PASCO AirLink PS-3200 Reference Manual

Top
view
Power: Rechargeable Battery
Connection:
Hardware
Included Equipment
®
PASCO AirLink (PS-3200)
Introduction
The PASCO AirLink is a combination wireless and USB device that connects to a computer or tablet device through
Bluetooth SMART, and can also connect to a computer with a USB cable (included). The AirLink is powered with a
rechargeable battery and it has a single port that accepts any PASPORT sensor or adapter. Since each AirLink has a
unique device identification code, more than one AirLink can be connected to a computer or tablet device at the same time.
The PASCO AirLink can be used to do any experiment that involves a PASCO sensor.
If the AirLink is plugged into a USB charger, it can still be used to collect data wirelessly using Bluetooth SMART.
Initial Step: Charge the Battery
• Connect the Cable: Use the Micro USB Cable to connect the Micro
USB port on the PASCO AirLink to a USB port or USB charger (such
as the PS-3501 USB Charging Station). Charging begins
automatically. The battery status LED will shine yellow as the battery is
charging, and will shine green when the battery is charged. The battery
is partially charged at the factory. Initial charging time may be three
hours or longer depending on the power source and the condition of
800-772-8700 (US)
www.pasco.com
®
PASCO AirLink
Bluetooth status LED
Battery status LED
OR
USB Cable
Quantity Included Equipment
1 Micro USB Cable (1 meter)
PS-3200
Device ID
Micro USB Cable
Reference Guide
®
End view
ON button Micro USB
port
Quantity
1
Battery status LED
support@pasco.com
013-14636C
Micro USB
cable
+1 916 462 8384
