Remote Management Card
User's Manual
Copyright © 2018 CyberPower Systems, Inc. All rights reserved.
K01-E000001-06

Advertisement

loading

Related Manuals for CyberPower RMCARD305

Summary of Contents for CyberPower RMCARD305

  • Page 1 Remote Management Card User’s Manual Copyright © 2018 CyberPower Systems, Inc. All rights reserved. K01-E000001-06...
  • Page 2 TABLE OF CONTENTS ........................... 6 ............................10 ........................ 34 ....51 ....................... 52 ........................... 58 ......................... 59 ..60 .. 62 ..................... 63 ......................63 ................... 66...
  • Page 3 CyberPower Remote Management System Introduction Overview Features                      System Requirements   ...
  • Page 4 CyberPower Remote Management System Application Unpacking     ...
  • Page 5 CyberPower Remote Management System LED Status Indicators Link LED Condition Tx/Rx LED...
  • Page 6 CyberPower Remote Management System Installation Guide Step 1. Hardware Installation Note: RMCARD205...
  • Page 7 CyberPower Remote Management System RMCARD305 Step 2. Configure the IP address for the CyberPower Remote Management Card Note:...
  • Page 8 CyberPower Remote Management System cyber cyber...
  • Page 9 CyberPower Remote Management System Note: “arp -s 192.168.10.134 00-0C-15-00-FF-99” for Windows OS; type in ”arp –s 192.168.10.134 00:0c:15:00:ff:99” “ping 192.168.10.134 -l 123”...

  • Page 10: Web Interface

    CyberPower Remote Management System Web Interface Login User Account cyber cyber device cyber Note: Web Content Note: [Summary] Item Definition...
  • Page 11 CyberPower Remote Management System Item Definition [UPS] [UPS->Status] Item Definition...
  • Page 12 CyberPower Remote Management System Item Definition [UPS->Information] Information Description Update:...
  • Page 13 CyberPower Remote Management System [UPS->Configuration] Item Definition...
  • Page 14 CyberPower Remote Management System Item Definition Note:...
  • Page 15 CyberPower Remote Management System Item Definition...
  • Page 16 CyberPower Remote Management System Item Definition [UPS->Master Switch] Item Definition Note:...
  • Page 17 CyberPower Remote Management System [UPS->Bank Control] Item Definition [UPS->Diagnostics] UPS/Diagnostics Item Definition Battery Test Start Note: Passed: Failed: CyberPower...
  • Page 18 CyberPower Remote Management System Item Definition Runtime Calibration Start Abort Note: Passed: Failed: Canceled: [UPS->Schedule]: Schedule...
  • Page 19 CyberPower Remote Management System Note: [UPS->Wake on Lan] Item Definition Note: [UPS->EnergyWise] Item Definition...
  • Page 20 CyberPower Remote Management System Item Definition ® [UPS->PowerPanel List] Item Definition [Envir] [Envir->Status] Item Definition...
  • Page 21 CyberPower Remote Management System Item Definition [Envir->Configuration] Item Definition [Logs->Event Logs] Note: [Logs->Status Records] • •...
  • Page 22 CyberPower Remote Management System • • • • • • • • [Logs->Energy Records] Item Definition [Logs->Graphing] Item Definition...
  • Page 23 CyberPower Remote Management System [Logs->Maintenance] Item Definition Note: [Logs->Syslog] Item Definition [System->General->Time] Item Definition...
  • Page 24 CyberPower Remote Management System Item Definition [System->General->Identification] Item Definition [System->General->Daylight Saving Time] Item Definition [System->Security->Authentication] Item Definition Note:...
  • Page 25 CyberPower Remote Management System [System->Security->Local Account] Information Description Note: Note: [System->Security->RADIUS Configuration] Item Definition Note:...
  • Page 26 CyberPower Remote Management System [System->Security->LDAP Configuration] Item Definition Note: [System->Security->Session Control] Item Definition [System->Network Service->TCP/IPv4] Item Definition...
  • Page 27 CyberPower Remote Management System [System->Network Service->TCP/IPv6] Item Definition [System->Network Service->SNMPv1 Service] Item Definition • • • • • •...
  • Page 28 CyberPower Remote Management System [System->Network Service->SNMPv3 Service] Item Definition • • • Note: [System->Network Service->Web Service] Item Definition ‧ ‧ ‧ ‧ ‧ ‧...
  • Page 29 CyberPower Remote Management System Item Definition ‧ ‧ Note: [System->Network Service->Console Service] Item Definition ‧ ‧ Note: [System->Network Service->FTP Service] Item Definition Note:...
  • Page 30 CyberPower Remote Management System [System->Notifications->Event Action] • • • • [System->Notifications->SMTP Server] Item Definition [System->Notifications->E-mail Recipients] [System->Notifications->Trap Receivers]...
  • Page 31 CyberPower Remote Management System [System->Notifications->SMS Service] Item Description Clickatell HTTP GET HTTP GET HTTP POST HTTP POST...
  • Page 32 CyberPower Remote Management System Item Definition [System->Notifications->SMS Recipients] [System->Reset/Reboot] Item Definition...
  • Page 33 CyberPower Remote Management System [System->About] Item Definition...

