Nidec Unidrive M200 Quick Start Manual page 12

Figure 4-3 Pr 05 = AV.Pr
10k
Figure 4-4 Pr 05 = AI.Pr
Current speed
reference input
* Refer to the Control User Guide.
12
1 0V
Voltage speed reference
2
input (AI 1)
4 + 10 V output
Reference select
5
Analog output 1
7
(motor frequency)
+ 24 V output
9
Digital output
10
(zero frequency)
Drive enable
11
12
Run forward
Run reverse
13
Reference select
14
1 0V
Current speed
2
reference input (AI 1)
4 + 10 V output
5
Reference select
Analog output 1
7
(motor frequency)
+ 24 V output
9
Digital output
10
(zero frequency)
11 Drive enable
12
Run forward
Run reverse
13
Reference select
14
Unidrive M200/201 Control Quick Start Guide
Terminal 5 Terminal 14
0 0 Analog reference 1*
0 1 Preset speed 2*
1 0 Preset speed 3*
1 1 Preset speed 4*
Terminal 5 Terminal 14
0 0 Analog reference 1*
0 1 Preset speed 2*
1 0 Preset speed 3*
1 1 Preset speed 4*
Reference selected
Reference selected
Issue Number: 4
