Evenflo Spectrum Owner's Manual

Booster seat, with backrest/without backrest 18 to 49.8 kg 40 to 110 lbs./112 to 145 cm 44 to 57 in. at least four years old
Hide thumbs
Table of Contents

Advertisement

Quick Links

Spectrum™

Booster Seat

Owner's Manual
Keep for future use
Child Requirements
With Backrest*
18 to 49.8 kg
(40 to 110 lbs.)
112 to 145 cm
(44 to 57 in.)
At least four years old
Without Backrest*
18 to 49.8 kg
(40 to 110 lbs.)
112 to 145 cm
(44 to 57 in.)
At least four years old
* See page 1 for complete requirements.
Para instrucciones en Español,
llamar al: 1-800-233-5921
WARNING:
To reduce the risk of serious injury
or death, read this owner's manual prior
to installing and using this child restraint.
© 2016 Evenflo Company Inc.
25701292
9/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spectrum and is the answer not in the manual?

Questions and answers

Related Manuals for Evenflo Spectrum

Summary of Contents for Evenflo Spectrum

  • Page 1: Booster Seat

    Spectrum™ Booster Seat Owner’s Manual Keep for future use Child Requirements With Backrest* 18 to 49.8 kg (40 to 110 lbs.) 112 to 145 cm (44 to 57 in.) At least four years old Without Backrest* 18 to 49.8 kg (40 to 110 lbs.)

  • Page 2: Table Of Contents

    More children are killed every year as passengers U.S. REGULATORY NOTICE in car crashes than by any other type of injury. This booster seat meets all applicable requirements of To reduce the risk of SERIOUS INJURY or DEATH, read Federal Motor Vehicle Safety Standard 213. this owner’s manual and your vehicle owner’s manual CANADIAN REGULATORY NOTICE before installing and using this child restraint.

  • Page 3: Warnings

    WARNING WARNING Airbag Warnings Location Warnings • DO NOT use this restraint in the front seat of a vehicle • According to statistics, children are safer when equipped with an active air bag. Air bags may cause properly restrained in a rear seating position than serious injury or death to children 12 and under.

  • Page 4: Safe Practices

    WARNING Recall Information • Child restraints could be recalled for safety reasons. Additional Warnings You must register this restraint to be reached in a • DO NOT use this booster seat if it has been involved in recall. Send your name, address, e-mail address if an accident.

  • Page 5: Visual Glossary

    Visual Glossary Visual Glossary Your vehicle may appear significantly different than Front Seat Lap and pictured. Consult your vehicle Owner’s Manual to help Shoulder Belts identify your vehicle components. Headrests Headrest in front of Back Seat child must be in the Belt Buckles lowest position.

  • Page 6: Child Seat Features

    Child Seat Features Child Seat Features Description Front LYF+Guard Advanced Compression Technology™ Seat Pad Armrest Cup Holder* Lap Belt Guide Base Shoulder Belt Guide Back Instruction Storage Area (Under the Base) Shoulder Belt Clip * Not all features are available on all models. Styles may vary.

  • Page 7: Assembling Your Booster Seat

    Assembling Your Booster Seat Attach the seat pad to the backrest assembly. Assemble the backrest. Insert the lower part of the Connect elastic seat pad headrest into the grooves on the backrest , as straps to the hooks on shown. backrest assembly.

  • Page 8: When To Put Your Child In A Booster Seat

    When to Put Your Child How can you tell if your child is ready to transition to a booster seat? in a Booster Seat You should consider using a booster seat if the following conditions apply: • The child is mature enough to sit in the booster seat and Booster seats raise the child up and help to position the not put the belts under their arm or behind their back.

  • Page 9: Using Your Booster Seat With The Backrest

    Using Your Booster Seat Installation Checklist With the Backrest Place the booster seat on the vehicle seat. Set the child in the booster seat. Child Requirements Make sure the child’s back and bottom are flat Weight: 18 – 49.8 kg (40 – 110 lbs) against the back and bottom surfaces of the Height: 112 –...

  • Page 10: Using Your Booster Seat Without The Backrest

    Using Your Booster Seat Installation Checklist Without the Backrest Remove the backrest from the booster seat. (See Removing the Backrest, page 19.) Child Requirements Place the booster seat on the vehicle seat. Weight: 18 – 49.8 kg (40 – 110 lbs) Set the child in the booster seat.

  • Page 11: Adjusting The Headrest

    Adjusting the Headrest Removing the Backrest Lay the booster seat on its front. To adjust the headrest , pull and hold the adjustment Pull lever on the bottom of the base handle then slide the headrest up or down. The remove the backrest from the base.

  • Page 12: Using The Shoulder Belt Clip

    Using the Shoulder Belt Clip Using the Cup Holders Note: Use the Shoulder Belt Clip only when necessary to To use Cup Holders, slide them out from the base. position the belt so it lays across the child’s chest midway between his/her shoulder and neck.

  • Page 13: Removing The Seat Pad

    Removing the Seat Pad Care and Cleaning • Plastic parts may be wiped clean with mild soap and water and dried with a soft cloth. Do not use abrasive Remove the seat pad cleaners or solvents. from the backrest • Take care not to damage any labels. assembly.

  • Page 14: Replacement Parts

    EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS HEREBY DISCLAIMED. EVENFLO SHALL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL OR PUNITIVE DAMAGES OF ANY KIND FOR BREACH OF THE EXPRESS LIMITED WARRANTY ON THIS PRODUCT, OR ANY WARRANTY IMPLIED BY OPERATION OF LAW.
  • Page 15 • www.evenflo.com • USA:1-800-233-5921 8 AM to 5 PM E.T. • Canada: 1-937-773-3971 • México: 01-800-706-12-00...
