uk...