  • Page 34: Command Line Interface

    CyberPower Remote Management System Command Line Interface How to log on Note:...
  • Page 35 CyberPower Remote Management System Note: How to use the Command Line Interface    date ?).   date yyyy 2015 mm 3 dd 21 Command Response Codes...
  • Page 36 CyberPower Remote Management System Command Descriptions CyberPower > ups info show UPS information Model: OL1000XL Voltage Rating: 100V Working Frequency: 40~70 Hz Power Rating: 1000 VA Current Rating: 10 Amp Load Power: 900 Watts Battery Voltage Rating: 36 V USB Version: 0.1B...
  • Page 37 CyberPower Remote Management System CyberPower > upsctrl reboot 10/20 upscfg Option Argument Description...
  • Page 38 CyberPower Remote Management System Option Argument Description No Bypass－ Check Volt/Freq－ Check Volt Only－...
  • Page 39 CyberPower Remote Management System Option Argument Description normal－ eco10%－ eco15%－ generator－ bypass－ CyberPower > upscfg supply? CyberPower > upscfg bypasscond voltonly CyberPower > upscfg rechargedelay 120 CyberPower > upscfg mode generator...
  • Page 40 CyberPower Remote Management System upsbatt Option Argument Description CyberPower > upsbatt test CyberPower > upsbatt cal start date Option Argument Description CyberPower > date timezone +0800 CyberPower > date yyyy 2015 mm 3 dd 21 CyberPower > date time 13:45:12...
  • Page 41 CyberPower Remote Management System Option Argument Description － － CyberPower > ntp access enable CyberPower > ntp priip 192.168.26.22 CyberPower > ntp update now Option Argument Description Reboot－ notcpip－ all－...
  • Page 42 Name: RMCARD305 (205) Location: Server Room Contact: Admainistrator Model: RMCARD305 (205) Hardware Version: 1.1 Firmware Version: 1.0.3 Firmware Update Date: 03/08/2015 MAC Address: 00-0C-15-00-B9-42 CyberPower > sys reset all Option Argument Description － － － CyberPower > dst type manual...
  • Page 43 CyberPower Remote Management System CyberPower > dst show DST: Manual DST Date Time Start: 02:00, the second Sunday of Mar End: 02:00, the first Sunday of Nov login Option Argument Description － － － － ldaponly－ CyberPower > login type radiuslocal...
  • Page 44 CyberPower Remote Management System admin / device Option Argument Description CyberPower > admin pmip 192.168.26.0/24 Input admin password : cyber Pass radius Option Argument Description CyberPower > radius add Radius Server IP: 192.168.26.33 Radius Server Secret: testsecret Radius Server Port: 1812...
  • Page 45 CyberPower Remote Management System CyberPower > radius show Primary Radius Server Server IP: 192.168.26.33 Server Secret: testsecret Server Port: 1812 ldap Option Argument Description CyberPower > ldap add Input LDAP Server Type [openldap | ad]: ad Input IP address: 192.168.26.33...
  • Page 46 Primary LDAP Server Type: Windows AD LDAP Server: 192.168.26.33 LDAP SSL: Disable Port: 389 Base DN: dc=cyber,dc=com Login Attribute: cn AD Domain: cyber.com tcpip Option Argument Description － － CyberPower > tcpip dhcp disable ip 192.168.26.33 tcpip6 Option Argument Description...
  • Page 47 CyberPower Remote Management System Option Argument Description CyberPower > tcpip6 manualip 2001:cdba:0:0:0:0:3257:9652 show Access: Enable Router Control: Enable Manual: Enable Manual IPv6 Address: [2001:cdba::3257:9652] snmpv1 Option Argument Description snmpv3 Option Argument Description Option Argument Description http－ https－ disable－...
  • Page 48 CyberPower Remote Management System Example 1: CyberPower > web httpport 5000 console Option Argument Description － － － CyberPower > console sshport 5000 access ssh Option Argument Description CyberPower > ftp access enable eventlog 12/11/2015 03:32:08 Admin login from 192.168.26.33. ……………………………………..
  • Page 49 CyberPower Remote Management System Description CyberPower > eventlog clear Do you want to clear all eventlog [yes / no]: yes syslog Option Argument Description...
  • Page 50 CyberPower Remote Management System CyberPower > syslog add Syslog Server IP: 192.168.26.33 Syslog Server Port: 514 CyberPower > syslog show Syslog: Enable Facility Code: user Server1 IP: 192.168.26.33 Port: 514 menumode exit clear...
  • Page 51 CyberPower Remote Management System Reset to Factory Default Setting / Recover from a Lost Password RMCARD205 RMCARD305...
  • Page 52 CyberPower Remote Management System RMCARD Firmware Upgrade [System->About] Note: Note: Method 1: Using FTP command ftp> open To 192.168.22.126 21 ftp > bin ftp > put cpsrm2scfw_XXX.bin ftp > quit ftp > bin ftp > put cpsrm2scdata_XXX.bin ftp > quit...
  • Page 53 CyberPower Remote Management System Method 2: Using Upgrade and Configuration Utility (Bulk firmware upgrade tool) Note: Note: Note:...
  • Page 54 CyberPower Remote Management System...
  • Page 55 CyberPower Remote Management System Method 3: Using Secure Copy (SCP) command Note: pscp –scp <filename> <user>@<IP address of RMCARD>: Note: <filename> cpsrm2scfw_XXX.bin cpsrm2scdata_XXX.bin cpsrm2scfw_XXX.bin cpsrm2scdata_XXX.bin <user> pscp –scp cpsrm2scfw_xxx.bin cyber@192.168.1.100: Note: cpsrm2scfw_xxx.bin cpsrm2scdata_XXX.bin...
  • Page 56 CyberPower Remote Management System scp <filename> <user>@< IP address of RMCARD>: Note: <filename> cpsrm2scfw_XXX.bin cpsrm2scdata_XXX.bin cpsrm2scfw_XXX.bin cpsrm2scdata_XXX.bin <user> scp cpsrm2scfw_xxx.bin cyber@192.168.1.100: Note: cpsrm2scfw_xxx.bin cpsrm2scdata_XXX.bin...
  • Page 57 CyberPower Remote Management System Save and Restore Configuration Settings [System->About]...

