Modular Fire Panel

FPA-5000

System Information

Table of Contents

Summary of Contents for Bosch FPA-5000

Page 1 Modular Fire Panel FPA-5000 System Information...
Page 3: Table Of Contents
Product Description FPA-5000 with Functional Modules MPC Panel Controller Remote Keypad Housings for Frame Installation Housings for Wall Mounting System Overview of FPA-5000 with Peripherals Networking Connection to BIS Connecting a Voice Alarm System Planning General Information Structures in Local Security Network...
Page 4 Testing the Addressing/Activation Maintenance and Service Warranty Repair Disposal Additional Documentation Technical Data System Limits Power loss of FPA-5000 Components Housing and Accessories 7.3.1 Housings for Frame Installation 7.3.2 Housings for Wall Mounting 7.3.3 PRS-0002-C Panel Rail Short for 2 Modules 7.3.4...
Page 5 Power Supply Units, Power Supply Brackets, Batteries 8.2.6 Panel Controller/Remote Keypad 8.2.7 Functional Modules 8.2.8 Cable Sets 8.2.9 Thermal Printer 8.2.10 CAN/FOC Adapters Special Applications 8.3.1 Controlling Extinguishing Systems Index Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 6: System Information
Consider national and local regulations when installling and operating the fire system. Product Description With its modular design, the FPA-5000 Fire Panel is easily adapted to local circumstances and regulations. Due to the different functional modules, country-specific characteristics are accommodated in the connection just as quickly as the respective alarm protocol.
Page 7 CAN bus interface. With a loop or bus structure, this networking is adapted to the conditions of use (see Networking, page 23). The FPA-5000 can be connected to the Bosch UGM Universal Security System and thus integrated into large-scale systems.
Page 8 IN 3 A U X 4 O U T 4 IN 4 F B 1 F B 2 Figure 2.2: Example configuration Position Description Position Description Functional modules Power supply unit 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 9 Due to its modular structure, the FPA‑5000 Modular Fire Panel provides complete flexibility and thus customized solutions for any application. The configuration of the components is supported by Planning Software by Bosch for fire alarm systems. The software provides information about the size and number of housings, the modules and the energy balance calculation.
Page 10 The technical data can be found in Housing and Accessories, page 146. Notice! Planning Software by Bosch can be used to plan fire alarm systems that conform to the relevant limits (e.g. in terms of cable length and power supply).
Page 11: Mpc Panel Controller
Product Description | en Notice! Planning Software by Bosch for fire alarm systems enables the system dimensions, the energy requirements and the quantity and prices of the elements required to be estimated at each different phase in the planning process.
Page 12: Remote Keypad
Power can be supplied by the panel or an external power supply unit such as the FPP-5000. The easy-to-install housing was designed for tilted installation and for surface or flush wall mounting. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 13: Housings For Frame Installation
The mounting frames are screwed to the wall surface and hold the pre-cabling. Alternatively to surface mounting, installation in 482.6 mm (19") racks is also possible using special installation kits. 12 V/45 Ah batteries can be used in the frame installation housing. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 14 For the FMH 0000 A, the FPO‑5000‑EB Earth Bar can be ordered as an extension if required. – For continuous installation in combination, all mounting frames have T-shaped guide rails on the base and T-shaped grooves on the top. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 15 MPH 0010 A FRB 0019 A EPH 0012 A FRB 0019 A PSF 0002 A FRB 0019 A PMF 0004 A FRM 0019 A USF 0000 A FRS 0019 A Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 16: Housings For Wall Mounting
Two wall mounting housings are available as a base unit: – HCP 0006 A (for 6 modules), and – HBC 0010 A (for 10 modules) These housings can accommodate an MPC Panel Controller with operating and display unit as the central element. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 17 The housings can also be equipped with transparent front doors. The doors are made of impact-resistant plastic and are available in two sizes (each with a lock on the left or right). Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 18: System Overview Of Fpa-5000 With Peripherals
FDT 0001 A The technical data for the housings can be found in Housings for Wall Mounting, page 146. System Overview of FPA-5000 with Peripherals The following figure shows a typical fire detection system design using an FPA-5000 Fire Panel. LSN improved/classic Figure 2.7: System overview of FPA-5000 with peripherals...
Page 19 FLM-420/4‑CON Conventional Interface Module can be found in the relevant compatibility lists: Module/interface module Compatibility list CZM 0004 A F.01U.164.327 FLM-420/4‑CON F.01U.079.455 The current versions of the compatibility lists are available on the Internet (see Additional Documentation, page 143). Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 20 ADW 511A • N4387A • • Infrared flame detectors DF1192 • DF1101A-Ex • 016519 • • 016589 • • Duct smoke detectors FAD-420-HS-EN • • 1) Connection via DCA1192/SB3 only 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 21 ROLP-W-LX/ROLP- • R-LX FNM-420-A/-B/-A- • • FNM-420U-A • • FNM-420V-A • • DS 10 • HPW 11 • Visual notification appliances FNS-320 • FNS-P400RTH • FNS-420-R • • SOL-LX • Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 22 IOS 0020 A + MPC FMF-ADP-TTY – FPE-5000-UGM – IOS 0020 A FMF-FAT/FMF-FBF-FAT FMF-ADP-TTY FMF-FIBS-A4/FMF-FIBS-A3 FMF-ADP-TTY FMF-ESPA – FMF-ADP-TTY – FMF-FAT/FMF-FBF-FAT – FMF-FIBS-A4/FMF-FIBS-A3 2) Included in the scope of delivery of the FAT 2002 RE 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 23: Networking
(e.g. there must be no technical interference due to differences in grounding potential) – whether the bus users are designed for this kind of network (e.g. sufficient bandwidth). Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 24: Connecting A Voice Alarm System
Connecting a Voice Alarm System The Praesideo/PAVIRO or Plena voice alarm system can be connected via a data transmission line to the FPA-5000 system. This enables the FPA-5000 to control voice alarm zones. The control can be defined down to the individual detector level.
