Midea FS40-12HR Owner's Manual

ELECTRIC FAN
CAUTION
Read Rules for Safe Operation and Instructions Carefully.
WARNING
1. If the supply cord is damaged, it must be replaced by manufacturer
or its service agent or a similarly qualified person in order to avoid
a hazard.
2. To protect against the risk of electrical shock, do not immerse the
unit, cord or plug in water or other liquid.
3. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
4. When the appliance is not in use and before cleaning, unplug the
appliance from the outlet.
5. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without supervision.
6. When the fan was assembled, the rotor blade guard shall not be
taken off anymore
- Prior cleaning unplug the fan.
- The rotor guard shall not be dissembled/opened to clean the
rotor blades.
- Wipe the fan enclosure and rotor blade guard with a slightly
OWNER'S MANUAL
damp cloth.
DC STAND FAN RULES FOR SAFE OPERATION
1. Never insert fingers, pencils, or any other object through the grille when fan is
MODEL:FS40-12HR running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
Please read the instruction manual carefully before use and safekeeping.
5. Household use only.
MIDEA.COM | 4008899315
1
PART FIGURE GRILL & FAN BLADE ASSEMBLY
Front Grill Blade Rear Grill
Shaft Motor 1. Unscrew the spinner clockwise (or take the spinner out from the bag) and the
plastic nut counterclockwise to remove both of them. Fix the rear grill to the
motor then tighten the plastic nut again. (Fig.4)
2. Insert the blade into shaft, and make sure the rotor shaft pin is fitted into groove
of the blade. Turn the spinner counterclockwise to tighten the blade. (Fig.5)
Center Piece
Remote Control Hook 3. Fix the front grill and the rear grill with circlip clip and then use the fasten clip to
Circlip
tighten the fan grill. (Fig.6)
Control Part
Grill Clip
Plastic Nut Fastening Knob
Tube
Tighten
Loosen
Female terminals
Spinner
Round Base
Fig.4 Fig.5
Butterfly Screws For Fixed Base
Fig.7
Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between On/Off
the real object and the illustration in the drawing shall be subject to the real subject.
Drive plate
ASSEMBLY INSTRUCTION
OSC PRO/Timer
1. Take out the base tube, three butterfly screws for fixed base and the round base
Mode
from the packing carton;
2. Insert the tube to the round base, be sure to make the positioning screw align with
OPERATING INSTRUCTIONS
the base;
Plug in the power adapter, after a "beep" tone, the fan is on standby.
3. Screw the three butterfly screws into the holes on the tube and tighten them;
I. Remote Controller (Fig.7)
4. Loosen the fastening knob, adjust the height of inner tube and tighten the knob.
5. Take out the control part of the fan from the packing carton, loosen the fastening " " ON/OFF KEY
Press this button under standby mode, the fan starts at normal wind of level 10, then
screw at the back of the box, insert the inner tube into the bottom hole, make sure
the panel displays "normal wind, level 10". Press this button during working, the fan
that the fastening screw and the fastening knob in the same position. turns off to standby mode.
6. Usage of the remote control hook: make the straight face of hook up, clip the hook After start, rotate the drive plate clockwise, the fan increases from the current level
circulation in the following manner: ...... silent 01 → silent 09 → normal wind 01 →
to the inner tube along with the opening, the hook can be moved up and down
...... → normal wind 26 → natural wind → sleep wind→ smart wind → silent 01 →
along the tube (Fig.1). The hook of the remote control may be linked to the
......, rotate the drive plate counterclockwise, the fan will decrease from the current
hole for storage when not in use. (Fig.2) level in the following manner: ...... smart wind → sleep wind → natural wind → normal
wind 26 → ...... → normal wind 01 → silent 09 → silent 01 → smart wind → ......
" " MODE KEY
Fig. 1 Fig. 2
Repeat press this button, the wind will be switched in order of "normal wind - natural
wind - sleep wind - intelligent wind - normal wind - ... ". Normal wind: the wind speed
Straight face Hook hole
is constant set by the wind level, when the "normal wind" icon is lit, 01 - 26 levels are
Hook
normal wind; natural wind: Fan will simulate natural wind according to pre-
Inner tube
programmed manner, the wind speed changes in accordance with the program,
which makes people feeling idle, naturally and it likes to be in the nature. Smart wind:
based on the temperature and wind speed when it starts, its speed changes
Opening according to the temperature. When the temperature is below 20°C, the fan stops,
when the temperature rises to 20°C, it continues automatically at the stopped level.
Silent: fan blows in silent mode; it has a total of nine levels for adjustment.
2 2 3
" " OSC KEY
IV. Height Adjustment
After the fan starts, repeatedly touch this button to start or stop oscillation.