  • Page 58: Troubleshooting

    CyberPower Remote Management System Troubleshooting Problem Solution ► ►...

  • Page 59: Conformance Approvals

    CyberPower Remote Management System Conformance Approvals FCC Warning European Union...

  • Page 60: Appendix 1: Ip Address Identification For Cyberpower Remote Management Card

    CyberPower Remote Management System Appendix 1: IP Address Identification for CyberPower Remote Management Card Overview Note: 1. Locate the subnet of the CyberPower Remote Management Card. Ethernet adapter Connection-specific DNS Suffix………: xxxx.com Description……………………...: D-Link DE220 ISA PnP LAN adapter Physical Address………………: 00-80-C8-DA-7A-C0 DHCP Enabled………………….…: Yes...
  • Page 61 CyberPower Remote Management System 2. Select an IP Address for the CyberPower Remote Management Card Pinging 192.168.20.240 with 32 bytes of data: Request timed out. Request timed out. Request timed out. Request timed out. Pinging 192.168.20.240 with 32 bytes of data: Reply from 192.168.20.240: bytes=32 time<10ms TTL=64...

  • Page 62: Appendix 2: How To Configure A Rmcard User Account In Authentication Servers

    CyberPower Remote Management System Appendix 2: How to Configure a RMCARD User Account in Authentication Servers RADIUS 3808 Cyber-Service-Type Cyber-Outlets VENDOR Cyber 3808 BEGIN-VENDOR Cyber ATTRIBUTE Cyber-Service-Type integer ATTRIBUTE Cyber-Outlet string VALUE Cyber-Service-Type Admin VALUE Cyber-Service-Type Viewer VALUE Cyber-Service-Type Outlet...

  • Page 63: Appendix 3: Ups Firmware Upgrade

    CyberPower Remote Management System Appendix 3: UPS Firmware Upgrade Method 1: Using Web Interface Method 2: Using FTP Command ftp > open To 192.168.22.126 21 ftp > bin ftp > put XXX.bin ftp > quit Note: Note: Note:...

  • Page 64: Appendix 4: Software Support

    CyberPower Remote Management System Appendix 4: Software Support ® Communicate with PowerPanel Business Edition Client Note: Note:...
  • Page 65 CyberPower Remote Management System Obtain IP Address for Linux Operating System [Power->Configuration]...

  • Page 66: Appendix 5: Rmcard Adapter Guide

    CyberPower Remote Management System Appendix 5: RMCARD Adapter Guide Remove the Adapter to convert an RMCARD305 to an RMCARD205 Add the adapter to convert an RMCARD205 to an RMCARD305 Note: Note:...
  • Page 67 CyberPower Systems, Inc. www.cyberpowersystems.com For USA and Canada: 4241 12th Ave East, Suite 400 Shakopee, MN 55379 Toll-free: (877) 297-6937 For all other regions: Please visit our website for local contact information. K01-E000001-06...
