Note:
The Leveloader
will not turn on
when connected to
the PC with a USB Cable.
You must turn the Leveloader
on before connecting, or
unplug from the PC then turn
on and reconnect it.

7.2 View Stored Data

'View Stored Data' displays a list of stored log files together with the serial
number for each Levelogger file (Figure 7-3). To select a specific log file use the
Up/Down Buttons to highlight the desired log file and select 'OK'. The next
screen (Figure 7-4) will show the number of readings within the log file and the
complete data set. Use Up/Down Buttons to scroll.
View Stored Data
Log ID 1, 1019733
Log ID 2, 1019755
Log ID 3, 1018566
Log ID 4, 1014857
Log ID 5, 1016321
OK
Figure 7-3 View Stored Data

7.3 Data to PC

'Data to PC' lists the number of log files stored in the Leveloader Gold
(Figure 7-5). To transfer data from the Leveloader Gold, turn the Leveloader
ON, connect the USB cable from the Leveloader Gold to the PC and open the
Levelogger Version 3.2.3 (or later) Software. Within the software, select the
'Data Control' tab and then click the Leveloader tab (Figure 9-1). Inside the
Leveloader window, click the download icon to start data transfer from the
Leveloader Gold to the PC. To return to the previous menu, press the right
Chevron Button (see Section 9 for more details).
Leveloader Gold User Guide
22:10
3/200 Readings
Time, cm, Deg C
16:32:25 60.2, 24.78
16:32:27 58.8, 24.75
16:32:29 59.3, 24.77
Menu OK
Figure 7-4 Next Screen, View Stored Data
Data to PC
3 logs in Leveloader
Ready for data transfer.
Use PC Software
Connect to PC
Figure 7-5 Data to PC Menu
22:12
View Stored Data
Return
Menu
22:15
