Qui c k Reference
LP-1000N
Label Printing Scale

Setting Up the Label

These procedures explain how to correctly set up the label
in the LP-1000N. They can be used when changing
from one label style to another or simply to perform a

Selecting Label Type

The LP-1000N can print on either a die cut label stock (gapped labels) or on a continuous strip label. To accommodate
this feature you must tell the scale which type of labels you are going to use. This feature usually only needs to be done
once unless you are changing back and forth between the two types of labels.
1) Determine which type of labels you are going to use.
2) Press the number 1 key followed by the MODE key. The display will show "PLU".
3) Press
until the display shows "SEt". Press the PRT/* key and the display will show ""SEt EntEr 0".
4) Press the number 4 key then the PRT/* key. The display will show "LAbEL EntEr 1". Press the number
5 key and the display will show "LAbEL CLAbEL 0".
5) Press the "0" key if you are using "Gapped Labels" or press the "1" key if you are using continuous strip
labels. Then press the PRT/* key. The display will show "LAbEL EntEr ".
6) Press the C key twice to exit the PROGRAM Mode. Power the scale off then on again. You are now ready
to start setting up your label.

Selecting a Label Format

1) Press the number 1 key followed by the MODE key. The display will show "PLU".
2) Press
until the display shows "SEt". Press the PRT/* key and the display will show "SEt EntEr 0".
3) Press the number 4 key followed by the PRT/* key and the display will show "LAbEL EntEr 1".
4) Press the number 2 key and the display will show "LAbEL ForMAt X" (X is the current programmed format
number).
5) Select the format number from pages 69 or 73 in the Owner's Manual that matches your label size and print in
formation style. Enter this number and press the PRT/* key. The display will show "LAbEL EntEr ".
Label Set-up
fine adjustment of the print location on a label that is
already installed in the scale. Please to refer to the appro-
priate charts and figures to ensure correct label setup.
20100121
