INSTRUCTION MANUAL
TV Soundbar
AXS030BTU
346/3424
Important - Please read these instructions fully before installing or operating and keep for
future reference.
These instructions contain important information which will help you get the best
from your Soundbar and ensure safe and correct installation and operation.
For and help concerning set up and use of your TV
Please call the Customer Helpline: 0345 604 0105
Lines open: 9am - 8pm Monday to Saturday and 10am - 4pm Sunday

Advertisement

loading

  Related Manuals for Hitachi AXS030BTU

  Summary of Contents for Hitachi AXS030BTU

  • Page 1 INSTRUCTION MANUAL TV Soundbar AXS030BTU 346/3424 Important - Please read these instructions fully before installing or operating and keep for future reference. These instructions contain important information which will help you get the best from your Soundbar and ensure safe and correct installation and operation.
  • Page 3: Table Of Contents

    Contents Some Dos and Don’ts on the Safe Use of Equipment ............4 Safety Warnings ........................6 Support ..........................Unpacking ..........................9 Product Overview ........................10 Front View ..............................10 Top View ................................10 Bottom View ..............................10 Remote Control ........................11 Remove the plastic strip from the remote control............11 Inserting new batteries and replacing old batteries for the Remote Control....
  • Page 4: Some Dos And Don'ts On The Safe Use Of Equipment

    SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. read the operating instructions before you attempt to use the equipment.
  • Page 5 Used correctly, domestic batteries are a safe and dependable source of portable power. Problems can occur if they are misused or abused Here are some simple guidelines to safe battery use designed to eliminate any such problems. Replace the whole set of batteries at correctly, observing the plus and one time, taking care not to mix old minus marks on the battery and...
  • Page 6: Safety Warnings

    Safety Warnings Ventilation • Read all the instructions carefully before using the unit and keep them for future • To prevent the risk of electric shock or reference. • Retain the manual. If you pass the unit that curtains and other materials do not onto a third party make sure to include this obstruct the ventilation vents.
  • Page 7 Supervision • Children should be supervised to ensure that they do not play with the unit and the remote control. • Never let anyone especially children push anything into the holes, slots or any other openings in the case - this could result in a fatal electric shock.
  • Page 8: Support

    Support Technical experts are available 7 days a week Simple help and advice on setting up your digital equipment (image). Guidance on connecting other devices to your television such as a DVD player, Sky, home cinema system or a games console. Order spare parts, including that lost remote control.
  • Page 9: Unpacking

    Thank you for purchasing your new HITACHI Soundbar. We recommend that you spend some time reading this instruction manual Read all the safety instructions carefully before use and keep this instruction manual for future reference. Unpacking Remove all items from the packaging. Retain the packaging. If you dispose of it please do so according to local regulations.
  • Page 10: Product Overview

    Product Overview Front View Speakers Bluetooth LED Display Foot pad Status Display Top View 4 5 6 7 VOL – Button Button Switches the unit Decreases the volume. between ON and STANDBY modes. MODE Button VOL + Button Selects the input source. Increases the volume.
  • Page 11: Remote Control

    Remote Control button Switches the unit between ON and STANDBY modes. Mute button mutes ON or OFF. VOL- button short press reduces the volume, long press reduces continue to reduce the volume. VOL+ button short press increases the volume, long press increases continue to increase the volume.
  • Page 12: Handling The Battery

    Replace with a new battery. Insert the battery holder back into the remote control. Handling the Battery • Improper or incorrect use of batteries may cause corrosion or battery leakage, • Install the batteries correctly in the battery compartment. • Use only the battery type indicated in this manual.
  • Page 13: Connections

    Connections Using the AUX 1 Connection Use a (included) to connect the TV's audio output sockets 3.5mm to phono stereo audio cable AUX1 (L/R) sockets, turn on the unit and go to AUX 1(Phono) mode. to the soundbar's Connection interface of the unit 3.5mm to phono stereo audio cable (included) Using the AUX 2 Connection...
  • Page 14: Using The Optical Connection

    Press and hold the Input button on unit (or the BT button on remote control) for 5 seconds, your mobile device is disconnected, the BT NOTE: The BT ID for the unit is AXS030BTU. Using the OPTICAL Connection Use an optical cable (not included) to connect the DVD’s OPTICAL OUT socket to the soundbar’s OPTICAL socket, then turn on the unit and go to OPTICAL mode.
  • Page 15: Connecting To The Mains Supply

    Connecting to the Mains Supply • This unit is designed to operate with the provided mains adapter. • Connecting the unit to any other power source may damage the unit. Connect the power plug and adapter which are attached in the package, then connect the DC plug to the unit 24V DC in, then connect the power plug to mains socket.
  • Page 16: Special Operation

    Special Operations Compound keys on the Unit VOL- & VOL+: Hold down the VOL- & VOL+ at the same time for 5 seconds to mute or un-mute the unit; VOL- & VOL+ & POWER: Hold down VOL- & VOL+ & POWER at the same time for 5 seconds to reset the unit.
  • Page 17: Hints And Tips

    • The plugs and sockets are dirty. Wipe them with a cloth slightly is heard. moistened with an appropriate non-abrasive cleaning solution. If any functional abnormality is encountered, unplug the unit from the mains socket and reconnect it again. AXS030BTU Model Mains Adapter Adaptor Model Name: S065AQ2400270; Input: AC 100-240V~50/60Hz 1800mA;...
  • Page 18: Notes For Battery Disposal

    otes for battery disposal The batteries used with this product contain chemicals that are harmful to the environment. To preserve our environment, dispose of used batteries according to your local laws or regulations. Do not dispose of batteries with normal household waste. For more information, please contact the local authority or your retailer where you purchased the product.
  • Page 19: Guarantee

    Guarantee Product Guarantee This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.
  • Page 20: Contact Us

    Manufacturer: Hitachi Europe Ltd., Whitebrook Park, Lower Cookham Road, Maidenhead, Berkshire SL6 8YA U.K. Importer: Argos Ltd., 489 - 499 Avebury Boulevard, Central Milton Keynes, Buckinghamshire MK9 2NW U.K. www.hitachidigitalmedia.com...