Page 25: Structures In Local Security Network
Terminating each stub and each T-tap with EOL modules is essential to set up a complete fire alarm system complying with EN 54-13. – Conventional detectors approved for the FPA-5000 can be connected using one of the following methods: –...
Page 26 When configuring the detectors, it is essential to ensure that no mesh structures are created. FPA-5000 FPA-5000 Mesh structures within a stub structure Mesh structures within a loop structure Table 3.2: Unusable network structures 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 27: Detection Points
The following settings are possible: Rotary switch setting Address Operating mode 0 0 0 Loop/stub in LSN improved version mode with automatic addressing (T-tapping not possible) = factory default setting Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 28: Achievable Cable Length With Lsn 0300 A
The possible cable length can be estimated using the formula below. This formula is also used in the Planning Software by Bosch for fire alarm systems and is based on the critical application situation where all network elements are concentrated at the end of the bus line.
Page 29 Remote indicators activated by the detector C point: A maximum additional cable length of 500 m is allowed when using remote indicators (e.g. FAA-420-RI-DIN/FAA-420-RI-ROW). The total length of installed cable must not exceed the limit of 1600 m. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 30 Figure 3.1: Diagram for determining the maximum achievable cable length: LSN classic elements with LSN 0300 A cable length in meters number of LSN classic elements 1600 m limit 300 mA limit maximum possible number of LSN classic elements = 127 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 31: Achievable Cable Length With Lsn 1500 A
This formula is also used in the Planning Software by Bosch for fire alarm systems and is based on the critical application situation where all network elements are concentrated at the end of the bus line. The calculated cable lengths are therefore on the conservative side.
Page 32 Remote indicators activated by the detector C point: A maximum additional cable length of 500 m is allowed when using remote indicators (e.g. FAA-420-RI-DIN/FAA-420-RI-ROW). The total length of installed cable must not exceed the limit of 3000 m. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 33 Figure 3.3: Diagram for determining the maximum achievable cable length: LSN classic elements with LSN 1500 A cable length in meters number of LSN classic elements 3000 m limit maximum possible number of LSN classic elements = 127 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 34 Figure 3.4: Diagram for determining the maximum achievable cable length: LSN improved elements with LSN 1500 A cable length in meters number of LSN improved elements Bus dynamic limit maximum possible number of LSN improved elements = 254 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 35: Examples Of Housing Equipment
FBH 0000 A / FHS 0000 A HMP 0003 A 12 V / 45 Ah 12 V / 45Ah Figure 3.5: Example of configuration with CPH 0006 A frame installation housing for 6 modules Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 36: Configuration Of Bcm Battery Controller Module
Notes – The 24 V switch outputs may not be connected in parallel. – The total current for all connected components including the battery charge current may not exceed 6 A. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 37 Configuration with One to Four BCM Modules in Frame Installation Housings – Up to 2 BCM-0000-B modules on short panel rail – Maximum 2 BCM-0000-B modules at the end of the last long panel rail Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 38 2 BCM-0000-B modules at the end of the long panel rail – The remaining BCM-0000-B modules on a panel rail in the center of the system. – Each BCM-0000-B module requires one UPS 2416 A Universal Power Supply. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 39 The current load on a panel rail may not exceed the maximum value of 12 A. The current load via a panel rail plug may not exceed the maximum value of 10 A. Figure 3.10: Area 1 Figure 3.11: Area 2 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 40: Redundancy
Redundant panel controller – Redundant connection to a Bosch UGM – Redundant connection of the transmission device or AT3000, see the FPA-5000/ FPA-1200 wiring guide (document number F.01U.009.201) – Activation of extinguishing systems in accordance with VdS 2496: If a signal processing unit fails, no more than one extinguishing area may fail.
Page 41 CPH 0006 A or Redundant panel housing, additionally installed PRD 0004 A MPH 0010 A Panel Rail Long (1 x in the CPH 0006 A or 2 x in the MPH 0010 A ) may be fitted with modules. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 42: Installation
– The fire panel may only be installed and commissioned by trained specialist personnel. – Only use installation materials recommended by BOSCH Security Systems. Otherwise, interference resistance cannot be guaranteed. – Connection conditions set down by the regional authorities and institutions (police, fire service) must be observed.
Page 43: Quick Installation Guide
Building Management System – If connected to a building management system (Bosch Building Integration System BIS) via an Ethernet interface using an OPC server, the following must be noted: In a multi-building network, it is essential to clarify with the network administrator whether the network is designed for multi-building connections (e.g.
