SOREX FLEX Instruction Manual

This document is addressed to users of the SOREX FLEX -
product.
Product properties
3xAAA Batteries
Voltage supply
-40°C–80°C
Operating temp.
10 keypad codes &
User memory
20 RFID devices
Lifetime Keypad 10 mil. operations
1 year
Lifetime Battery
Weight 500g
Outside: 40 mm
Minimum length
Inside: 30 mm
Outside: 60 mm
Maximum length
Inside:65 mm
Items delivered
Qty. Name
SOREX FLEX
1
digital cylinder
1 Screwdriver
Product description
V1.0
21.04.2017
SOREX FLEX - Keypad & RFID cylinder
Instruction manual
Keypad & RFID
Installation of battery
1. Remove locating screw from outer
knob.
2. Remove
housing for the batteries. Insert 3 x
AAA batteries.
reassembled in reversed order.
Adjusting the outer knob
1. Open
described above.
2. Remove screw in the middle of the
battery housing.
3. Fit the outer knob on the spindle at
your desired position. The cylinder is
reassembled in reversed order.
Installation
1. Remove screw on inner knob.
2. Remove inner knob.
3. Insert cylinder into the lock. The
position of the cylinder in the lock is
correct when the latch can be
operated via the spindle of the
cylinder.
Wir möchten Ihnen Türen öffnen
cylinder, and helps them with the initial installation and usage of the
sleeve and open the
The cylinder is
the battery housing as
4. Fixate cylinder in the lock with a
centering screw.
5. Fit the inner knob on the spindle at
your desired position.
Operation
Note: There can be up to 10 codes and 20
RFID devices linked to the digital cylinder.
There can only be one administrator code.
Note: Keypad codes have to be at least 6
digits long.
Note: Before an administrator code has
been configured, the cylinder is in delivery
condition. While in delivery condition, it is
always possible to cause an opening
action with the combination 123456 or
any RFID medium.
1. Configure administrator code
Note: The cylinder has to be in delivery
condition, before an administrator code
can be configured

Press any key on the keypad. The
keypad lights up.

Press the key and enter the
combination 123456. Confirm your
entry with . The keypad flashes
seven times.
