  • Page 1 P9-0133-B ver. 2.0.5 - October 2015...
  • Page 2 Medema A/S Serial number: ___-______________-______-_______ Delivery date: ________________ Year 20______ This vehicle was supplied by: Date: User guide P9-0133-B 2 of 62 Version 2.0.5 - 2015...

  • Page 3: Table Of Contents

    Electric seat adjustment ............14 Seat rotation ................15 Steering column ..............16 Serial number................. 17 Driving the Mini Crosser M1 HD .......... 18 Mini Crosser M1 as a ”seat” in a vehicle......21 Transportation ............... 21 Interoperability............... 21 ............ 23 ............
  • Page 4 Medema A/S Introduction to the Ergo2 seat ..........46 Introduction to the Eblo seat ..........52 Troubleshooting ..............54 Programming ................. 57 Technical data ................ 57 User guide P9-0133-B 4 of 62 Version 2.0.5 - 2015...

  • Page 5: Symbols

    For safety reasons the vehicle must not be lent to persons who are not completely familiar with it. The vehicle is designed for one person only. The Mini Crosser M1 HD has been designed for users weighing max. 250 kg. Contagion! Note! linoleum.

  • Page 6: Help For The Visually Impaired

    Medema A/S Help for the visually impaired manual in PDF format. You can enlarge the PDF manual on your PC monitor to suit your needs and preferences. FSN (Field Safety Notice) All information concerning safety can be found at www. we will notify our customers directly (FSN).

  • Page 7: Introduction

    - we recommend that you read this User Manual section entitled “Driving the Mini Crosser M1 HD”. The Mini Crosser M1 HD is designed for safe travel for at least 10 service must be carried out by an authorised workshop.

  • Page 8: Declaration Of Conformity

    Use: (Prescribed use in User Manual) Model No: M1 HD Complies with the Medical Device Directive 93/42/EEC The product is made in accordance with the harmonized Crossers and their chargers. The product is risk analysed in accordance with the harmonized standard DS/EN ISO 14971:2007-04-10 2.

  • Page 9: Medema A/S Warranty

    Medema A/S Medema A/S Warranty intact. The warranty will be void if the product has been removed or appears to have been mishandled. There is a 5-year warranty against breakage and corrosion of the undercarriage. Medema A/S. Items returned under a warranty claim must be suitably packaged to prevent damage during transport.

  • Page 10: Control Panel

    Medema A/S Control panel Avoid subjecting the control panel to jarring and knocks. Take care when driving and avoid hitting obstacles. The manufacturer accepts no liability in respect of the panel. Battery indicator Hazard warning lights Light switch Speed selector Handbrake Indicator lights, R/L Indicator lights,...
  • Page 11 Medema A/S Designation Description To start the vehicle: Turn the key to driving position (1) When the Mini Crosser the electrical system. The check lasts half a second. If the be able to move until you have turned the key to 0 and back to 1. Speed selector The tortoise in minimum position indicates the lowest speed range.

  • Page 12: Preparations / Adjustments Prior To Use

    Medema A/S Preparations / Adjustments prior to use Adjusting the height of the seat Lift the seat off and remove the rear cover. Pull the release out and adjust the seat tube to the desired position. See the picture on the next page. Check that the seat height is correct and let go of the release.
  • Page 13 Medema A/S Loosen the counter nut. Loosen the screw. Use spanner, 17 mm. Adjust the seat post to the desired position. The seat post is marked with a ring at each centimeter. Tighten the screw, here after the counter nut. Mount the seat.

  • Page 14: Electric Seat Adjustment

    Medema A/S Seat tube Release holes for adjusting the seat tube. The release must be in a hole for the seat to be stable. Electric seat adjustment an optional extra. reduces the speed by 50% when the seat is raised more than 7.5 cm.

  • Page 15: Seat Rotation

    Medema A/S Seat rotation Pull the release lever back. The seat can be rotated 90° to and holds it in place at 45° intervals. Other seats that can be supplied for the Mini Crosser work on similar principles. The release lever is normally mounted on the IMPORTANT! The Mini Crosser is most stable when the seat is in its lowest position.

  • Page 16: Steering Column

    Medema A/S Steering column Can be adjusted forward/back with the release lever. Pull down on the lever and pull the handlebars closer for a good driving position. Use the lever again and push the steering column forward to make it easier to get out. The height of the steering column can be adjusted approx.

