User's Manual
AC Power Supply PCR-LE series
PCR500LE
PCR1000LE
PCR2000LE
PCR3000LE
PCR4000LE
PCR6000LE
PCR9000LE
PART NO. IB02390H
Oct. 2017
About the PCR-LE Documentation 4
Precautions Concerning Installation 6
Precautions When Moving the Product 6
Handling the Terminal Block Tray (PCR1000LE - PCR9000LE) 7
Connecting the PCR500LE Power Cord 8
Connecting the power cord (PCR1000LE - PCR 9000LE) 9
Limit Values and Protection Functions30
Using the Synchronization Function 45
Using the Voltage compensation Function 46
Using Power Line Abnormality Simulations 51
Using the Harmonic Current Analysis Function 63
Generating Special Waveforms (Waveform bank) 64
Setting Soft Starts (The voltage rise time) 65
Using the Power Management Functions 67
Controlling the Output Using External Analog Signals 68
Peak hold current measurement 102
Factory Default Settings (Initialization) 122
Checking the Package Contents 3
Features 3
PCR-LE Series models 6
Turning the Power On 9
Connecting the Load 10
- Basic -
Front Panel 13
Rear Panel 15
Panel Operation Basics 16
Selecting the Output Mode 20
Setting the Output Voltage 21
Setting the Frequency 26
Turning Output On and Off 26
Displaying Measured Values 28
Setting Limits31
Using Protection Functions 36
Using Memory 38
- Advanced -
Using the Sequence Function 54
Setting the Output Impedance 65
Fixing the Internal Vcc 66
Selecting the Response 66
- Specifications -
Main Unit Specifications 77
Option Specifications 84
Outline Drawings 86
- Appendix -
Glossary 91
Operating Characteristics 93
About the output and the load 94
Sequence tutorial 103
Option 115
Maintenance 125
Troubleshooting 126
Alarms and Trouble 128
Error Message 131
Index 132

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCR500LE and is the answer not in the manual?

Questions and answers

Related Manuals for Kikusui PCR500LE

Summary of Contents for Kikusui PCR500LE

  • Page 1 Precautions Concerning Installation 6 Precautions When Moving the Product 6 Handling the Terminal Block Tray (PCR1000LE - PCR9000LE) 7 Connecting the PCR500LE Power Cord 8 Connecting the power cord (PCR1000LE - PCR 9000LE) 9 Turning the Power On 9 Connecting the Load 10 User’s Manual...
  • Page 2 Every effort has been made to ensure the accuracy of this manual. However, if you have any questions or find any errors or omissions, please contact your Kikusui agent or distributor. Firmware version of the product to which this manual applies This manual applies to PCR-LEs with firmware version 5.0x.

  • Page 3: Checking The Package Contents

    • Master-Slave parallel control (Optional) The PD05M-PCR-LE/PD05S-PCR-LE option enables the PCR-LE Series to be operated in parallel (except for the PCR500LE and PCR1000LE; up to five units or within 27 kVA of power; different models can be mixed).

  • Page 4: About The Pcr-Le Documentation

    If the manual gets lost or soiled, a new copy can be pro- vided for a fee. To replace or purchase a manual, please contact your Kikusui agent or distributor. At that time, inform your agent or distributor of the “Part No.” written on the front cover of this manual.

  • Page 5: Documentation Structure

    Documentation Structure The PCR-LE Series manual comprises the following documentation. „ User’s Manual -Basic- „ User’s Manual -Advanced- „ „ • Front panel and Rear panel • Using the synchronization Function • Panel Operation Basics The synchronization function synchronizes the frequency and •...

  • Page 6: Precautions Concerning Installation

    20 A 10 A and the PCR2000LE do not have a stopper.) PCR3000LE 3 kVA 30 A 15 A ● Unlock the casters (on all products excluding the PCR500LE). PCR4000LE 4 kVA 40 A 20 A PCR6000LE 6 kVA 60 A 30 A ●...