Page 44: Installation Of Housing Components
At the marked points, drill holes approx. 55 mm deep with an 8-mm drill. Insert a dowel in each hole. Refit the FSH 0000 A Mounting Frame, as described in step 1. Screw the FSH 0000 A Mounting Frame tight. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 45: Installation Instructions For Housing
Wall mounting extension housing for 12 modules 4.998.153.996 PSB 0004 A Wall mounting power supply housing 4.998.154.010 PSS 0002 A Wall mounting power supply housing 4.998.154.009 DIB 0000 A Distribution box F.01U.003.105 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 46 FDT 0001 A Front door, transparent, large, lock right side F.01U.003.100 FDT 0002 A Front door, transparent, large, lock left side F.01U.003.104 FDT 0003 A Front door, transparent, lock left side F.01U.003.102 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 47: Installation Dimensions For Wall Mounting Housing
Modular Fire Panel Installation | en 4.3.2 Installation Dimensions for Wall Mounting Housing HCP 0006 A Modular Panel Housing for 6 Modules 12,5 Figure 4.1: Housing: Installation dimensions - HCP 0006 A [in mm] Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 48 | Installation Modular Fire Panel HBC 0010 A Modular Panel Housing for 10 Modules 12,5 Figure 4.2: Installation dimensions - HBC 0010 A [in mm] 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 49 Modular Fire Panel Installation | en HBE 0012 A Modular Extension Housing for 12 Modules 12,5 Figure 4.3: Installation dimensions - HBE 0012 A [in mm] Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 50 | Installation Modular Fire Panel PSB 0004 A Power Supply Module, Wall Mounting 12,5 Figure 4.4: Installation dimensions - PSB 0004 A [in mm] 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 51 Carefully punch out the pre-punched hole for the cable entry and fit a suitable cable grommet. When inserting the cable into the housing, pierce a hole in the grommet with a pointed object, do not cut. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 52 | Installation Modular Fire Panel HCP 0006 A HBC 0010 A HBE 0012 A PSB 0004 A PSS 0002 A Figure 4.6: Wall mounting housing cable bushings 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 53: Installation Dimensions For Frame Installation Housing
Installation Dimensions for Frame Installation Housing Installation Dimensions for CPH 0006 A, EPH 0012 A and MPH 0010 A with FBH 0000 A or FHS 0000 A Mounting Frames 15,5 452,5 455,5 Figure 4.7: Housing:Installation dimensionsInstallation dimensions for CPH 0006 A, EPH 0012 A and MPH 0010 A [in mm] Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 54 | Installation Modular Fire Panel Installation Dimensions for PMF 0004 A with FMH 0000 A Mounting Frame 15,5 452,5 455,5 Figure 4.8: Installation dimensions for PMF 0004 A [in mm] 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 55 Modular Fire Panel Installation | en Installation Dimensions for PSF 0002 A and USF 0000 A with FSH 0000 A Mounting frame 15,5 452,5 455,5 Figure 4.9: Installation dimensions for PSF 0002 A and USF 0000 A [in mm] Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 56: Installation Dimensions For Mounting Frames
| Installation Modular Fire Panel 4.3.4 Installation Dimensions for Mounting Frames FBH 0000 A/FHS 0000 A Mounting Frame Large 290 ± 0,5 Figure 4.10: Mounting frame:Installation dimensionsInstallation dimensions - FBH 0000 A/FHS 0000 A [in mm] 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 57 Modular Fire Panel Installation | en FMH 0000 A Mounting Frame Medium 290 ± 0,5 Figure 4.11: Installation dimensions - FMH 0000 A [in mm] Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 58 | Installation Modular Fire Panel FSH 0000 A Mounting Frame Small 290 ± 0,5 Figure 4.12: Installation dimensions - FSH 0000 A [in mm] 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 59: Installation Kits For 48 Cm (19") Racks
PMF 0004 A FRM 0019 A PSF 0002 A FRS 0019 A USF 0000 A FRS 0019 A No mounting frame is required when using the 48 cm (19'') installation kits. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 60 FRS 0019 A PSF 0002 A, USF 0000 A 267 x 449 x 233.5 mm FRB 0019 A Rack Installation Kit, Large Figure 4.14: FRB 0019 A installation kit for CPH 0006 A, MPH 0010 A, EPH 0012 A [installation dimensions in mm] 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 61: Accessories For Housing
Junction boards receive the cables coming from outside and allow clear onward transmission to the individual modules. The RLE 0000 A Junction Board is also required to connect the AT3000 transmission unit. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 62 | Installation Modular Fire Panel RLE 0000 A M3 x 10 Figure 4.17: RLE 0000 A installation 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 63: Hmp 0003 A Mounting Plate For Mounting Frame
The mounting plate is required to install interface modules, external device controllers, relays and other components. It can be fitted with a distributor rail. Notice! The distributor rail is not included in the scope of delivery for the HMP 0003 A Mounting Plate. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 64 | Installation Modular Fire Panel Figure 4.19: HMP 0003 A installation 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 65: Fpo-5000-Eb Earth Bar
Position the temperature sensor between the batteries. Power supply brackets are available in the FPO‑5000‑PSB‑CH (see FPO‑5000‑PSB‑CH Power Supply Bracket, page 67) and FPO‑5000‑PSB1 (see FPO-5000-PSB1 Power Supply Bracket, page 71) versions. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 66 Notice! A maximum of one power supply bracket and one power supply can be installed in the power supply housing. M4 x 12 mm Figure 4.21: FPO‑5000‑PSB‑CH/FPO‑5000‑PSB1 installation (1-4) 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 67: Fpo-5000-Psb-Ch Power Supply Bracket
