QUICK INSTALLATION GUIDE (QIG)

INSTALLING - CyberView X5- for PC (Windows) User
a. Insert CD into the computer CD/DVD drive and explore the contents of the CD. Page
3 of 38Double click the "CyberView" icon to begin the installation process. Follow the
onscreen prompts to complete the installation process.
NOTE: Make sure the scanner is NOT connected to the computer during the
CyberView driver installation.
b. Restart computer once the installation process is complete.
Installing the Hardware
a. Connect the slide scanner to a power source. The hardware drivers automatically loaded
with the CyberView X installation process.
1. Locate the power switch on the lower left side of the scanner. M ake sure the
scanner is TURNED OFF.
2. Plug the AC adapter into an AC power source FIRST before plugging it into the
scanner.
3. Attach the USB cable to the computer using the standard USB adapter end.
Attach the USB adapter end of the cable to back panel of the scanner.
b. Ensure the scanner does NOT have a slide magazine loaded, turn the scanner ON.
The calibration cycle on the scanner will start automatically and will take several
minutes to complete. A green light will flash while the calibration is in progress.
The slide transport arm will move in and out of the scanner. MAKE SURE THERE IS
ENOUGH ROOM IN FRONT OF THE SCANNER FOR THE SLIDE TRANSPORT ARM TO
EXTEND FULLY; DO NOT PUSH THE ARM BACK DURING CALIBRATION.
WINDOWS SYSTEMS INSTALLATION: DURING DRIVER INSTALLATION A WARNING DIALOGUE BOX MAY
APPEAR, IF THIS IS THE CASE PLEASE SELECT "INSTALL THIS DRIVER ANYWAYS".
NOTE: Not all PC's will display the found new hardware window, most will install in the background
Should it occur (Generally on XP/Vista systems) follow the steps below
1. Then In the "Found New Hardware Wizard" window, select "Search automatically or Browse computer for
driver software."
2. Next In "Completing the Found New Hardware Wizard" window, Click "Finish" to finalize the hardware
installation.
Circle in OFF / Line in ON
3