  • Page 7: Handling The Terminal Block Tray (Pcr1000Le - Pcr9000Le)

    Handling the Terminal Block Tray (PCR1000LE - PCR9000LE) The PCR-LE Series AC INPUT, OUTPUT terminal block, SENSING Pull out the stopper to lock the terminal block tray terminal block, and J1 to J4 connectors are designed so that they in place. can only be wired after you first pull out the terminal block tray.

  • Page 8: Connecting The Power Cord

    • The power cord with a plug can be used to disconnect the prod- PCR500LE - PCR6000LE (Single-phase, 200 V input): uct from the AC power line in an emergency. Connect the plug L, N, and...

  • Page 9: Turning The Power Switch On

    The product can receive a nominal power supply voltage: Check that nothing is connected to the OUTPUT ter- PCR500LE - PCR4000LE (Single-phase, 200 V input) : minal block on the rear panel and the outlets on the 100 Vac to 120 Vac or 200 Vac to 240 Vac front panel.

  • Page 10: Connecting The Load

    L is negative electric potential. Use the upper holes to fix the terminal Screw diameter of OUTPUT terminals cover in place. This keeps the OUTPUT PCR500LE, PCR1000LE, and PCR2000LE: M4 terminals from being exposed. PCR3000LE and PCR4000LE: M5 PCR6000LE and PCR9000LE: M8...
  • Page 11 Connecting cables(PCR1000LE - PCR9000LE) When the load is located at a remote location Pull out the terminal block tray, and then connect the load cables. If the load is located at a remote location, the PCR-LE may need be controlled remotely. Check that the POWER switch is turned off.
  • Page 12 Max. output voltage: 250 Vac(rms) Maximum output current: 10 Aac (rms) per outlet (on models other than the PCR500LE) 5 Aac (rms) total for the two outlets on the PCR500LE 10 Aac (rms) total for the two outlets on the PCR1000LE Do not disconnect the load when the maximum rated voltage of the outlets has been exceeded or in DC mode.

  • Page 13: Front Panel

    - Basic - This chapter explains the basic operating procedures of the PCR-LE Series. Front Panel PCR-LE (excluding the PCR500LE; example of the PCR4000LE) REMOTE connector (not used) RS232C connector connector Control Panel Power units and air inlet of the PCR-LE Series...

  • Page 14: Control Panel

    Front Panel (Cont.) Control Panel Numeric keypad/ Setting key Numeric keypad Enter numeric values directly CLR key Clear the numeric keypad input. ON PHASE key Set the output on phase RANGE key Switch between output voltage ranges SYNC key Enable the synchronization function OFF PHASE key Set the output off phase KEYLOCK key Lock and unlock the keys...

  • Page 15: Rear Panel

    Rear Panel PCR-LE (excluding the PCR500LE; example of the PCR2000LE) SLOT1 Expansion slot for a multiphase operation (optional) SEQ STAT OUT connector SLOT3 Connecting a BNC cable Expansion slot for an analog signal interface (optional) (status output) to SLOT2 SEQ TRIG OUT connector...

  • Page 16: Panel Operation Basics

    Panel Operation Basics This section explains the status indicators of the product and the basics of operating the product from the front panel. Control panel You can pull out the control panel and tilt it to one of the two available settings. If you use the optional EC05-PCR extension cable, you can use the control panel while it is detached from the PCR-LE Series.

  • Page 17: Home Position

    Parts of the screen Explanation of function keys in this manual The screen consists of the following three parts. The function keys in this manual are explained in a tabular form as shown below. Status, LOAD RESP.M OUTPUT measured-value, 99.00 Item Title Description...

  • Page 18: Switching From Remote Mode To Local Mode

    Panel Operation Basics (Cont.) Switching from remote mode to local mode Specifying values When the PCR-LE Series is in remote mode, “RMT” is displayed To specify values, use the numeric keypad or the rotary knob. on the screen. To switch the PCR-LE Series to local mode from When the cursor is displayed in the entry area, you can use the the panel, press LOCAL (SHIFT+2).