  • Page 17: Serial Number

    Medema A/S Serial number All vehicles have a serial number plate showing the year of production and serial number. The same serial number can also be found on the front of the User Manual. Please quote this number when making inquiries about Maximum user weight Model description Vehicle’s unladen weight inc.

  • Page 18: Driving The Mini Crosser M1 Hd

    Mini Crosser. In general the following method should be followed: • Make sure that the Mini Crosser M1 HD is off (switch turned to 0) the accelerator was touched inadvertently. • Make sure that the brake is on. (Lever for disengaging motor in top position.)
  • Page 19 Medema A/S General safety advice Make sure that the backrest is upright and the seat is as low as possible. Positioning belts are recommended if the user is unable to maintain a good driving posture independently. Reduce speed immediately if you feel you are losing control. Always use the indicators when changing direction.
  • Page 20 Medema A/S gradients than it has been tested as dynamically stable for. The same applies to driving down such gradients. In such cases there is an increased risk of the Mini Crosser tilting and even tipping over. So be extra careful in following the driving tips given below.

  • Page 21: Mini Crosser M1 As A "Seat" In A Vehicle

    Medema A/S Note! The driving distance of the Mini Crosser will be reduced when with low tyre pressure. user’s responsibility to familiarise him/herself with the relevant legislation. Mini Crosser M1 as a ”seat” in a vehicle motor vehicle. This option does not apply for the cabin model. Transportation The Mini Crosser M-model is suitable for both land and air transportation.
  • Page 22 Medema A/S Electromagnetic compatibility If the Mini Crosser starts making involuntary movements or if is safe to do so. In certain circumstances a Mini Crosser can set off shop alarms. Crossers in an environment with electromagnetic noise. There can affect the Mini Crosser. Sources of such noise include radio phones.
  • Page 23 Medema A/S Up kerbs • Stop at right angles to the kerbstone about 5-10 cm away from it. • Lean forwards. • Accelerate moderately so that your vehicle can overcome the is up. • route. Down kerbs • Lean back. •...
  • Page 24 Medema A/S Up a ramp/hill • There is a risk of tipping over backwards if the seat is pushed • Pull the seat forward! Check that any ramp is stable. • Lean forwards. • Accelerate moderately so that your vehicle can overcome the obstacle.
  • Page 25 Medema A/S Across a slope • Lean into the slope. • Avoid sudden and sharp movements. This is particularly relevant when reversing. • Always drive at low speed. The Mini Crosser is at risk of overheating on very long and high user weight.

  • Page 26: Anti-Tilt Wheels / Stabilisers

    Medema A/S Anti-tilt wheels / stabilisers case of incorrect weight distribution or careless driving there is a risk of tipping over. circumstances. (See picture below) (Anti-tilt wheels / stabilisers are optional extras.) Anti-tilt wheels User guide P9-0133-B 26 of 62 Version 2.0.5 - 2015...

  • Page 27: General Care And Maintenance

    Medema A/S General care and maintenance A Mini Crosser M1 HD does not require much maintenance. following should be checked regularly: • • Tyre wear. • box under the seat dry. • Battery charging. Never wash the Mini Crosser with a high-pressure cleaner or direct water jet! This could damage the Mini Crosser’s...

  • Page 28: Insurance

    (For further information see the Service Manual.) Insurance In the eyes of the law a Mini Crosser M1 HD with a maximum required. Most contents/home insurance policies include third-party liability insurance for cyclists and so also cover Mini Crosser M1 HD users.

  • Page 29: Batteries

    Medema A/S Batteries batteries. They do not generate gas and do not have to be topped up with water. Battery weight 56 Ah = 21 kg 80 Ah = 26 kg 110 Ah = 38 kg Charging Please NOTE that the Mini Crosser can be equipped with several types of charger (ask your dealer for information on the various types).

  • Page 30: Battery Disposal

    Medema A/S The charging time will be extended by approximately 60% at a temperature of +5° C compared to a temperature of +20° C. absorb the current. It is recommended to charge the Mini Crosser in a heated room. as well as at low temperatures. The battery capacity at -10°C is half of the capacity at +20°C.
  • Page 31 Medema A/S below. Make sure that the terminals are properly tightend. For the same reason there must not be any burrs on the cable terminals. Polarity of charging plug Connect the charging plug to the 3-pin NEUTRIK NC3MX charging plug socket on the steering column.

