Leveloader Gold User Guide

9.2 Erase Data

To erase the stored files on the Leveloader Gold, click on the erase icon
located in the Levelogger Software (3.2.3 or later) main window. A message
will prompt the user that all of the data will be erased. Once the data is erased,
the attached Leveloader Gold will indicate that there are 0 logs stored.

9.3 Clock Synchronization

The attached Leveloader Gold's system time is displayed in the bottom left
corner of the Levelogger Software window. To synchronize the Leveloader
Gold to the PC clock, simply click the 'Synchronize' button (Figure 9-6).
Figure 9-6 Leveloader Window
Figure 9-7 Clock Synchronization Window
Page 21
