1 Cable chain
2 Vertical connector (connected to the midplane)
3 Horizontal connector (connected to the drive drawer)
The top cable chain is attached to drive drawer 1. The bottom cable chain is attached to drive
drawer 5.
4. Use your finger to move the cable chain on the right side to the left.
5. Follow these steps to disconnect any of the right cable chains from its corresponding vertical
bracket.
a. Using a flashlight, locate the orange ring on the end of the cable chain that is connected to the
vertical bracket in the enclosure.