  • Page 32: Storage

    Medema A/S Note charger to start charging the battery. There is no warranty on batteries that have been damaged as a result of deep discharging. If you are not using the Mini Crosser for a longer period of disconnect the one pole to the fully charged batteries. This way there will be no consumption of standby power.

  • Page 33: Changing The Wheels

    Medema A/S Changing the wheels If you get a puncture in one of the pneumatic tyres or if a instructions below. Tyres and inner tubes can be purchased from the authorised dealer who supplied the Mini Crosser. The Mini Crosser must be TURNED OFF before you start. Changing the wheels on the 4W model Remove the hubcap.
  • Page 34 Medema A/S the 5 screws (5 mm Allen key). Replace or patch the tube. Ensure that there are no foreign objects in the tyre before the tube is replaced. Pump air into the tube so that it is positioned In this way the tube will Pump up the tyre to the correct pressure.

  • Page 35: Fuses

    Medema A/S Fuses The Mini Crosser has the following protection systems: • motor. This protection is integral to the control system and cannot be adjusted. It prevents both the control system and the motor from being overloaded. In the event of overload the current to the motor is reduced - full speed and traction can be resumed after the motor has cooled down for 2-5 minutes.

  • Page 36: Brakes

    Medema A/S Brakes There are four braking systems on the Mini Crosser: • Motor brake - adjusts vehicle speed also when going downhill. • Magnetic brake - the magnetic brake is automatic and the Mini Crosser can be stopped instantaneously by turning the key switch.

  • Page 37: Disengagement

    Medema A/S Disengagement • Turn the key to (0) position. • Push the disengagement lever at the back down. The motor brake is now disengaged and the vehicle can be NOTE! The motor brake must never be disengaged on sloping terrain.

  • Page 38: Transporting By Motor Vehicle

    Medema A/S Transporting by motor vehicle The Mini Crosser must always be restrained and the handbrake locked during transport in a motor vehicle or trailer. between the rear lights and by the front bumper. Important! If you drop the Mini Crosser from a height of half a metre or destroyed.
  • Page 39 Medema A/S Dahl Engineering belt set for securing in motor vehicles. Item No. C2-0242 ALWAYS use four belts at the back and two at the front. vehicle and the four eyes welded to the Mini Crosser. The belts MUST be attached within the angles shown in the picture for optimum security.
  • Page 40 Medema A/S Attachment point Attachment point Greater than the anchorage points on the Greater than Mini Crosser the anchorage Centre line points on the Mini Crosser User guide P9-0133-B 40 of 62 Version 2.0.5 - 2015...
  • Page 41 Medema A/S can be lifted off and the handlebars folded down. This reduces the maximum height to 69 cm. The Mini Crosser can be used as a seat during transport in with approved four-point belts attached to the restraint points provided on the Mini Crosser.

  • Page 42: Transporting By Plane

    Medema A/S Remember to turn the Mini Crosser off during transport. Turn the key to 0. occupies one of the seats in the motor vehicle. All other things Transporting by plane require: • • the air to be let out of the tyres •...

  • Page 43: Dimensioned Drawing, Mini Crosser M1 Hd

    Medema A/S Dimensioned drawing, Mini Crosser M1 HD M1 HD: 400 mm M1 HD+: 320 mm 1030 mm 1400 mm M1 HD+: Fotplassen reduseres ved bruk av ekstra store batterier. User guide P9-0133-B 43 of 62 Version 2.0.5 - 2015...

  • Page 44: Introduction To The Ergo Standard Seat

    Medema A/S Introduction to the Ergo Standard seat Lever for seat rotation tilted up. The seat can be rotated 45°. The lever is spring loaded and the seat locks automatically when the lever is released. on the left side. Lever for seat forward / back To release the seat on the slide Then the seat can be moved forward or back as required.
  • Page 45 Medema A/S Adjusting the angle of the backrest The angle of the backrest can be adjusted by about 30°. This can be done by undoing the adjusting screw and changing the position of the spacer. Do the screw up again after making the adjustment.

