Page 1: User Manual
Ref.: SCAN500RGB/SCAN1100RGB/SCAN2000RGB/SCAN1100PINK USER MANUAL MODE D’EMPLOI Imported from China by LOTRONIC SA – Avenue Zénobe Gramme 9 – 1480 Saintes - Belgium ©Copyright Lotronic 2017... - Page 2 LASER FOR PROFESSIONAL USE ONLY This laser complies with the international standards EN60825-1:2014. It is meant exclusively for professional use. Its installation and use should only be carried out by a skilled technician who is aware of the specific dangers of lasers. REMINDER OF SAFETY INSTRUCTIONS Lasers of class 3 and 4 are for outdoor use only.
- Page 3 Transverse Beam Mode Cooling TEC & Fan Cooling Scanning High speed scanner 25kpps Laser Power : SCAN500RGB : 100mW-G-532nm+200mW-R-650nm+200mW-B-445nm SCAN1100RGB: 200mW-G-532nm+300mW-R-638nm+600mW-B-445nm SCAN2000 RGB: 500mW-G-532nm+500mW-R-638nm+1000mW-B-445nm SCAN1100PINK: 500mW-R-638nm+600mW-B-445nm Specification: Mains Input: ..................AC100~240V, 50/60Hz, total 30W Fuse: ....................250V 2A slow blow (20mm glass) Menu mode: ..........
- Page 4 4. Turn on all units' power, the units begins reset, then the unit begins working. 5. Use DMX console to control your units. Operating introduction： 1. Built-in performance programs, AUTO, SOUND 2. DMX mode 3. Master/Slave 4. ILDA DB25 mode 5.
- Page 5 side of the display. You are now in the setting menu. Select the sequence by selecting SE and press ENTER. This sub-menu also allows to (not recommended for beginners!) Configure motors X & Y via dr – X and dr – Y •...
- Page 6 >2:Professional DMX mode: 34 channels Order 1: Professional DMX mode is available to the experienced lighting engineers, who are professional in DMX control, as well as the laser pattern scanning principle , if not, pls use simple DMX mode 4 channels Order 2: DQF6 (the Bluetooth number) is a double-pattern laser system, and two patterns can be scanned at the same time.
- Page 7 128-159 Horizontal 3 160-191 Horizontal 4 192-223 Horizontal 5 224-255 Horizontal 6 0-63 Manual moving 64-95 vertical 1 96-127 vertical 2 128-159 vertical 3 Vertical moving 160-191 vertical 4 192-223 vertical 5 224-255 vertical 6 0-63 Manual X zooming 64-95 X zooming 1 96-127 X zooming 2...
- Page 8 The auxiliary function of the drawing 64-127/160- The moving time of the pattern drawing gradually control (used in conjunction with 191(CH15) CH15) 192-255 The number of nodes that are drawn 0-31 Forward hand-drawn gradually 32-63 Reverse manual drawing 64-95 Extended drawing CH15 Progressive control 96-127...
-
Page 9: Vertical Moving
64-95 Zooming3 96-127 Zooming4 128-159 Zooming 5 160-191 Zooming 6 192-223 Zooming 7 224-255 Zooming8 0-63 Manual rotating 64-95 Rotating 1 96-127 Rotating 2 CH23 128-159 Rotating 3 Patterns rotating 160-191 Rotating 4 192-223 Rotating 5 224-255 Rotating 6 0-63 Manual moving 64-95 Horizontal 1... - Page 10 32-39 blueviolut 40-47 blue 48-55 purple 56-63 white 64-95 Red/green/blue discolor 96-127 Blueviolut/blue/purple discolor 128-159 7 colors discolor 160-191 RGB discolor 192-223 Positive walking color 224-255 Reverse walking color 0-63 Normal blanking control 64-127 Patterns without blanking,flyback line banking CH30 128-159 Patterns and line without blanking Node and blanking control...
- Page 11 LED display instruction: * {INTR}{DMX}{APP}{SET}{SND}{SEL} for status identification. - {INTR} Indicates that the fixture is using the built-in effect. When the status flag is lit (INTR} alone, it is the built-in effect play mode. - {DMX} indicates that the fixture is controlled by the DMX signal. The status flag is only bright (DMX) for the standard DMX control mode - {INTR} {DMX} is a simple DMX mode that calls the built-in scenario via DMX signals.
