Note:
In 'Event Based'
sampling, the user
must define what
the percentage pressure change
must be for data logging to
occur, as well as define the
sampling rate to determine how
often the data logger checks
pressure changes.
8.4.3 Edit Sampling Rate and Sampling Type
The 'Edit Sampling Rate' screen displays the current sampling rate stored in the
Levelogger (Figure 8-6).
sampling rate:
1. Select unit (Seconds, Minutes and Hours) using UP/DN and click Edit.
2. Select duration (1 – 99) using UP/DN and click OK.
3. When {SUBMIT} is highlighted, click OK to confirm all the changes
and the new setting will be sent to the Levelogger.
To cancel the operation, click 'Cancel' to return to the Edit Levelogger menu.
These changes can be confirmed by viewing the 'Edit Levelogger Menu'.
The 'Edit Sampling Type' screen displays the current sampling type stored
in the Levelogger (Figure 8-7). Use the up/down buttons to scroll through
the sampling types: Linear, Schedule or Event Based. To accept the selection
press {Submit}.
Figure 8-6 Edit Sampling Rate Menu
Figure 8-7 Edit Sampling Type Menu
Leveloader Gold User Guide
The following procedure is used to modify the
Edit Sampling Rate:
Second(s) Second(s) 05
{SUBMIT}
Cancel
OK
Edit Sampling Type:
Linear Linear
{SUBMIT}
Cancel
OK
22:26
22:25