  • Page 19: Adjusting The Screen Brightness

    Adjusting the screen brightness You can set the screen brightness to one of three levels (1 to 3). „ Rotary knob operations „ The larger the number, the brighter the screen. Turn the rotary knob to the right to increase the displayed value. Press CONFIG (SHIFT+OPR MODE) and then DISPLAY (F4) to Turn the rotary knob to the left to decrease the displayed value.

  • Page 20: Selecting The Output Mode

    Selecting the Output Mode If the 2P05-PCR-LE single-phase, three-wire output option is „ Setting the output mode „ installed, select whether to use single-phase, three-wire output Press OPR MODE and then 2P (F3) to select the output or two-phase output . mode.

  • Page 21: Setting The Output Voltage

    Setting the Output Voltage To set the output voltage, set the output voltage mode, the output voltage range, and the output voltage value. Setting the output voltage mode The PCR-LE Series has the following output voltage modes: „ Output voltage mode setup procedure „...

  • Page 22: Setting The Output Voltage Range

    Setting the Output Voltage (Cont.) Setting the output voltage range Setting the output voltage The PCR-LE Series has the following output voltage ranges: L You can set the output voltage while output is on or off. The and H. measured value is always displayed. The maximum output current varies depending on the output Set the voltage limit to prevent the PCR-LE Series from generat- voltage range.
  • Page 23 Output voltage setup procedure To set the AC voltage, press V and then ACVOLT (F1). To set the DC voltage, press V and then DCVOLT (F2). LOAD AC+DC RESP.M OUTPUT 58.00 6.87 28.1 RANGE ACVolt 7.5V ACVOLT DCVOLT PROTECT VMAX VMIN Item Title...
  • Page 24 Setting the Output Voltage (Cont.) Single-phase, three-wire output (optional) voltage setup procedure „ AC+DC mode Be sure to set the output mode (single-phase, three-wire output „ or two-phase output) before you set the voltage. -> p20 Specifying the AC voltage with phase voltages „...
  • Page 25 Three-phase output (optional) voltage setup procedure „ Voltage setting range „ AC+DC Mode „ „ • Phase voltage setting range Specifying the AC voltage with phase voltages To set all the phases at the same time, press V and then AC PH AC voltege setting range DC voltage setting range VOLT (F1).

  • Page 26: Setting The Frequency

    Setting the Frequency Turning Output On and Off You can set the frequency in AC mode and AC+DC mode. The F key is disabled in DC mode. WARNING You can set the frequency while output is on or off. Risk of electric shock. Set the frequency limit to prevent the PCR-LE Series from gen- Do not touch the OUTPUT terminal block, the outlets, erating a frequency that is greater than is necessary.
  • Page 27 Output on/off phase control „ Impedance when the output is off „ The internal circuits and the output of the PCR-LE Series are You can set the AC mode output on/off phase. You can set the not separated by a mechanical switch or relay. The PCR-LE output on and output off phases separately.

  • Page 28: Displaying Measured Values

    Displaying Measured Values You can monitor the present output value. When the output is off, this is nearly 0. Setting the aperture time (measurement time) Displaying the voltage With a longer aperture time, the measurements become more The measured voltage is displayed in the status, measured- stable, but it takes longer to update the display of the mea- value, and setting display area.
  • Page 29 Load level meter Displaying the current, power, and power factor The load level meter displays the ratio of the output current The rms current, peak current, average current, power, appar- (which is detected as the current flowing through the load) to ent power, or power factor is displayed in the status, measured- the rated current on a bar graph.

  • Page 30: Limit Values And Protection Functions

    Limit Values and Protection Functions This product has the following limit functions and protection functions. • Limit Functions Limits can be placed on the PCR-LE Series output voltage setting and frequency setting. They prevent damage to the load caused by mistaken operations and limit the current that flows through the load.

