Foscam FI9803EP Quick Installation Manual

Quick Installation Guide
（For Windows & Mac OS）
Outdoor HD PoE IP Camera
Model: FI9803EP
Foscam Digital Technologies
V1.1
EE200506
Foscam Digital Technologies
www.foscam.us www.foscam.ca www.foscam.co.uk
www.foscamgroup.com www.foscam.com

Package Contents

IP Camera Power Adapter Resource CD
Ethernet Cable Mounting Bracket
Quick Installation Guide
（For Windows & Mac OS）
Outdoor HD PoE IP Camera
Model: FI9803EP
Foscam Digital Technologies
Quick Installation Guide Security Warning Card
2

Software Installation

1. Insert the CD into the CD drive of your computer.
2. Go to the folder "IP Camera Search Tool" and find the folder "For
Windows OS"or "For Mac OS". Copy and paste the IP camera tool file
to your computer, or drag it onto your desktop.
Shortcut icon for Windows OS Shortcut icon for Mac OS
Notes:
If your computer ( Windows OS ) supports autorun function,
you can find the corresponding file in the opened control panel.
If your computer doesn't have CD drive, you can download
the IP camera tool from our website for free.
Security Warning
Foscam cameras require good security practices to
safeguard your privacy. You can help protect your camera
by changing the default username and/or password.
You should update your camera regularly at
http://www.foscam.us/firmware.html. Make sure your
camera has the latest firmware installed for your specific
camera model.
3

Access the Camera

1. Enable the DHCP feature of your router (Enabled by default
normally), then open the IP Camera Tool program. It should
display the camera's IP address in your LAN (Local Area Network).
FI9803EP Http://192.168.1.100:88
2. Double click the camera listed here, and your default browser
will open up to the camera's login page. When logging in for the
first time, you will need to download and install the add-on. We
will use Internet Explorer as an example. For Google Chrome,
Apple Safari, or Mozilla Firefox, please refer to the User Manual.
Note：
Doesn't support 64-bit browser, such as IE9 64-Bit.
Click Install
1
Hardware Introduction
Physical Description
LENS
LAN
Infrared Lamp Array
Induction IC Power
Reset Button
3. After installing the add-on, refresh the browser and click
Login.
Default user is admin with no
password.
Main stream offers the highest
quality video while Sub stream
offers less quality, but also less
delay when viewing.
4. When you log in for the first time, it will request that you
modify the default username and/or password . Input the New
username, New password and Confirm the password, click
Modify to complete the modification. You will now use the new
username and password to log in to the camera in the future.
Input the New username, Input the New username,
New password and New password and
Confirm the password. Confirm the password.
Hardware Connection
WPS
1. Connect the camera to the LAN network (Router or Switch)
via ethernet cable.
2. Connect the power adapter to the camera.
5. After logging in, you should see live video on the interface.
Notes:
After logging in for the first time, it will go to "Setup Wizard"
automatically. Please set the basic parameters, such as the
camera name, camera time, and more.
If you forget your username or password, you can press and
hold the reset button on the cable of the camera for 5 seconds.
This resets the camera to factory defaults.
