24 | Service Guide for DS460C, DS224C and DS212C Disk Shelves
1 Orange ring on the vertical bracket
b. Disconnect the vertical connector (connected to the midplane) by gently pressing on the center
of the orange ring and pulling the left side of the cable out of the enclosure.
c. To unplug the cable chain, carefully pull your finger toward you approximately 1 inch (2.5
cm), but leave the cable chain connector within the vertical bracket.
6. Follow these steps to disconnect the other end of the cable chain:
a. Using a flashlight, locate the orange ring on the end of the cable chain that is attached to the
horizontal bracket in the enclosure.
The figure shows the horizontal connector on the right and the cable chain disconnected and
partially pulled out on the left side.