  • Page 31: Setting Limits

    Setting Limits Limits can be placed on the PCR-LE Series output voltage setting and frequency setting. They prevent damage to the load caused by mistaken operations and limit the current that flows through the load. You can set limits in advance according to the load conditions. You can set these values while output is on or off.

  • Page 32: Current Limit And Peak Current Limits

    Setting Limits (Cont.) Current limit and peak current limits Limits can be placed on the current that flows through the load. • Current limit There is a current limit, a positive peak current limit, and a neg- You can set the output current’s upper limit. You cannot set ative peak current limit.
  • Page 33 W -IPKLimit Sets the negative peak current limit of W phase (the rated current × 0.1 to the rated current × 4.4) *1. Single-phase three-wire output or three-phase output (optional) only *2. Three-phase output (optional) only Setting Output mode PCR500LE PCR1000LE PCR2000LE PCR3000LE PCR4000LE PCR6000LE PCR9000LE Current limit 0.50 A to 1.00 A to 2.00 A to...
  • Page 34 Setting Limits (Cont.) Current limit and peak current limits (Cont.) „ Action to perform when the current limit is exceeded „ You can set the action to perform (whether the output is turned Press I and then TRIP (F2) to select the action to perform when off) when the current exceeds the current limit.
  • Page 35 Setting the time (Trip time) that elapses before the output is turned off when the current limit is exceeded In AC mode, you can set the amount of time that elapses after the current limit is exceeded (the amount of time during which the current limit is continuously exceeded) before the output is turned off.

  • Page 36: Using Protection Functions

    PCR-LE Series may be malfunctioning. average value. Stop using it immediately, and contact your Kikusui agent or In AC+DC mode, specify an rms value. To set an average distributor. Inform the individual that you contact of the alarm value, change to DC mode, set the average value, and then code that is displayed.
  • Page 37 „ Internal semiconductor protection (OCP) „ This protection function protects the internal semiconductors Setting the time that elapses before an alarm is generated of the PCR-LE Series. The internal semiconductor protection In AC mode, you can set the time that elapses after the internal function will not be activated if you follow the PCR-LE Series semiconductor protection has been activated (the amount of usage guidelines outlined in the specifications.

  • Page 38: Using Memory

    What to do if the breaker trips data to a USB memory device. • Internal memory The PCR500LE and PCR1000LE do not have a breaker. This is useful when you are testing drastic changes in volt- On the PCR2000LE, PCR3000LE, PCR4000LE, PCR6000LE, age or frequency.

  • Page 39: Using Internal Memory

    Using internal memory The frequency, AC voltage, DC voltage, and waveform bank number can be stored to and recalled from the internal memory. During single-phase, three-wire output and three-phase output (optional), phase voltages are stored. Line voltages are calculated from phase voltages.

  • Page 40: Using Usb Memory Devices

    Using Memory (Cont.) Using USB memory devices The data of one waveform bank, internal memory (entries num- „ Folders where the files are saved and file names „ ber 1 to 99), panel settings, power line abnormality simulations, The following folders are created on the USB memory device. and sequence data can be saved to a USB memory device.
  • Page 41 „ Saving data to USB memory devices „ Press SAVE (F4) to save the settings. Set up the configuration that you want to save. Do not remove the USB memory device until “File was saved” disappears. LOAD RESP.M OUTPUT Connect a USB memory device to the USB port Disappears when 99.00 on the front panel.
  • Page 42 Using Memory (Cont.) Using USB memory devices (Cont.) „ Recalling settings from a USB memory device „ Connect a USB memory device to the USB port Use the rotary knob to select the file that you on the front panel. want to recall.
  • Page 43 „ Error messages „ If there is a problem with the USB memory device, an error will occur. Error messages are displayed when errors occur. Error message Description Data out of range. (Line = the line A setting is outside of its range. number) Disk access error.