Figure 4.22: FPO‑5000‑PSB‑CH Power Supply Bracket The FPO‑5000‑PSB‑CH Power Supply Bracket is used in the HCP 0006 A, HBC 0010 A and HBE 0012 A wall mounting housings. The technical data can be found in FPO‑5000‑PSB1/FPO‑5000‑PSB‑CH Power Supply Brackets, page 148. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 68 | Installation Modular Fire Panel HCP 0006 A HBC 0010 A HBE 0012 A Figure 4.23: FPO‑5000‑PSB‑CH housing compatibility and installation of temperature sensor 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 69 Modular Fire Panel Installation | en M4 x 12 mm Figure 4.24: FPO‑5000‑PSB‑CH installation (5-8) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 70 | Installation Modular Fire Panel 100 - 240 V AC 50 - 60 Hz T 10 A / 250 V L1 G Figure 4.25: FPO‑5000‑PSB‑CH installation (9) 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 71: Fpo-5000-Psb1 Power Supply Bracket
The FPO‑5000‑PSB1 Power Supply Bracket is used in the PSS 0002 A and PSB 0004 A power supply housings. It is installed in a central position between two batteries. The technical data can be found in FPO‑5000‑PSB1/FPO‑5000‑PSB‑CH Power Supply Brackets, page 148. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 72: Ups 2416 A Universal Power Supply 24 V/6 A
FPA‑5000 Fire Panel. It is inserted into a power supply bracket and is then ready to use immediately. The power supply unit is protected against pole reversal and overvoltage. A green LED on the power supply unit itself indicates that it is functioning. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 73 Figure 4.28: UPS 2416 A Universal Power Supply 24 V/6 A Pos. Labeling Connection 1 - 2 ACL | ACN Mains supply Protective ground 4 - 5 DC+ | DC- 26.76 V DC output plus/0 V DC output minus FAULT Mains fault output Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 74 HCP 0006 A, HBC 0010 A, HBE 0012 A Information on power supply brackets can be found in Power Supply Brackets, page 65. The technical data can be found in UPS 2416 A Universal Power Supply 24 V/6 A, page 148. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 75 U P S 2 4 1 6 A 24 V 24 V MAIN POWER MAIN POWER TROUBLE BATTERY 1 TROUBLE BATTERY 2 TROUBLE 24 V BCM-0000-B UPS 2416 A Figure 4.29: Installation of UPS 2416 A in FPO‑5000‑PSB1 (1) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 76 F P O - 5 0 0 0 - P S B 1 Figure 4.30: Installation of UPS 2416 A in FPO‑5000‑PSB1 (2-5) Notice! Only one power supply unit can be installed in the FPO-5000-PSB‑CH Power Supply Bracket (see figure). 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 77 Figure 4.31: Installation of UPS 2416 A in FPO-5000‑PSB‑CH (1-4) Notice! Each power supply unit and each housing comes with a self-adhesive product label. Attach the sticker to the outside of the housing (see figure). Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 78: Panel Rails
PRS-0002-C Panel Rail Short is intended for installation of the following modules without operating and display elements: – BCM-0000-B Battery Controller Module – IOS 0020 A and IOS 0232 A Communication Modules 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 79 Modular Fire Panel Installation | en CANH CANL +24V PRD 0004 A Figure 4.33: PRS-0002-C connections The technical data can be found in PRS-0002-C Panel Rail Short for 2 Modules, page 146. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 80: Prd 0004 A Panel Rail Long For 4 Modules
The technical data can be found in PRD 0004 A Panel Rail Long for 4 Modules, page 147. A line terminator (RE) has to be plugged at the open end of the last rail. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 81: Panel Rail Installation
Modular Fire Panel Installation | en 4.7.3 Panel Rail Installation Short rail installation CPH 0006 A MPH 0010 A HCP 0006 A HBC 0010 A Figure 4.35: PRS-0002-C installation Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 82 | Installation Modular Fire Panel Figure 4.36: Connection of panel rail 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 83 Modular Fire Panel Installation | en Long rail installation CPH 0006 A MPH 0010 A EPH 0012 A HCP 0006 A HBC 0010 A HBE 0012 A Figure 4.37: PRD 0004 A installation Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 84: Mpc Panel Controller
| Installation Modular Fire Panel Figure 4.38: Connection of panel rail MPC Panel Controller The panel controller with the operating and display unit is the central element of the fire detection system. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 85 The technical data can be found in MPC, page 148. Figure 4.39: Scope of delivery for MPC Functional Description The panel controller controls all components in the system and has the following functional elements Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 86 2 Ethernet interfaces (ETH1/ETH2) für Vernetzung – 2 signal inputs (IN1/IN2) – 1 USB and 1 RS232 interface Note the maximum cable length of 2 m for connection to the USB and RS232 interface. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 87 FSM-5000-OPC-Server manual. USB Device RS232 max. 3 m max. 3 m Figure 4.41: MPC, USB and RS232 interfaces Ethernet Server 100BaseTX FPA-5000 FPA-1200 Figure 4.42: MPC connection to BIS via OPC server Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 88 Caution: Connection at the OUT slot or to a Panel Rail Long is not permissible. – Plug the terminal element for the data bus into the OUT slot on the last occupied panel rail (8). 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 89 Modular Fire Panel Installation | en PRS-0002-C Figure 4.43: MPC installation (1-3) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 90 | Installation Modular Fire Panel PRS-0002-C PRD-0004-A Figure 4.44: MPC installation (4-6) 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 91 Modular Fire Panel Installation | en Figure 4.45: MPC installation (7-9) Address Cards ADC xxxx A Address cards are used to specify the number of possible detection points. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 92 Each module, each monitored module input and each LSN element occupies a detection point (an address). – An FPA-5000 can manage up to 4096 addresses. A detailed explanation of addresses and detection points can be found starting on Detection Points, page 27.
