Note:
The features
available within the
Levelogger Menu
are based on the type of data
logger connected.
Note:
If a Mini LT or
Black LTC
Levelogger are
connected, the 'Real Time
View Only' function will be
replaced by 'Last Readings'.
This function will allow the user
to only view the last data points
recorded by the attached
Levelogger
22:20
Last Readings #65269
Free Mem 24000Readings
LEVEL 64.7cm
TEMPERA 23.90Deg C
Real Time ON Menu
Last Readings Menu (Silver LT)
22:22
Last Readings
Second (s) 01
{SUBMIT}
OK Menu
Real Time Edit Menu (Silver LT)

8 Levelogger Gold Menu

When 'Connect to Logger' is selected, the Leveloader Gold will begin to
communicate with the connected data logger.
successful the Levelogger Menu will appear (Figure 8-1). There are six options
available: 'Real Time - View Only', 'Data from Levelogger', 'Info from
Levelogger', 'Edit Levelogger', 'Load Default Settings' and 'Restart Levelogger'.
Levelogger Menu

Real Time - View Only

Data from Levelogger

Info from Levelogger
Edit Levelogger
Load Settings File
Restart Levelogger
OK
Figure 8-1 Levelogger Menu
8.1 Real Time - View Only
When 'Real Time - View Only' is selected from the Levelogger Gold Menu, the
Levelogger will take a reading immediately and display it in the LCD screen
(Figure 8-2). The display will show the data logger serial number, available memory
and the readings from the data logger's available channels (level, temperature
and/or conductivity).
To update the Levelogger readings periodically, select 'Real Time On' using the left
Chevron Button. When enabled, input a sampling rate (Figure 8-3). Select the
time increments: seconds, minutes or hours and then the rate: 1-99.
8.2 Data from Levelogger
'Data from Levelogger' downloads the stored data from the attached
Levelogger. The screen (Figure 8-4) allows scrolling with the Up/Down buttons
through the stored data, indicates battery level, time, data logger serial number
and number of readings. To save the data to the Leveloader Gold, push the left
Chevron Button. After the data has been saved in the Leveloader Gold
memory, the Leveloader Gold will return to the main menu.
Leveloader Gold User Guide
22:20
Real Time - View Only
Free Mem: 40000Readings
Return
Real Time ON
Figure 8-2 Real Time - View Only
Real Time - View Only
Second (s) 01
{SUBMIT}
OK Menu
Figure 8-3 Real Time - Edit Menu
When communication is
22:21
23.90Deg C
105.77 cm
Menu
22:22
