Optex OA-PRESENCE T Operation Manuals page 2

ADJUSTMENTS
1
Detection area according to the test conditions required by EN 16005.
500
Mounting height : 2,000(6' 6")
0
500
-1,500 -1,000 -500 0 500
500
Mounting height : 2,200(7' 2")
0
500
-1,500 -1,000 -500 0 500
: Detection area : Emitting area
NOTE The actual detection area may become smaller depending on the ambient light, the color / material of
the object or the floor as well as the entry speed of the object.
The sensor may not be activated when the entering speed of the object or a person is slower than
50mm / sec. or faster than 1,500mm / sec.
2
Area depth angle adjustment
Deep
2.0 2.0
2.2 2.2
2.4 2.4
2.6 2.6
2.8 2.8
3.0 3.0
0.5 -0.5
The detection area can be adjusted up to 5° away from the door (Deep) or 5° towards the door (Shallow).
Adjust the required detection area by turning the depth adjustment screw wth a screw driver. Check the detection area
position with Red LED of the Operation LED using a tool such as a reflecting mirror.
For the compliance with EN 16005, the required fine adjustments applying the EN 16005 test conditions are recommended.
NOTE Make sure the detection area does not overlap with the door / header,otherwise ghosting / signal saturation
may occur.
Do not place any highly reflecting objects in the detection area, otherwise signal saturation may occur.
REFERENCE
Area depth adjustment with INFRARED FINDER (Separately available)
1. Turn the depth adjustment screw to the right (Deep) to place the detection area most away from the door.
2. Set INFRARED FINDER sensitivity to "H" (High) and place it on the floor as shown below.
3. Turn the depth adjustment screw to the left (Shallow) until the emitting area is placed at the position where
INFRARED FINDER is in the low detection status (Slow Red blinking).
3
Dipswitch settings
Follow these steps to change the settings of dipswitches.
1.Change the function key from "Operation Mode" to "Setting Mode".
2.Change the dipswitches setting.
3.Change the function key back to"Operation Mode".
NOTE When the above procedures (1-3) are not followed, an error
(Red & Green blinking) occurs.
Make sure to use the sensor only in "Operation Mode".
The sensor does not operate properly in "Setting Mode".
3-1.Setting the sensitivity
Normally set to "Middle". "Low" decreases the sensitivity and "High / S-High" increases
the sensitivity. Refer to the chart below for the suitable sensitivity to each installation
environment.
2,000 (6' 6")
Low reflection Middle
Low
Middle reflection
High reflection
Low
Special attention to the setting is required when the door is used often by the elderly or children.
NOTE
Please adjust the sensitivity and presence detection timer according to your risk assessment.
3-2.Setting the presence detection timer
The presence detection timer can be selected from 4 settings. To comply with
EN 16005, set the timer "30sec." or longer.
To enable the presence detection, do not enter the detection area
NOTE
for 10 seconds after setting the timer.
3-3.Setting the area width
The left and right width can be adjusted by combining dipswitches 5,6,7 and 8.
Referring to the chart below, select dipswitches 5 and 6 for the left and
dipswitches 7 and 8 for the right area width adjustment.
2.0
2.2
2.4
1 8
2.6
2 3 4 5 6 7
2.8
3.0
2.0 1.0 0 1.0 2.0
The actual detection area may become smaller depending on the ambient light, the color / material of
NOTE
the object or the floor as well as the entry speed of the object.
The sensor may not be activated when the entering speed of an object or a person is slower than
50mm / sec. or faster than 1,500mm / sec.
3-4.Setting the frequency
When using more than two sensors close to each other, set the different frequency for each sensor
by dipswitch 9.
[mm(feet,inch)]
Mounting
surface
Test conditions required by EN 16005
Floor : Grey paper
Detection object :
1,000 1,500
EN 16005 CA reference body
Sensor setting
Area angle : 0°
Mounting
Sensitivity : "Middle"
surface
Area width : 8 Spots
Test conditions
Speed of detection object :
1,000 1,500
: Sensor
Shallow
2.0
2.2
2.4
2.6
2.8
3.0
0.5 -0.5 0.5
Detection Area
INFRARED FINDER
Detection Area
Dipswitches
Function key
ON
1 2 3 4 5 6 7 8 9 10
Low Middle
1 2
Mounting height [ mm (feet,inch) ]
2,200 (7' 2") 2,500 (8' 2") 3,000 (9' 10")
High
Middle S-High
Middle Middle
S-High
Low
Middle High
30sec. 60sec.
3
3 4
Left area width adjustment
Dipswitches
5 6 5 6 5
1
Area No spots 1
eliminated Eliminated Eliminated Eliminated
spots
Right area width adjustment
Dipswitches
7 8 7 8 7
Area No spots 8 7
spots eliminated Eliminated Eliminated Eliminated
3-5.Setting the test input
Set dipswitch 10 according to the test input from the door controller.
