Dynojet POWER COMMANDER V Installation Manual page 3

FIG.A
Remove
FIG.B
FIG.C
22-079 www.powercommander.com
1 Remove the seat.
2 Remove the cosmetic covers around the fuel tank and remove the fuel tank.
3 Unplug the ECM.
Unplug
4 Remove the air box (Fig. A).
5 Lay the PCV in the tail section and route the harness down the right side of the
motorcycle.
6 Locate and unplug the stock Crank Position Sensor connectors (Fig C).
Unplug
This is a pair of BLACK 2-pin connectors just forward of the battery.
2016 Yamaha XSR900 - PCV - 3
