FL TM X LED FL T P NEL: PERFORM NCE SERIES
USER M NU L
MLFP14DP4535
MLFP14DP4541
MLFP14DP4550
T
INST LL TION GUIDE FOR:
1X4:
MLFP22DP4535
MLFP22DP4541
MLFP22DP4550
hank you for purchasing this MaxLite product.
For additional information or assistance
please e-mail info@maxlite.com
or log on to www.maxlite.com
and click on the
nformation and Quotes bar.
2X2:
MLFP24DP6035
MLFP24DP6041
MLFP24DP6050
2X4:
Advertisement
Table of Contents
Related Manuals for MaxLite MLFP14DP4535
Summary of Contents for MaxLite MLFP14DP4535
- Page 1 2X2: 1X4: 2X4: MLFP22DP4535 MLFP24DP6035 MLFP14DP4535 MLFP22DP4541 MLFP24DP6041 MLFP14DP4541 MLFP22DP4550 MLFP14DP4550 MLFP24DP6050 hank you for purchasing this MaxLite product. For additional information or assistance please e-mail info@maxlite.com or log on to www.maxlite.com and click on the nformation and Quotes bar.
-
Page 2: Table Of Contents
T BLE CONTENTS DESCRIPTION..1 CAPABILITIES..1 TECHNICAL SPECIFICATIONS..2 FEATURES..3-4 MOUNTING PANELS IN CEILING..5 SET-UP..6 CONNECTING TO AC POWER SOURCE..7 SET-UP FOR ON/OFF..7 SET-UP FOR OPTIONAL IR REMOTE..8 SET-UP FOR 0-10V BALLAST DIMMER Building Controls / Daylight Harvesting.. -
Page 3: Description
DESCRIPTION & C P BILITIES DESCRIPTION Models: vailable in 1’x4’, 2’x2’, 2’x4’ Construction: high performance LED flat panel designed for installation in drop ceilings; typically used to replace standard 2’x2’ and 2’x4’ fluorescent fixtures. The profile is slim, only 4.1 inches deep including the junction box, making it ideal for low depth ceiling cavities. -
Page 4: Technical Specifications
TECHNIC L SPECIFIC TIONS 1’ x 4’ Life: 50,000 hour life based on L70 standards Self-Driven: No additional drivers required Power: Connect directly to C power supply 120V through 277V Contains No Hazardous Material: Mercury and UV Free # Of LEDs: 144 Wattage: 45W Nominal Lumens: 3500-3800 CRI: 82... -
Page 5: Features
FE TURES IR Option Knock Back Panel Out Opening Pass Thru Wire ccess Control Box Knock Outs Wire Tie Off Loops Face Frame Clip Control Box Removed Option Module Mounting Studs Red/Blue LED board Leads Violet/Yellow/Grey Option leads Power Supply Black, White, Green for connection to C power source and... - Page 6 FE TURES 0-10V Connection on Dimming Control LED Board Leads Power Unit IR Dimmer IR Eye Controller 0-10V Wire Dimming Sensor...
-
Page 7: Mounting Panels In Ceiling
MOUNTING P NELS IN CEILING Ceiling Grid Groove: 1) The MaxLite LED Flat Panels are designed to lay into a gridded ceiling. Simply start on one side and gently lay down the panel. 2) Open seismic hanger 180° to engage ceiling grid frame. -
Page 8: Set-Up
SET-UPs 1. On/Off and C Power Connection 2. IR Remote 3. 0-10 Ballast/Building Controls (Daylight Harvesting): 4. Simple Wall Dimming 5. Linking Panels: Link up to 30 panels from master using 0-10 wires 0-10 0-10 0-10 0-10 Dimmer... -
Page 9: Connecting To Ac Power Source
CONNECTING TO C SOURCE Connecting panels to C source supply: ll units must be individually connected to the C supply. (120-277 V C) Black = Line White = Neutral Green = Ground C supply connections ON/OFF operation: Line connection to be made to switched lead from source. -
Page 10: Set-Up For Optional Ir Remote
SET UP OPTION L I.R. REMOTE 1. Follow Connecting Power procedures (see page 8). 2. Position IR Sensor so it can be visible to the Remote Controller 3. Connect control wires IR Sensor from dimmer control to Power Supply driver violet, yellow, grey IR DIMMER Module Violet... - Page 11 SET UP 0-10V B LL ST DIMMER–BUILDING CONTROLS 1. Follow Connecting Power procedures (see page 8). 2. Locate the leads violet, From yellow, grey Controller 4. 0-10 connection as shown CENTR L SYSTEM CONTROLLER CENTRAL SYSTEM CONTROLLER Output 0-10 Yellow DRIVER Wire to violet/yellow/grey Violet...
-
Page 12: Set-Up For 0-10V Simple Wall Dimming
SET UP FOR W LL DIMMING (0-10V SIMPLE DIMMING) 1. Follow Connecting Power procedures (see page 8). 2. Locate the leads violet, From yellow, grey Dimmer 4. Connect wall dimmer (non-relay wires) to Dimming Controller Wires. 0-10 connection as shown WALL DIMMER with wire nuts... -
Page 13: Set-Up For Linking Panels
SET-UP FOR LINKING P NELS 1. Select one of the panels to be Master Panel. Master panel will have 0-10 connection as shown WALL DIMMER Output 0-10 Yellow DRIVER Violet Violet Input 0-10 Grey Grey 2. Connect by linking to 0-10 input. Violet and grey wires are the 0-10 input wires 4. - Page 14 Lighting Possibilities For additional information or assistance please e-mail info@maxlite.com or log on to www.maxlite.com and click on the nformation and Quotes bar.
