Connections

Using the OPTiCaL Connection

Use an optical cable (not included) to connect the TV's OPTiCaL OUT socket to the
soundbar's D1 OPTiCaL socket.
GB

Using the aUX Connection

Use a 3.5mm to RCA stereo audio cable (included) to connect the TV's audio output sockets
to the soundbar's aUX in socket.
Use a 3.5mm to 3.5mm stereo audio cable (included) to connect the TV's headphone socket
to the soundbar's aUX in socket.
12
Bottom view of the unit
OPTICAL cable
(not included)
Bottom view of the unit
3.5mm to RCA stereo audio cable
(included)
Bottom view of the unit
3.5mm to 3.5mm stereo audio cable
(included)
TV
TV
TV
