CyberView X5-MS User Manual page 12

Universal Magazine
NOTE: Use only Universal Magazines with the DIN 108 labeling. Other magazines may result in problems and
could damage the scanner and VOID the warranty.
Pull out the slide transport arm all the way, gently press the orange adapter on the slide transport arm, move the
adapter on the slide transport arm to the front until it snaps in at the tip of the tappet arm.
Push the slide transport arm back into the scanner.
Load the magazine from the back in the respective guiding rails of the magazine tunnel until it touches the
slide transport arm.
c. Place the slide magazine into the scanner from the left side until it
touches the slide transport arm and the magazine "clicks" into
place.
Slide Transport Arm
Universal Magazine
Slide order numbers printed on top of magazine on
the right hand side of magazine towards the front of
the scanner when loading.
Slide tray h older area
Universal "DIN 108" Tray
8
