axis. With the switch in the up position, it will be at low rate, as indicated by the "L" at the end of
the line. In the mid position, it will be mid rate, and at the down position, it will be at high rate. You
can also include throttle if you'd like, to have different expo curves for each of the flight modes.

Mixer (5/11)

The function of the mixer is to take the inputs, perform some function on them and route them to
the output channels. Since selection is totally free you have a very flexible system which is
extremely powerful and very quick to boot.

Main Screen

When you enter the screen for the first time you'll probably see a list like so:
MIXER
CH1 100% THR
CH2 100% AIL
CH3 100% ELE
CH4 100% RUD
CH5 100% FULL GEA
CH6 100% HALF ID1
What this is telling you is that the rudder stick's input is being routed with a weight of 100% to
CH1. Same for the elevator, throttle and aileron. Though not visible now you can also see the
switch column which will tell you if a switch is assigned to the mix and also a crv (curve) column
which tells you what curve is applied to that mix.
When you scroll down you'll see that sometimes the weight is being highlighted and sometimes
the channel's number is underlined. When the weight is highlighted, pressing [LEFT]/[RIGHT] will
edit that value and pressing [MENU LONG] will enter the Edit Mix screen and allow you to edit that
mix.
When the channel's number is underlined, pressing [MENU LONG] will insert a new mix for that
channel and take you to the edit mix screen for it.
You can also press [MENU]. This will highlight the mix. Then you can press [UP]/[DOWN] to move
or copy the mix. Notice that moving or copying is decided by whether you press up or down on the
first press after highlighting the mix. If you first try to move it down it will be copied. Subsequent
presses of [UP]/[DOWN] will move the copy up or down until you press [MENU] or [EXIT].
Pressing [UP] will move the mix without copying it. Again, subsequent presses of [UP]/[DOWN] will
move the copy up or down until you press [MENU] or [EXIT].
If the Trainer function is enabled and active, the four values RUD, ELE, THR and AIL are changed to
the PPMin values selected in the TRAINER menu.