Lowing: lift up the head with a hand, unscrew the fastening knob counterclockwise
with the other hand, slowly lower the head to an appropriate height, and tighten the
" " PRO KEY
knob clockwise. Rising: lift up the head with a hand, unscrew the fastening knob
Under power-on state, timed power-off can be set. Press the PRO button; it starts the
counterclockwise slowly with the other hand, rises up the head to a proper height,
timing power-off state. "Timing" and icon displayed on the fan display will flash once
and tighten the knob clockwise.
per second, the rotate the drive plate clockwise, the fan display will display 0.5 → 1.0
→ ...... → 7.5 → 8.0 → 00 → 0.5 → ...... in cycle, rotate the drive plate counter-
V. Pivoting Angle Adjustment
clockwise, it cycles as 8.0 → 7.5 → ...... → 0.5 → 0 0 → 8.0 → .......
When adjust the pivoting angle, fix the guards with hands and reverse the head of fan.
When set a time, 5 seconds without any operation, the timing on the display flashes
Note: Do not forcibly twist the fan in order to avoid damage to the fan.
twice and beep to refer successfully settings, if there is any button operation in five
seconds (except for on/off button), the time is successfully set and the fan returns to VI. Screen-off Function
current state immediately, "Timing" and icon stops flashing, if the timing button is
Press the "On/Off" button for three seconds, the screen will turn off and the fan is still
pressed in five seconds then timing is cancelled. If there is time setting, then "Timing" running. Press any button [not include "On/Off" button), the screen will light up.
and icon is lit, if not, it is off. When setup is successful, the display returns to display
Fig.6 Remote control does not have this feature.
the wind level.
Fig.8 Under standby mode, press the PRO button to set power-on time, "PRO" and icon is VII. Forced Shutdown
Remote controller lit, the operation mode please refers to timed power-off; rotate the drive plate to The fan will be turned off when there is no operation of the control within 12 hours.
Battery
Battery cover adjust the time. After adjustment, the set time will be displayed on the screen. To
cancel a time setting, user only need to repeatedly press the PRO button.
BATTERIES INSTRUCTIONS (Fig.8)
Inquiry: Under working state, press forward/timing button to enter the timing status,
user can check the set time, and user can re-set the time in five seconds; if no Batteries should be installed before using the remote control. It uses a 3 -volt button
operation within five seconds, the time shown on the screen flashes twice and battery.
returned to the wind level.
(1) Open the battery cover;
(2) install a new battery, pay attention to the battery polarity (+ and -);
II. Control Panel (Fig.9)
Fig.9 (3) Close the battery cover.
• On/Off button
Same as them on remote control.
HOW TO USE THE REMOTE CONTROLLER CORRECTLY
• Function button
1. Under working state, short press the function 1. The remoter controller must point to the receiving window of the fan box when it
button, the fan will alternate between oscillation is used;
and fix; Long press the button, the fan enters
2. The remoter controller can be normally used within five meters and 30 degrees
into the timing function, refer to the operating
from the fan;
instructions of PRO button on remote control
3. Avoid direct sunlight on the receiving window, so as not to affect the receiver's
(To cancel the timer, long press function button).
effect;
2. Under standby mode, short press of the function
4. Remove the built-in batteries when do not use the remote control for a long time
button is invalid; Long press the function button,
or before the batteries are leaked.
the fan enters into the appointment starting
function, refer to the operating instructions of
OVERHEAT PROTECTION OF THE MOTOR
PRO button on remote control (To cancel the
timer, long press function button).
The windings of the motor have a thermal-fuse that burns out and the fan switches
off and temperature of the motor is no longer going up so that plastic parts of the fan
III. Tilt Adjustment
don't subject to deformation so far so to be burned by the overheat if the motor is
To adjust the air flow upward or downward, push
On/Off button Function button overheat for any unexpected reason.
the grilles lightly to the desired direction.
4
MAINTENANCE INSTRUCTION
The fan requires little maintenance. Do not try to fix it by yourself. Refer it to
qualified service personnel if service is needed.
1. Before cleaning and assembling, fan must be unplugged.
2. To ensure adequate air circulation to the motor, keep vents at the rear of the
motor free of dust. Do not disassemble the fan to remove dust.
3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.
4. Do not use any abrasive detergent or solvents to avoid scratching the surface.
Do not use any of the following as a cleaner: gasoline, thinner.
5. Do not allow water or any other liquid into the motor housing or interior parts.
CLEANING
1. Be sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with a soft cloth moisten with mild soap.
Thoroughly remove soap film with dry cloth.
5 6
GD Midea Environment Appliances Manufacturing CO.,LTD.
Midea Industrial Park, Dongfu Road, Dongfeng Town, Zhongshan, Guangdong, China
