PosiTector DPM Kit Contents
- Humidity, air and surface temperature sensors
- Protective rubber holster with belt clip
- Protective Cap for Surface Temperature Sensor
- Protective Lens Shield
- Wrist Strap
- 3 Alkaline AAA batteries
- Quick Guide Instructions
- Nylon carrying case with shoulder strap
- USB Cable
- Certificate of Calibration traceable to NIST
- Two (2) year warranty on Body and Probe
The PosiTector DPM powers-up when the center navigation
button is pressed. Readings are updated automatically each
second. To preserve battery life, the Gage powers down after
approximately 5 minutes of no activity. All settings are retained.
1. Remove the protective rubber cap from the surface
temperature sensor.
2. Power-up Gage by pressing the center navigation

Introduction

Introduction

Quick Start

Quick Start
1
button.
