Sanyo SAP-K161GJA Technical & Service Manual page 22

Outdoor Unit SAP – C161GA
SAP – C181GA
AIR DISCHARGE
SAP – C161JA
SAP – C181JA
538
AIR INTAKE
810
SAP – C181MA
136
ø12
Wide tube service valve
ø12.7 (1/2")
Narrow tube service valve
ø6.35 (1/4")
15
5
19
SAP – C181BA
275
Unit : mm