  • Page 46: Introduction To The Ergo2 Seat

    Medema A/S Introduction to the Ergo2 seat Lever for rotating the seat The lever must be pulled back to rotate the seat. The seat can locking at each 45°. when the lever is released. This lever is located on the right side as forward in order to rotate the seat instead of pulling back.
  • Page 47 Medema A/S Lever for fwd/bw adjustment of the seat. Pull the lever up to release the seat on the slide rail. Then the seat can be moved forward or backward as desired with 200 mm of travel. place in the closest position. Height adjustment of armrest Unzip the zipper on the side of...
  • Page 48 Medema A/S Adjusting the angle of the armrests The adjustment screw makes it possible for the armrest to be adjusted 60°. The armrest can be tilted up to facilitate entry and exit. Adjusting the angle of the backrest. The angle of the backrest can be adjusted 45°...
  • Page 49 Medema A/S Backrest forward / back. on both sides. The depth of the seat can now be adjusted by sliding the seatback forward and back. Shown here with 320 mm seat depth. The seatback can then be moved backward to the edge of the rail and forward to the desired position.
  • Page 50 Medema A/S Height adjustment of headrest. Press the button and the headrest can be raised and lowered as needed. Adjustment of the headrest forward and backward. The headrest can be tilted forward and backward as needed. User guide P9-0133-B 50 of 62 Version 2.0.5 - 2015...
  • Page 51 Medema A/S Mounting of basket on the seat. (Optional accessory) Complete mounting kit for basket. Two brackets and four Allen screws. Unzip the zipper and position the brackets in front of the two predrilled holes. Mount the basket on the brackets and now it is ready for use.

  • Page 52: Introduction To The Eblo Seat

    Medema A/S Introduction to the Eblo seat The lever for turning the seat Pull the lever up to release the seat. The seat can then be at each 45°. the seat is locked automatically when the lever is released. be positioned on the left side. Lever for fore/aft adjustment of the seat Pull the lever up to release the...
  • Page 53 Medema A/S Adjusting the angle of the backrest 10° The angle of the backrest can be adjusted approximately 60° 140°. This is done by lifting this lever. Adjusting the lumbar support The lumbar support can be adjusted by turning the handle counter-clockwise.

  • Page 54: Troubleshooting

    Medema A/S Troubleshooting remedies. Problem Possible causes Remedy The Mini Crosser will not The key has not been Turn the key and wait 5 turned to start. sec. before activating the accelerator. The battery indicator is The batteries are Charge the batteries. not lit.
  • Page 55 There is a fault in the Push the charging plug all charging plug for the Mini the way in and repeat the Crosser M1 HD. charging process. Read the operating instructions for the charger. The “ready” lamp on the The fuse in the charger Contact supplier.
  • Page 56 Medema A/S Lamps Causes Remedy 6 lamps The S180/200 is Stop the unit and wait 3-5 prevented from driving. minutes before restarting. Inhibit 2 is active. This Turn the key to 0 and then may be due to the to 1 to reset the fault. battery charger being Contact supplier.

  • Page 57: Programming

    Medema A/S Programming etc. Technical data M1 HD 4W General information: Transport height without seat (Steering column folded 69 cm down) Total length: 140 cm Total length incl. anti-tilt wheel: Total width: 68 cm Total weight incl. batteries and Ergo Std seat.
  • Page 58 Medema A/S M1 HD 4W M-127-3-065 13x3.00-8” ext. Ø340 mm Wheel black - T and M-model T-127-3-068 13x3.00-8” ext. Ø340 mm Wheel black puncture free - T and M-model Class C Seats: Effective seat width: Ergo Standard Spinalus Ergo2 48 cm...
  • Page 59 24 V - 2 W Standard colour Grey - metallic Noise: Noise level 60db The Mini Crosser M1 HD complies with the following standards: The Mini Crosser has been tested for the requirements EN 12184 described in: ISO 7176-8 fatigue strength...
  • Page 60 Medema A/S M1 3W M1 4W Diverse informationer: 8 kg 8 kg 15 kg 15 kg Wheel bolt must be tightened with 50 Nm 50 Nm User guide P9-0133-B 60 of 62 Version 2.0.5 - 2015...
  • Page 61 Medema A/S Weight of the seats This is our standard Ergo 45 cm seat, the heaviest part of the M2-MaxX to remove. The label showing the seat’s weight is located as shown above. Seat model Weight Eblo seat 19 kg Ergo seat 34 cm.
  • Page 62 medemagroup...
