Must not:
– Turn car after starting test
– Hold unit in hand or on body
– Move Mini Plus after pressing start
– Skid wheels
"A good stop is like stopping at a traffic light – steady."

3.6 Other Functions

 View Results? : Press ENTER and display will show the test number and the
date and time of test. Press
ENTER to view each test result. Mini Plus can store up to ninety test results. At
the end there is a "Clear Results?" option to clear all test results. The Mini Plus
will hold ninety tests and will display "Memory full" when the memory is full and
stored data has to be cleared.
 Adjust Contrast? : Press ENTER to adjust the contrast of the display and press
→
to increase the contrast and DEL to reduce contrast.
 Set acceleration units? : Press ENTER to select acceleration unit. The
acceleration units can be changed to g, percentage or m/s
 Imperial/Metric? : Press ENTER to change to Imperial or Metric units.
 View Clock? : This function is for viewing the date and time set on Mini Plus.
Press ENTER to view the clock
 Battery Life? : Press ENTER to view the battery life of the Mini Plus
 View Accel? : This function is to view the X, Y and Z-axes of the accelerometer.
Press ENTER to view these values.
 View Test Count? : This function is to view the total number of tests carried on
the Mini Plus after calibration. Press ENTER to view the test count.
 Language? : This function allows users to select a different interface language.
Press ENTER to view available languages. Note: results obtained using French
language will be based on SRV-P036 standard.

3.7 Printing on Bluetooth printer (optional accessory)

In order to print the test results on Bluetooth printer, switch on the printer and give print
command from the Mini Plus. Mini Plus will display "Finding printer" while searching for
the Bluetooth printer. Once the Bluetooth printer is found, Mini Plus will automatically
issue the printout of the test via the Bluetooth printer.
Note: When Mini Plus is not able to find a Bluetooth printer it will display "No printer
found" and "Find printer? Y/N" messages on the LCD screen. Switch OFF the Bluetooth
printer and switch it back ON and select "Find printer? Y" from Mini Plus to retry printing.
AutoStop Mini Plus User Manual v2.014
→
to select the required test number and press
2
Page 7
