- Page 1 Machine Translated by Google SOREX FLEX Comfort Instruction Manual / User Manual...
- Page 2 Machine Translated by Google imprint Version 1.0 © Copyright: April 2022 SOREX wireless Solutions GmbH Technology and Research Center WN Viktor-Kaplan-Strasse 2B A-2700 Wiener Neustadt Austria T +43 2622 320130 F +43 2622 3201315 @ office@sorex.eu w³ www.sorex.eu...
-
Page 3: Table Of Contents
Machine Translated by Google Table of Contents 1. Scope of delivery ............................1 2. Step by step installation..........................2 2.1. Cylinder structure............................2 2.2. Insert battery............................3 2.3. Removing/adjusting the inside knob of the cylinder............... 3 2.4. -
Page 4: Scope Of Delivery
Machine Translated by Google German 1. Scope of delivery The package includes: SOREX FLEX Comfort cylinder 2 x emergency keys 1 x Allen key to adjust cylinder length on the inside 1 x ½AA battery 2x covers for PZ hole... - Page 5 Machine Translated by Google German 2. Step by step assembly 2.1. cylinder construction View from above: Fingerprint & RFID sensor centering screw inside knob Front view (without plastic cap) battery compartment "+" pole first emergency key...
-
Page 6: Battery
Machine Translated by Google German 2.2. Insert battery First, remove the plastic cap the outside knob and unscrew the battery compartment cover . You can now insert the battery. You can then close the battery compartment again and screw the cover back on . Here the battery contact closed, the cylinder lights up blue and plays an acoustic signal . -
Page 7: From The Outside
German 2.4.1. From the outside First remove the inside knob of the cylinder. Now you can slide the SOREX FLEX Comfort cylinder into the lock case from the outside inwards. Make sure the side with the fingerprint sensor is on the outside of the door. -
Page 8: From The Inside
Machine Translated by Google German 2.4.2. From inside To do this, you must first loosen the outer knob from the cylinder by gently pulling it, while pressing down the lock (marked in red) on both sides . Now you can insert the cylinder (without the outside knob) through the lock case from the inside and fasten using the centering screw (see 2.4.1.). -
Page 9: Smartphone App
Sign up with your email address or phone number. This is • Search for the “SOREX SmartLock” important so that you can access the SOREX app in the Google Play Store or Apple FLEX Comfort cylinder if you lose your Store . -
Page 10: Initial Setup
Machine Translated by Google German • It will now close after 3.3. initial setup located locks searched. • Open the app and first press on the top left of the Please press the found lock. main page . Press in the menu that opens Please click on "Add lock". -
Page 11: Functions
Machine Translated by Google German Caution: First of all , you should definitely set the opening direction correctly. You can find this setting under 3.4. functions "Settings -> Door opening direction". 3.4.1. Opening via Bluetooth Here , select the same direction you would •... -
Page 12: Invite Users
Machine Translated by Google German • You always have to do this 3.4.2. invite user • To invite users to the app, please press on the first Specify recipient account (phone number or email) and name. Start page on "Send eKey". In addition, you can add more Specify information such as the period of time in which the access should be valid. -
Page 13: Fingerprint
Machine Translated by Google German 3.4.4. Learn fingerprint • First press on the home page Click on "Fingerprints" and then and "Add fingerprint". Now you can enter a name and choose whether the user has permanent or temporary access. 3.4.5. Delete fingerprint •... -
Page 14: Teach In Rfid Medium
Machine Translated by Google German • If your smartphone supports NFC and you 3.4.6. Teach RFID medium have your door lock with one Gateway is connected, the item "Add card remotely " also appears below "Add medium ". This option also allows you to add RFID media remotely if needed. -
Page 15: Read Logs
Machine Translated by Google German "Settings". Now select “Transfer the lock” 3.4.8. Read logs and choose that • Press to read the logs Home page desired lock. About the button "Records". "Move to Trash", you can now delete the device. Confirm with your account password. Important: Only erase the device this way if you no longer have access to the physical device. -
Page 16: Gateways
Machine Translated by Google German 3.5. Gateway 3.5.2. Add Gateway (available seperately) • From the main page, press first 3.5.1. Prepare lock on the top left. in the opening • You must first enable remote opening for your lock. menu, please press "Gateway". In the subsequent window, press to press For this first... - Page 17 Machine Translated by Google German are within the Bluetooth range of the locks (up to • Make sure the light on the gateway is flashing blue and red alternately. You can achieve this by doing 10m - this from depending on local conditions). Are locks further Disconnect the gateway from the power supply apart and you would like and plug it in again.
- Page 18 Bluetooth range limited. 4. Factory reset Around the SOREX FLEX Comfort Cylinder reset it, you have to delete it from the app (select cylinder -> Settings -> "Delete"). You must be close to the cylinder during...
- Page 19 Machine Translated by Google imprint Version 1.0 © Copyright: April 2022 SOREX wireless Solutions GmbH Technology and Research Center WN Viktor-Kaplan-Strasse 2B A-2700 Wiener Neustadt Austria T +43 2622 320130 F +43 2622 3201315 @ office@sorex.eu w³ www.sorex.eu...
- Page 20 Machine Translated by Google © 2022 SOREX Wireless Solutions...