Page 93 The ADC‑5000‑OPC License Key is a special address card that enables communication between an OPC server and an FPA-5000 Modular Fire Panel. The fire panels FPA-1200 or FPA-5000 can be connected to the Fire Monitoring System FSM-2500 or FSM-5000 via an Ethernet connection. The connection must be enabled with an ADC‑5000‑OPC License Key.
Page 94 The address cards can be in any order in a panel. ADC‑5000‑VA Licence Key The ADC‑5000‑VA enables the IP Ethernet data interaction between the FPA-5000/FPA-1200 fire panel and the Praesideo/PAVIRO voice alarm system. The activation of all programmed voice zones is realized by only one data connection without additional devices.
Page 95 Note the address on the sign below the rotary switches (see , step 2). The DIP switches are located on the rear of the panel controller (see ). Mark the selected setting on the sign above the DIP switches (see , step 4). Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 96 Redundant panels must have identical addresses. Notice! You will find detailed information about the CAN and Ethernet networking of the panels in the Networking Guide available for download at www.boschsecurity.com. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 97 Modular Fire Panel Installation | en Addressing and Configuration of MPC Panel Controller Figure 4.49: MPC Panel Controller, addressing Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 98 CAN1_GND CAN2_GND CAN1_GND CAN2_GND Connection Connection Connection PCTRL is PCTRL is PCTRL is Redundant-PCTRL No Off Redundant-PCTRL Redundant-PCTRL No Off No Off Figure 4.51: Standalone panel (regular and redundant): Configuration in network 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 99: Functional Modules
If a module is replaced the plug/screw terminals are simply re-fitted, with no need for complex rewiring. Functional settings on the modules are made using the FSP-5000-RPS programming software. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 100: Installation And Removal
100 en | Installation Modular Fire Panel 4.9.1 Installation and Removal Figure 4.52: Installation and removal of functional modules Figure 4.53: Detaching the screw terminal block 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 101: Ani 0016 A Annunciator Module
Please note that a power supply must be available. – The 24 V switch outputs can be reset. The switch output is deactivated if a fault occurs. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 102 The module can only be used with the MPC Panel Controller from software version 2.1 onwards. – If the FPA-5000 Fire Panel is not supplied with mains power, it can only be started – if a battery pair is connected to BAT1 and –...
Page 103 FPA-5000 Fire Panel is supplied with mains power and the BAT 2 connection is configured. – If the FPA-5000 Fire Panel is not supplied with mains power for an extended period, ensure that the batteries are disconnected. – When using the module in the FPP‑5000 External Power Supply, only one battery pair can be charged (see FPP‑5000 External Power Supply Unit Kit 24 V/6 A, page 121).
Page 104: Wiring Diagram
12 V / 28 Ah (12 V / 45 Ah) (12 V / 45 Ah) (12 V / 45 Ah) (12 V / 45 Ah) Figure 4.56: Wiring diagram for BCM‑0000‑B 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 105 A cable set is supplied and contains 2 connection cables: BCM/battery (90 cm) and battery/ battery (17 cm). If you want to install the batteries in a power supply housing, you require the CBB 0000 A Cable Set (BCM/battery cable length 180 cm. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 106 The temperature sensor is supplied with the power supply bracket and protects the batteries against overheating. If the sensor is not positioned correctly, the batteries can overheat and explode. Position the temperature sensor between the batteries. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 107: Czm 0004 A 4 Zone Conventional Module
The technical data can be found in CZM 0004 A 4 Zone Conventional Module, page 151. 4.9.5 ENO 0000 B Fire Service Interface Module The ENO 0000 B is used to connect fire service equipment: Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 108 FSE release element monitoring ⊗ + | − Signal lamp, e.g. BEGA lamp +24 V, approx. 10 W Relay 1-4 Information on the redundant connection of the module can be found in Redundancy, page 40. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 109: Fpe-5000-Ugm Interface Module
4.9.6 FPE‑5000‑UGM Interface Module The FPE-5000-UGM Interface Module allows the FPA-5000 Modular Fire Panel or an FPA-5000/ FMR-5000-C network to be connected to a higher-level system such as the UGM or to fire service devices such as FMF-FAT/FMF-FBF-FAT. The module provides two bi-directional transmission paths.
