2. Twirl the Overlay 1 or Overlay 2 knob to adjust the scale of the corresponding overlay
channel on both axes simultaneously.
FREELY ADJUST SCALE
1. Press and hold the button labelled Scale.
2. Use the Overlay 1 or Overlay 2 joysticks to independently adjust the scale of the
corresponding overlay channel on either axis.
RESET SCALE
1. Press and hold the button labelled Scale.
2. Press (click once) the Overlay 1 or Overlay 2 knob to reset the scale of the
corresponding overlay channel.
EFFECT
Press and hold the Effect button while twisting either the Overlay 1 or Overlay 2 knob to cycle
through the list of Overlay Effects currently available in the dropdown menu for the respective
channel.
3.5.4 FADE & TAKE (OVERLAY)
These last two buttons correspond to the onscreen Effect (name) and Take buttons for the two
Overlay channels (when the button is pressed while ALT is held down, the action is applied to
Overlay 2; otherwise, Overlay 1 is affected).
As you would expect, pressing Take toggles the current overlay on or off as using a Cut, while the
FADE button uses the currently assigned Effect to display or hide the overlay.