- Page 12 - In DMX or E- DMX mode, press this key to adjust the address code. - When setting mode, press this key to adjust the setting item. * [SET]key: - When the system is not in the set state, press 5 times to enter the system setting state. - When the system is in the setting state, press this key to exit the system setting state.
- Page 13 <3mm à la sortie Divergence (chaque rayon) <1.3 mrad Divergence (total) <1.3mrad Transverse Beam Mode Puissance des lasers Refroidissement TEC & ventilateur SCAN500RGB : 100mW-G-532nm+200mW-R- Balayage 650nm+200mW-B-445nm Scanner haute vitesse 25kpps SCAN1100RGB: 200mW-G-532nm+300mW-R- 638nm+600mW-B-445nm SCAN2000 RGB: 500mW-G-532nm+500mW-R-638nm+1000mW-B-445nm SCAN1100PINK: 500mW-R-638nm+600mW-B-445nm ©Copyright Lotronic 2017...
- Page 14 Caractéristiques techniques: Alimentation ......................AC100-240V, 50/60Hz Fusible ......................250V 2 A lent (verre 20mm) Modes: ............Auto, musique, DMX512, Master/slave, ILDA, télécommande Laser Classification: ........................Class 3B Laser Safety Standard: ....................EN60825-1:2014 Condition Temperature: ......................10℃~40℃ Canaux DMX ........................5 / 34 canaux Dimensions ........................
-
Page 15: Ch11
Mode DMX simplifié à 5 Canaux Note: Dans ce mode, les scenes intégrées sont utilisées telles quelles sont autre réglage. S CANAL Valeur DMX DESCRIPTION CH 1 On/off power 1-255 0-127 AUTO CH2 Act auto/sound 128-255 SOUND CONTROLLED 0-15 1 gallery (0) 16-31 2 gallery (16) Gallery Menu... -
Page 16: Force Segmentation Color
No zooming 1-31 Zooming 1 32-63 Zooming 2 64-95 Zooming3 96-127 Zooming4 Patterns zooming 128-159 Zooming 5 160-191 Zooming 6 192-223 Zooming 7 224-255 Zooming8 0-63 Manual rotating 64-95 Rotating 1 96-127 Rotating 2 128-159 Rotating 3 Patterns rotating 160-191 Rotating 4 192-223 Rotating 5... - Page 17 Patterns discolor 8-15 16-23 yellow 24-31 green 32-39 blueviolet 40-47 blue 48-55 purple 56-63 white 64-95 Red/green/blue discolor 96-127 Blueviolut/blue/purple discolor 128-159 7 colors discolor 160-191 RGB discolor 192-223 Positive walking color 224-255 Reverse walking color 0-63 Normal blanking control CH13 64-127 Patterns without blanking,flyback line banking...
- Page 18 Pattern A closed light, pattern B output light 0-49 Out of bounds 50-99 Reentry CH19 Out of bounds and pattern size 100-149 blanking 150-255 retain the smaller the value of the segment, the larger the 0-99 angular distribution of each unit, the gap is a positive CH20 The distribution angle of each unit of the the smaller the value of the segment, the larger the...
-
Page 19: Force Segmentation Color
Horizontal zooming 96-127 X zooming 2 128-159 X zooming 3 160-191 X zooming 4 192-223 X zooming 5 224-255 X zooming 6 0-63 Manual Y zooming 64-95 Y zooming 1 96-127 Y zooming 2 CH27 128-159 Y zooming 3 Y axis vertical zooming 160-191 Y zooming 4 192-223... -
Page 20: Copyright Lotronic
224-255 Turn over drawing 0-255, the greater the value, the smaller the distortion. CH33 Auxiliary control of twist [Note: CH33 can control the degree of twist of the twist 0-255 deformation effect channel effect when zooming, rotating, moving, and twisting effects] (0-19),(20-39)..(220-239) , (240-239),(240-255) CH34...
