- Page 1 HDMI® S P L I T T E R S 4K HDMI® Splitters Part Numbers: EVSP4K12 1x2 EVSP4K14 1x4 www.vanco1.com • 800.626.6445...
- Page 2 DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. This product is 100% inspected and tested in the United States to verify HDMI performance parameters.
-
Page 3: Package Contents
• Features status indicator for connection & input HDCP compliance • Can be cascaded with other Evolution by Vanco products to create additional output options or to create an expanded distribution system • Dimensions: 4” W x .7” H x 2.3” D PACKAGE CONTENTS •... - Page 4 • Features status indicator for connection & input HDCP compliance • Can be cascaded with other Evolution by Vanco products to create additional output options or to create an expanded distribution system • Dimensions: 6.4” W x .6” H x 2.5” D PACKAGE CONTENTS •...
-
Page 5: Specifications
SPECIFICATIONS Video Bandwidth ............600MHz/18Gbps Input Ports ..............1 × HDMI (Female type) Output Ports ............. 2 or 4 × HDMI (Female type), Output Resolution ............480i ~1080p50/60, 4K2K@24/30, 4K2K@60Hz, VESA Formats up to QSXGA 2560x2048@60H ESD Protection ............Human Body model: ±8 kV (air-gap discharge) ±4 kV (contact discharge) Power Supply ............ - Page 6 PANEL DESCRIPTIONS EVSP4K12 1. Power LED: This blue LED illuminates when the device is connected with power supply. 2. Out LED: These blue LEDs will light up to indicate which HDMI outputs are connected to an active TV/ display/monitor. 3. In LED: This blue LED illuminates when the Source connected to the device. 4.
- Page 7 PANEL DESCRIPTIONS EVSP4K14 1. Power LED: This blue LED illuminates when the device is connected with power supply. 2. Out LED: These blue LEDs will light up to indicate which HDMI outputs are connected to an active TV/ display/monitor. 3. In LED: This blue LED illuminates when the Source connected to the device. 4.
-
Page 8: Connect And Operate
CONNECTION DIAGRAM EVSP4K12 CONNECT AND OPERATE 1. Connect a HDMI/ DVI source device (e.g. Bluray Player, STB, etc.) to the HDMI INPUT socket of the 4K2K HDMI Splitter with quality HDMI cables. 2. Connect HDMI displays to the HDMI OUTPUT sockets of the 4K2K HDMI Splitter with quality HDMI cables. (Note: These products do support the use of HDMI extenders for extended cable runs) 3. - Page 9 CONNECTION DIAGRAM EVSP4K14 CONNECT AND OPERATE 1. Connect a HDMI/ DVI source device (e.g. Bluray Player, STB, etc.) to the HDMI INPUT socket of the 4K2K HDMI Splitter with quality HDMI cables. 2. Connect HDMI displays to the HDMI OUTPUT sockets of the 4K2K HDMI Splitter with quality HDMI cables. (Note: These products do support the use of HDMI extenders for extended cable runs) 3.
-
Page 10: Troubleshooting
TROUBLE-SHOOTING Problems Causes Solutions Color loss or no video signal The connecting cables may Check whether the cables are output in HDMI display not be connected correctly or connected correctly and in working it may be broken. condition. The display is not compatible Make sure the resolution of the with the present output display(s) is compatible with the... -
Page 11: Limited Warranty
If repairs are needed during the warranty period the purchaser will be required to provide a sales receipt/sales invoice or other acceptable proof of purchase to the seller of this equipment. The seller will then contact Vanco regarding warranty repair or replacement. - Page 12 ® Vanco International 506 Kingsland Drive Batavia, Illinois 60510 call: 800.626.6445 fax: 630.879.9189 visit: www.vanco1.com...
