Note:
Remember that the
Leveloader Gold
must be in the 'Data
to PC' mode when connecting to
the software.
Note:
Please note that
depending on the
computer make, the
USB connection must sometimes
be made before starting the
Levelogger Software.
Note:
Remember, the
Leveloader will not
turn on when
connected to the PC with a
USB Cable. You must turn
the Leveloader on before
connecting, or unplug from
the PC then turn on and
reconnect it.
9 Levelogger V3.2.3 (or later) Software and Leveloader Gold
Figure 9-1 shows the main screen for the Levelogger Gold Software Version 3.2.3
To begin communication between the Leveloader Gold and the PC, connect the
Leveloader using either the supplied USB or RS232 cables. Select the proper
communications port that the Leveloader is connected to using the drop down
'Com Port Selection' window. Turn the Leveloader on and select the 'Data to PC'
option from the Leveloader main menu.
from the software window click on the 'Data Control' tab and the 'Leveloader' tab.
Leveloader Gold User Guide
To access the Leveloader options
Figure 9-1 Leveloader Window
Page 17
