- Page 1 Technical Manual MONOBOX-400 Page - Copyright Llaza, S.A. - May 2011...
-
Page 2: Table Of Contents
MONOBOX-400 Contents Descriptive specifications Cutting, selection, and classification tables Annotated cross-sectional diagrams Assembly instructions 9-16 Installation instructions 17-19 Page 2 - Copyright Llaza, S.A. - May 2011... -
Page 3: Descriptive Specifications
Descriptive specifications 1. GENERAL CHARACTERISTICS The MONOBOX-400 awning brings together a series of innovative characteristics that make it stand out from other conventional systems. The articulated arm system, in conjunction with its other clearly unique characteristics, adds value to result in a top-of-the-line end product that responds to the needs of today’s professionals in the architecture and... -
Page 4: Projection
To address these factors, the materials chosen in the manufacture of this product have taken on vital im- portance. 3. DESCRIPTION OF THE PARTS THAT MAKE UP THE MONOBOX-400 The square bar that suspends the system is made of extruded aluminium and can allow for projections of 3 metres or even more by placing a 35x35x2 steel pipe inside the bar. -
Page 5: Descriptive Specifications
Aluminium Weather cover Extrusion Aluminium Extrusion Aluminium Front drop bar Extrusion comp. Extrusion Aluminium SPLENDOR model arms Components Pressure moulding Aluminium Front alum. profile Extrusion Aluminium Rear alum. profile Extrusion Aluminium Page 5 - Copyright Llaza, S.A. - May 2011... -
Page 6: Cutting, Selection, And Classification Tables
3.00 3.25 3.50 MOTOR SELECTION TABLE (in Nw/m) PROJECTION 1.75 2.25 2.50 2.75 3.25 3.50 70 Ø ROLLING TUBE 2 arms 80 Ø ROLLING TUBE 2 arms 3 arms 4 arms Page 6 - Copyright Llaza, S.A. - May 2011... - Page 7 If the outermost arm brackets are more than 500 millimetres from the end of the awning, an additional wall or ceiling bracket must be placed at each end of the awning to prevent torsion on the square bar. Page 7 - Copyright Llaza, S.A. - May 2011...
-
Page 8: Annotated Cross-Sectional Diagrams
MONOBOX-400 ANNOTATED CROSS-SECTIONAL DIAGRAMS FACE MOUNTING CEILING MOUNTING WALL BRACKET CEILING BRACKET Page 8 - Copyright Llaza, S.A. - May 2011... -
Page 9: Assembly Instructions
After this step has been performed (and not before), firmly tighten the bolt as done with the bracket on the other side. Page 9 - Copyright Llaza, S.A. - May 2011... - Page 10 Do not roll up all of the fabric; leave enough to be able to later place the front drop bar on the free end of the fabric. Page 10 - Copyright Llaza, S.A. - May 2011...
- Page 11 Once this has been ensured, place the arm on the bracket and insert the pin (L), so that it passes through the ring in the cam piece (I). Page 11 - Copyright Llaza, S.A. - May 2011...
- Page 12 (B). Remember to attach the rubber strip to the front of this profile, which cushions the closing of the cas- sette. Page 12 - Copyright Llaza, S.A. - May 2011...
- Page 13 (Q), which were previously inserted into the drop bar profile. After inserting the Mikalor threaded plates in the groove, attach the aluminium side caps to the front drop bar profile. Page 13 - Copyright Llaza, S.A. - May 2011...
-
Page 14: Projection
Attach the joint-guard clip at the location where the arm joint meets the profile. These steps will make the MONOBOX-400 easier to close and prevent rubbing or damage to the lacquer finish. Thanks to attachment plate (C), which was inserted into... - Page 15 (A). Insert the other square bar into the centre bracket, and hold it in position using the stud and the previously positioned nut. Page 15 - Copyright Llaza, S.A. - May 2011...
- Page 16 Page 16 - Copyright Llaza, S.A. - May 2011...
-
Page 17: Installation Instructions
From the interior of the bracket, insert the bolt and screw it directly into the threads on the cover. Page 17 - Copyright Llaza, S.A. - May 2011... - Page 18 The recommended measurement for the fabric to cover the gap between the two awnings is 600 milli- metres in width, and it must be manufactured with- out side seams. Page 18 - Copyright Llaza, S.A. - May 2011...
- Page 19 When performing this adjustment, it is important to alternate screwing in the bolts for each bracket, so that the MONOBOX-400 unit does not tilt too far in the horizontal direction. IMPORTANT The cam system to lock inclination is only activated during the final one-third of the opening of the awning.
- Page 20 LLAZA WORLD, S.A. - Tramuntana, 1 - Polígono Ind. Roques Roges (P.O. Box 11) - 43460 - ALCOVER Tel. +34 977 990 600 - Fax +34 977 990 610 info@llaza.com - export@llaza.com www.llaza.com Page 20 - Copyright Llaza, S.A. - May 2011...