Page 110: Iop 0008 A Input/Output Module
Outputs, max. voltage of 35 V DC at 1.5 A per output (nominal 0.7 A) Ground IN1-IN8 Inputs, max. voltage of 5 V DC at 0.1 mA per input Ground The technical data can be found in IOP 0008 A Input/Output Module, page 152. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 111: Ios 0020 A 20 Ma Communication Module
RXD | TXD | GND RS232 interface Assignment of DSUB 9 Plug Figure 4.63: DSUB 9 plug PIN no. Connection TxD0 RxD0 The technical data can be found in IOS 0020 A 20 mA Communication Module, page 153. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 112: Ios 0232 A Rs232 Communication Module
RXD2 | TXD2 | GND RS232 interface 2 Assignment of DSUB 9 Plug Figure 4.65: DSUB 9 plug PIN no. Connection TxD0 RxD0 The technical data can be found in IOS 0232 A RS232 Communication Module, page 153. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 113: Lsn 0300 A Lsn Improved Module 300 Ma
* The auxiliary voltage may only be fed back to AUX2 when isolators (ERT technology) are used in the loop (suitable components include YBO-R/SCI isolators). The technical data can be found in LSN 0300 A LSN improved Module 300 mA, page 153. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 114: Lsn 1500 A Lsn Improved Module 1500 Ma
* The auxiliary voltage may only be fed back to AUX2 when isolators (ERT technology) are used in the loop (suitable components include YBO-R/SCI isolators). The technical data can be found in LSN 1500 A LSN improved Module 1500 mA, page 154. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 115 PRD 0004 A LSN 1500 A LSN 1500 A LSN 1500 A PRD 0004 A PRD 0004 A LSN 1500 A LSN 1500 A Figure 4.68: LSN 1500 A - Inserting the module Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 116: Nzm 0002 A Notification Appliance Zone Module
24 V DC input, battery voltage SYNC GND | SYNC OUT Output synchronization SYNC GND | SYNC IN Input synchronization The technical data can be found in NZM 0002 A Notification Appliance Zone Module, page 155. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 117: Rmh 0002 A Relay Module For Mains Voltage
FB1 + | FB1 - Feedback relay 1 FB2 + | FB2 + Feedback relay 2 The technical data can be found in RMH 0002 A Relay Module for mains voltage, page 155. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 118: Rml 0008 A Relay Module For Low Voltage
NO7 | C7 | NC7 Relay 7 NO8 | C8 | NC8 Relay 8 The technical data can be found in RML 0008 A Relay Module for Low Voltage, page 156. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 119: Accessories For Functional Modules
The strips can be individually printed using a standard laser printer. A dot file is included on the CD supplied with the MPC Panel Controller. Scope of delivery: 20 sheets of 6 strips. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 120: Cable Sets
The document numbers of the installation instructions can be found in the footer on every page of the document. The table below shows the instructions available. 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 121: Monitoring Auxiliary Power According To En
The FPP-5000 External Power Supply Unit Kit is designed to provide a universal power supply, and has space for two 12 V/45 Ah batteries. Figure 4.76: FPP‑5000 External Power Supply Unit Kit 24 V/6 A Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 122 (support points for looping through) LSN1 a2 - | LSN1 b2 + LSN outgoing AC FAULT - | + Input of mains fault BATT FAULT - | + Input of battery fault 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 123: Thp 2020 A Thermal Printer
The following information can be sent to the printer: – Operating procedures on the panel (e.g. daytime operation) – Alarm and fault messages – Plain text; programming is carried out via the programming software FSP-5000-RPS. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 124 200 lines of text. Printer Settings using Jumpers Notes: – The jumpers BR2, BR3 and BR4 must not be inserted if connecting to the FPA-5000. – Caution: Inserting jumper BR1 changes the character set from Western to Cyrillic. 09.2017 | 11.3 | F.01U.028.089...
Page 125 Modular Fire Panel Installation | en 125 = DR 2020 = THP 2020 A (FPA-5000) = 2400 bit/s (UEZ 2000) = 9600 bit/s (FPA-5000) = A, B, C, D (Western) Figure 4.80: THP 2020 A jumpers Changing the Paper Roll The paper roll in the printer is changed as follows (see also ):...
Page 126 12. If necessary, tension the paper by pressing the paper feed button. Notice! Only use the thermal printer paper specified by the manufacturer (Bosch product ID 4.998.110.290, pack of 5 rolls). The paper roll can be changed without turning off the printer. 09.2017 | 11.3 | F.01U.028.089...
