Dynojet POWER COMMANDER V Installation Instructions

2002-2007 suzuki hayabusa

Hide thumbs Also See for POWER COMMANDER V:

2002-2007 Suzuki Hayabusa

I n s t a l l a t i o n I n s t r u c t i o n s

PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

20-023

www.powercommander.com

2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com

PARTS LIST

Power Commander

USB Cable

Installation Guide

Power Commander Decals

Dynojet Decals

Velcro strips

Alcohol swab

THE IGNITION MUST BE TURNED

OFF BEFORE INSTALLATION!

THE LATEST POWER COMMANDER

SOFTWARE AND MAP FILES CAN BE

DOWNLOADED FROM OUR WEB SITE AT:

www.powercommander.com

2002-2007 Suzuki Hayabusa - PCV - 1

Need help?

Do you have a question about the POWER COMMANDER V and is the answer not in the manual?

Page 1 Power Commander USB Cable Installation Guide 2002-2007 Suzuki Hayabusa Power Commander Decals Dynojet Decals I n s t a l l a t i o n I n s t r u c t i o n s Velcro strips Alcohol swab THE IGNITION MUST BE TURNED...
Page 2 Crank- Do NOT connect anything to this port unless plug. instructed to do so by Dynojet. It is used to transfer crank trigger data from one module to NOTE: If you tin the wires with solder it will make another.
Page 3 FIG.A Remove the main seat and the passenger seat. Hold the front of the fuel tank up using the prop rod located in the trunk area. unplug Locate the connector from the main wiring harness to the injector rail and unplug this connector as shown in Figure A. Note: This connector is white in color. FIG.B Attach the connectors from the PCV to the stock wiring harness connectors as shown in Figure B. Ground wire FIG.C ground wire Route the PCV wiring along the inside of the frame towards the battery. Attach the ground wire from the PCV to the negative side of the battery as shown in Figure C. 20-023 www.powercommander.com 2002-2007 Suzuki Hayabusa - PCV - 3...
Page 4 FIG.D Using the supplied velcro, secure the PCV in the rear section of the trunk as shown in Figure D. Make sure to clean both surfaces with the alcohol swab before attaching. Bolt fuel tank back into place. 20-023 www.powercommander.com 2002-2007 Suzuki Hayabusa - PCV - 4...