< Test input and Safety / Test output timing chart >
Test input
(from door controller)
Safety / Test output
(to door controller)
*The test input delay time is the time period between the test input and safety / test output.
CHECKING
50mm / sec.
Check the operation according to the chart below.
Entry
Status
Operation
LED
Output
COMPLIED STANDARDS
EN 16005:2012
-0.5
EMC Directive 2004/108/EC
EN 61496-3:2001 clause 4. 3. 5 and 5. 4. 7. 3
Notified Body: TÜV SÜD Product Service GmbH, Daimlerstraße 40 60314 Frankfurt Germany
INFORM BUILDING OWNER / OPERATOR OF THE FOLLOWING ITEMS
WARNING
1. Always keep the detection window clean. If dirty, wipe the window lightly with a damp cloth.
2. Do not wash the sensor with water.
3. Do not disassemble, rebuild or repair the sensor yourself, otherwise electric shock may occur.
4. When an operation LED blinks green, contact your installer or service engineer.
5. Always contact your installer or service engineer when changing the settings.
6. Do not paint the detection window.
1. When turning the power ON, always walk-test the detection area to ensure proper operation.
NOTE
2. Do not place any objects that move or emit light in the detection area. (e.g. Plant, illumination, etc.)
TROUBLESHOOTING
Operation
Problem
LED
None
Door does not
open when a
person enters
Unstable
the detection
Setting Mode
area.
Door opens Unstable
Operation Mode
when no one
is in the
detection area.
High S-High
(Ghosting)
1 2 1 2
1 2
For example
-Carpet
-Dark color floor
-Concrete
-Tile
-Marble
Door remains Red
open
180sec. Proper
4 3 4 3 4
Fast
Green
blinking
Slow
Green
blinking
Red &
6 5 6
Green
blinking
2 1 2 3
Proper
Door remains
closed
* Before changing these settings, set the function key to the "Setting mode". When finished, set back to the
"Operation mode".
8 7 8
8 6 7 8
Manufacturer
OPTEX Co.,LTD.
5-8-12 Ogoto Otsu 520-0101, Japan
TEL.: +81(0)77 579 8700
WEBSITE: www.optex.co.jp
North and South American Subsidiary
OPTEX Technologies Inc.
Corporate Headquarters
Setting1 Setting2
3882 Del Amo Blvd., Suite 604 Torrance, CA 90503 U.S.A.
TOLL-FREE: 800 877 6656
9 9
WEBSITE: www.optextechnologies.com
Detection Test input
High
Low
t2
Outside of
Power OFF
detection area
Motion/Presence
- Stand-by
detection active
Green
None
ON
OFF
EN 12978+A1:2009
EN ISO 13849-1:2008
(Do not use any cleaner or solvent.)
Possible cause
Power supply voltage. Set to the stated voltage.
Wrong wiring or connection failure.
Check the wires and connector.
Wrong detection area positioning. Check ADJUSTMENTS 1 , 2 & 3(*).
Sensitivity is too low. Set the sensitivity higher(*).
Short presence detection timer. Set the presence detection timer longer(*).
Dirty detection window. Wipe the detection window with a damp cloth.
(Do not use any cleaner or solvent.)
Vibration of the header. Set the sensitivity lower.
Water drops on the detection window. Use the rain-cover (Separately available).
Or install in a place keeping the waterdrops off.
The detection area overlaps
Check ADJUSTMENTS 3-4(*).
with that of another sensor.
The detection area overlaps Adjust the detection area to "Deep" (Outside).
with the door / header.
Reflecting objects in the detection area. Remove the objects.
Or reflecting light on the floor.
Sensitivity is too high. Set the sensitivity lower(*).
Remove the objects.
Objects that move or
emit light in the detection area.
(Ex.Plant, illumination, etc.)
Wet floor. Check the installation condition referring to
INSTALLATION on the reverse side.
The exhaust emission or fog pen-
etrate into the detection area.
Check ADJUSTMENTS 3-1 & 3-2(*).
Sudden change in the detection area.
If the problem still persists, hard-reset the
sensor.(Turn the power OFF and ON again.)
Wrong wiring or connection failure.
Check the wires and connector.
Wrong setting of dipswitches . Check ADJUSTMENTS 3-5(*).
Wrong setting of function key . Set to "Operation Mode".
Sensor failure. Contact your installer or service engineer.
Dirty detection window. Wipe the detection window with a damp cloth.
(Do not use any cleaner or solvent.)
Sensitivity is too low. Set the sensitivity higher(*).
Remove highly reflecting objects from the
Signal saturation.
detection area. Or lower the sensitivity.
Or change the area angle.
The detection area overlaps with Adjust the detection area to "Deep" (Outside).
the door / header.
Wrong setting of dipswitches. 1. Set the function key to "Setting Mode"
2. Change dipswitch 10 setting (ON
or OFF
3. Set the function key back to "Operation Mode".
Wrong wiring or connection failure. Check the wires and connector.