Page 127: Remote Keypad
Modular Fire Panel Installation | en 127 Figure 4.81: THP 2020 A - Changing the paper roll 4.14 Remote Keypad Notice! Installation must only be carried out by authorized specialist personnel. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 128 The remote keypad can be used to perform the same operating procedures as the (MPC) panel itself, enabling a networked system to be operated decentrally. It has the following functional elements: 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 129 Information about address setting and configuration in the network can be found in . Installation Follow the instructions for the required installation version. Installation version Installation instructions Surface wall mounting See steps 1 to 13 and (see figure, I) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 130 Dismantle the operating unit before housing installation. This avoids damage to the touch screen and makes it easier to screw in the lower fixing screws. Figure 4.84: Remote Keypad installation variations 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 131 Modular Fire Panel Installation | en 131 Figure 4.85: Remote Keypad installation (1‑6) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 132 132 en | Installation Modular Fire Panel Figure 4.86: Remote Keypad installation (7‑10) 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 133 Modular Fire Panel Installation | en 133 Figure 4.87: Remote Keypad installation (11‑13) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 134 134 en | Installation Modular Fire Panel (∅ 8 x 40 mm) 5 x 50 mm ∅ ∅ 5 x 50 mm ∅ Figure 4.88: Remote Keypad surface mounting; dimensions in mm 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 135 Installation | en 135 (∅ 8 x 40 mm) ∅ 5 x 50 mm ∅ 8 mm ∅ 5 x 50 mm 250 x 310 Figure 4.89: Remote Keypad flush mounting; dimensions in mm Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 136 136 en | Installation Modular Fire Panel ∅ 5 x 50 mm ∅ 2 mm 244 x 304 Figure 4.90: Remote Keypad tilting installation; dimensions in mm 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 137 Modular Fire Panel Installation | en 137 Figure 4.91: Remote Keypad sticker Wiring 1. Place the shield wire on the support point (step 1) 2. Secure the cable with cable ties (step 1 to 4). Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 138 138 en | Installation Modular Fire Panel SHIELD Figure 4.92: Remote Keypad wiring 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 139 -BAT FAULT ⇒ IN1 -AC FAULT ⇒ IN2 Figure 4.93: Remote Keypad wiring with BCM-0000-B Notice! The value 2.8 A must be set in the configuration window of the BCM‑0000‑B in the panel's programming software. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 140 Configure the remote keypad using the DIP switches. Mark the selected setting on the sign below the DIP switches (see , step 4). Addressing and Configuration of Remote Keypad RESET 1 - - 240 Figure 4.94: Addressing and Configuration 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 141: Commissioning
The fire panel is configured on a PC using the FSP-5000-RPS programming software. The programming software and the associated documentation can also be found on the CD supplied with the FPA-5000. More recent versions of the software are available on the Internet for those with access rights.
Page 142: Testing The Power Supply
Test the activation of the transmission devices (TD/DACT/TSN/GSM/X25/X31) by initiating the corresponding fault. Test the activation of extinguishing systems, door controls etc. Test all internal alarm signaling equipment (e.g. audible and visual notification appliances). 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 143: Maintenance And Service
Notice! Have maintenance and inspection work carried out regularly by trained, qualified personnel. Bosch Sicherheitssysteme GmbH recommends a functional and visual inspection at least once a year. Danger! Touching live components can result in electric shock.
Page 144 Importable objects including counters (without pre-defined system 2000 counters) Automatic connections to FMR-5000-C Blocks of State-Dependent Rules (depending on what kind of activations are possible) Maximum number of rules within a block 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 145: Power Loss Of Fpa-5000 Components
IOS 0020 A IOS 0232 A LSN 0300 A LSN 1500 A NZM 0002 A RMH 0002 A RML 0008 A Power loss of FPA-5000 Components Component Power loss ANI 0016 A 0.62 W (all LEDs lit) BCM‑0000‑B – 0.96 W (controller + green LED lit) –...
Page 146: Housing And Accessories
PRS-0002-C Panel Rail Short for 2 Modules Input voltage 24 V DC (20 V DC to 30 V DC) Current consumption at 24 V 2.8 mA Output voltage 5 V DC ± 4.5 %/24 V DC Maximum input current 8 A at 24 V DC 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 147: Prs 0002 A Panel Rail Short For 2 Modules (No Longer Available)
ABS plastic (UL94 V-0), satin finish, anthracite, RAL 7016 Space required (H x W x D) approx. 146 x 396 x 35 mm Weight approx. 280 g Installation of the panel rail is described in Panel Rails, page 78. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 148: Fpo-5000-Psb1/Fpo-5000-Psb-Ch Power Supply Brackets
Display element TFT touch screen, 320 x 240 pixels, 127.5 mm x 170 mm active area Operating elements 22 buttons, 1 key switch, 12 LEDs, 1 reboot button Interfaces CAN1, CAN2, ETH1, ETH2, USB, RS232 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 149: Remote Keypad
ABS plastic, light gray (similar to RAL 7035) Space required (H x W x D) 280 x 340 x 87 mm Weight approx. 3 kg Installation of the device is described in Remote Keypad, page 127. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 150: Fsp-5000-Rps Programming Software
– Fault 40 mA Permissible battery capacities – with 2 batteries 24 to 26 Ah, 36 to 45 Ah – with 4 batteries 48 to 52 Ah, 72 to 90 Ah Maximum current – of the module Max. 6 A – to panel rails Max. 6 A 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 151: Czm 0004 A 4 Zone Conventional Module
Space required (H x W x D) approx. 127 x 96 x 60 mm Weight without packaging Approx. 135 g Operating and display elements 8 LEDs (4 x red, alarm/4 x yellow, fault) 4 keys (LED test) Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 152: Eno 0000 B Fire Service Interface Module
Maximum current consumption 15 mA at 24 V DC Maximum switch-on current 700 mA (short-circuit protected, I = 1.5 A) Maximum cable length 3 m Space required (H x W x D) approx. 127 x 96 x 60 mm 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 153: Ios 0020 A 20 Ma Communication Module
28 ± 1.0 V DC Maximum current consumption 1750 mA at 24 V DC Nominal current consumption – Module 39 mA at 24 V DC – 1.7 x current consumption of the LSN elements – 1.2 x auxiliary supply AUX Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 154: Lsn 1500 A Lsn Improved Module 1500 Ma
500 mA for an LSN loop (ERT technology) or 2 x (28 V DC) max. 500 mA with 2 stubs Space required (H x W x D) approx. 127 x 190 x 60 mm Weight approx. 440 g 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 155: Nzm 0002 A Notification Appliance Zone Module
Space required (H x W x D) approx. 127 x 96 x 60 mm Weight Approx. 135 g Installation of the power supply unit is described in RMH 0002 A Relay Module for Mains Voltage, page 117. Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 156: Rml 0008 A Relay Module For Low Voltage
Protection class as per EN 60950 Class I equipment Permissible operating temperature -5 °C to 50 °C Permissible storage temperature -20 °C to 60 °C Relative humidity Max. 95 % non-condensing Cooling Ventilation without ventilator 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 157: Fpp-5000-Ti Trouble Interface
The module is described in FPP‑5000 External Power Supply Unit Kit 24 V/6 A, page 121. Appendix Options with requirements under EN 54‑2:1997/A1:2006 The FPA-5000 provides the following options with requirements under EN 54‑2:1997/A1:2006: – Output for activation of fire alarm devices –...
