Inhaltsverzeichnis Lieferumfang Seite Begrüßung Seite Allgemeine Tipps Seite Auspacken und Zusammenbau Seite Anschließen der Lautsprecher Seite Aufstellen der Lautsprecher Seite Abschluss des Setups Seite Technische Spezifikationen Seite Contents page 10 Lieferumfang Ihre neuen Lautsprecher werden in zwei getrennten Kartons geliefert. Ein Karton enthält neben einem Laut- sprecher die Zubehörpackung „1“...
Ihr Vertrauen in unsere Produkte und heißen Sie im Kreise der audiophilen Freunde von AUDIO PHYSIC herzlich willkommen. Sie haben sich für ein erstklassiges Produkt aus deutscher Entwicklung und Fertigung entschieden, dazu beglückwünschen wir Sie und wünschen Ihnen viel Freude damit.
Sie bequem die Fußkonstruktion befestigen können. Zusammenbau Die CARDEAS 30 Limited Jubilee Edition besitzen eine ausgeklügelte Fußkonstruktion, die Ihnen die Aufstellung erleichtert und dabei Schäden an Boden oder Teppich ausschließt. Zum Lieferumfang zählen solide Kugelfüße aus Kunststoff, mit denen sich die Lautsprecher bequem verschieben lassen.
Bewegen Sie die Lautsprecher, möglichst ebenfalls zu zweit, an die Position in Ihrem Raum, an dem Sie die CARDEAS 30 LJE betreiben möchten. Vor der Feinabstimmung der Ausrichtung verbinden Sie die Lautsprecher mit Ihrem HiFi-System. Anschließen der Lautsprecher Bitte schalten Sie alle Geräte Ihrer HiFi-Anlage aus, bevor Sie die Lautsprecher anschließen.
Aufstellen der Lautsprecher Ideal ist es, wenn Sie ihre neuen Lautsprecher im Raum so positionieren, dass sie mit Ihrem Hörplatz ein gedachtes gleichschenkliges Dreieck bilden. Der Abstand zwischen den Boxen sollte etwa das 0,8- bis 1,2-fache des Abstandes zum Hörplatz betragen. Je näher Sie vor den Lautsprechern sitzen, umso direkter und trockener wird das Klangerleben.
Stimme. Mit den besonders ausführlichen Tipps auf unserer Webseite können Sie Ihre neuen CARDEAS 30 Limited Jubilee Edition perfekt auf den Hörplatz feinjustieren. Die Tipps finden Sie auf www.audiophysic.de im Bereich „Technik“ unter dem Punkt „Aufstellung“.
VCF V Magnetic Füßen (links) ausgestattet. Sie entkoppeln die Lautsprecher besonders effektiv vom Untergrund. Die im Zubehör enthaltene Dosenlibelle erleichtert die exakte Aufstel- lung der CARDEAS 30 LJE. Wir wünschen Ihnen nun viel Freude mit Ihren CARDEAS 30 Limited Jubilee Edition.
Technische Spezifikationen CARDEAS 30 Limited Jubilee Edition Höhe 119 cm Tiefe 30,5 cm Breite 59,5 cm Standfläche 41 x 59,5 cm Gewicht 74 kg Empf. Verstärkerleistung 40 - 350 W Impedanz 4 Ohm Frequenzgang 25 Hz - 40 kHz Wirkungsgrad...
Your new loudspeakers are delivered in two separate boxes. Box “A“ contains one loudspeaker and two accessory packs, as well as your “Welcome to the Audio Physic Family“ package containing this Owner‘s Manual and the Final Inspection Certificate. In box “B“ you will find the other loudspeaker and two further accessory packs.
General Tips Depending on the size and weight of your loudspeakers, it is a good idea for two people to unpack them. The ideal way to do so is to stand the boxes upright so that the top of the loudspeaker is resting on the floor (the boxes are marked accordingly) and you can easily attach the foot construction.
Unpacking Place the boxes on the floor, making sure that the product labels are facing up. Carefully open the packaging on the long side where it has been taped up, as shown in the illustrations below (illustration similar), preferably using a pocket knife or kitchen knife. Accessory Pack 1 Welcome-Package Accessory Pack 2...
Preferably working together with another person, move the loudspeaker to the position in your room where you wish to operate the CARDEAS 30 LJE. Prior to fine-tuning their position, connect the loudspeakers to your hi-fi system. Connecting the Loudspeakers Please switch off all equipment in your Hifi system before you begin to connect your loudspeakers.
Setting Up the Loudspeakers The ideal placement of your loudspeakers in your room involves positioning them in an isosceles triangle arrangement including your listening seat, creating equal spacing between each loudspeaker and the listening position. The distance between the loudspeakers should be around 0.8 - 1.2 times as much as the distance between the loudspeakers and the listening position.
Page 15
Alongside the strength of the bass response, the distance from the side walls also particularly affects the localisation of sound events and therefore the precision of the spatial imaging. As the distance from the walls increases, the localisation will become more precise and the sound will be more balanced.
VCF V Magnetic in such a way that the air bubble in the interior of the circle comes to a rest. Secure the VCF V Magnetic again with the upper caps. As a standard feature, CARDEAS 30 LJE loudspeakers are equipped with the technologically pioneering VCF V Magnetic feet (left).
Page 17
Technical Specifications CARDEAS 30 Limited Jubilee Edition Height 46.9“ Width 12“ Depth 23.4“ Required Space: Width x Depth 16.1“ x 23.4“ Weight 74 kg Recomm. amplifier power 40 - 350 watts Impedance 4 Ohm Frequency range 25 Hz - 40 kHz...