Page 158: Component Overview
Extension Housings for Wall Mounting Designation Product ID DIB 0000 A Distribution Box 4.998.139.497 HBE 0012 A Modular Extension Housing for 12 Modules 4.998.137.287 PSB 0004 A Power Supply 4.998.137.289 PSS 0002 A Power Supply Small, Frame Installation 4.998.137.288 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 159: Accessories For Housing
F.01U.073.324 FPP‑5000‑TI13 LSN Communication interface for FPP‑5000 F.01U.161.679 UPS 2416 A Universal Power Supply 24 V/6 A F.01U.500.367 FPO‑5000‑PSB‑CH Power Supply Bracket F.01U.078.860 FPO‑5000‑PSB1 Power Supply Bracket F.01U.078.858 Battery 12 V/28 Ah 2.799.502.177 Battery 12 V/45 Ah 2.799.380.000 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 160: Panel Controller/Remote Keypad
FMR‑5000‑C-02 Remote Keypad ES, F.01U.275.062 Labeling and documentation in Spanish FMR‑5000‑C-03 Remote Keypad PT F.01U.275.063 Labeling and documentation in Portuguese FMR‑5000‑C-05 Remote Keypad FR/NL, F.01U.275.064 Labeling and documentation in French/Dutch 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 161 4.998.137.283 ADC 1024 A 1024 point Address Card 4.998.137.284 ADC‑2048‑A 2048 point Address Card F.01U.076.111 License Key Designation Product ID ADC‑5000‑OPC License key F.01U.076.112 ADC‑5000‑VA Licence Key F.01U.282.794 ADC‑5000‑OPC-VA Licence Key F.01U.282.795 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 162: Functional Modules
CPA 0000 A Cable Set AT 2000 4.998.153.247 CPB 0000 A Cable BCM/UPS 4.998.153.243 CPR 0001 A Printer Cable F.01U.500.372 CRP 0000 A Redundant MPC cable set 4.998.153.242 8.2.9 Thermal Printer Designation Product ID THP 2020 AThermal Printer, in frame installation housing 4.998.137.295 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 163: Can/Foc Adapters
Modular Fire Panel Appendix | en 163 8.2.10 CAN/FOC Adapters Designation Product ID DL‑CAN/1x13-MM‑ST, PzP CAN‑LWL System/MM 0 100 07421 DL‑CAN/1x13-MM‑SC 0 100 07423 DL‑CAN/1x13-SM‑ST 0 100 07431 DL‑CAN/1x13-SM‑SC 0 100 07433 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 164: Special Applications
– a– b+ – a– b+ AUX1 LSN1 AUX2 LSN2 AUX1 LSN1 AUX2 LSN2 – NO COM NO COM – REL1 REL1 Figure 8.1: Several FLM-420-RLE modules in the LSN loop 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 165: Index
12, 84 Disposal 143 Installation 42 Distributor rail 14, 15, 63 Documentation 43, 143 Documentation 43, 141, 143 Instructions 42 Door control 23 88 Dummy cover plate 120 Quick guide 43 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 166 9, 24 Interfaces 12 Instructions 24 Module 109 Software 9, 10, 11, 24 Introduction 6 Planning Software by Bosch 9, 10, 11, 24 Plena Voice Alarm System 7, 24 Power loss 146 Junction board 61 Power supply External 122 Key deposit 23...
Page 167 Modular Fire Panel Index | en 167 Universal security system 7 Voice alarm system 24, 94, 144 Wiring guide 24, 43, 143 Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089...
Page 168 168 en | Index Modular Fire Panel 09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH...
Page 170 Bosch Sicherheitssysteme GmbH Robert-Bosch-Ring 5 85630 Grasbrunn Germany www.boschsecurity.com © Bosch Sicherheitssysteme GmbH, 2017...

Bosch FPA-5000 System Information Manual

Quick Links

Related Manuals for Bosch FPA-5000

Summary of Contents for Bosch FPA-5000

Table of Contents
