Kikusui PCR6000LE2 Setup Manual

Setup Guide
AC Power Supply PCR-LE2
seriess
PCR6000LE2
PCR9000LE2
PCR12000LE2
PCR18000LE2
PCR27000LE2
Thank you for purchasing the PCR-LE2 Series AC Power Supply.
The PCR-LE2 Series is a special version of the PCR-LE Series that
can produce highly pure AC signals through the combination of
its high-speed linear amplifier and arbitrary waveform synthesizer.
It features switchable single-phase, single-phase three-wire, and
three-phase outputs.
Checking the Package Contents
When you receive the product, check that all accessories are in-
cluded and that the accessories have not been damaged during
transportation. If any of the accessories are damaged or missing,
contact your Kikusui agent or distributor. We recommend that you
save all packing materials, in case the product needs to be trans-
ported at a later date.
Accessory
Setup Guide (1pc.)
[Z1-006-120]
CD-ROM (1 pc.)
[SA-6060]
English: 1pc. [Z1-006-102]
Japanese: 1pc. [Z1-006-100]
Quick Reference
KIKUSUI ELECTRONICS CORP.
1-1-3, Higashiyamata, Tsuzuki-ku, Yokohama, 224-0023, Japan
TEL: +81-45-593-7570 Fax: +81-45-593-7571
http://www.kikusui.co.jp/en
WEBSITE
The newest version of the operation manual can be
downloaded from Download service of Kikusui web-
site.
Printed in Japan © 2013
PCR-LE2 series
PART NO. Z1-006-120, IB027733
Dec. 2014
If necessary, attach
to the product.
Heavy object warning label
PCR6000LE2/PCR9000LE2 only
[A8-900-158]
Safety information
(1pc.) [Z1-005-040]
PCR-LE2 manual
Features
The PCR-LE2 Series is equipped with the following features.
• Switchable between single-phase output, single-phase three-
wire output, and three-phase output
Three types of output are available on a single unit.
• Various power supply simulations
Power line abnormalities such as outages and voltage dips can
be simulated. This is a basic feature for power-supply-environ-
ment testing.
• Various measurements
The rms voltage and current, the peak voltage and current, the
active power, apparent power, and power factor of the output
can be measured. Harmonic analysis (up to the 40th harmonic)
can be performed on the output current.
• DC output
The PCR-LE2 Series can generate DC output (single-phase out-
put or single-phase three-wire output only) and AC + DC output
(single-phase output only). This makes it possible to use the
PCR-LE2 Series in a wide variety of fields, including chemistry
and physics.
• Sequences
The output voltage, frequency, and waveform can be changed
over time. Power-supply-environment testing can be automated.
In addition to the AC output sequences, DC output (single-phase
output or single-phase three-wire output only) and AC + DC out-
put (single-phase output only) sequences are also available. A
variety of standard tests can also be performed.
• Sensing and regulation adjustment
Even if the load device is at a remote location, the PCR-LE2 Se-
ries can stabilize the voltage across the load by correcting for
voltage drops.
There are two types of sensing: hard sensing (single-phase
output only) and soft sensing. The different types of sensing are
used depending on the load conditions and how you will use the
PCR-LE2 Series.
• Output current control
The output limit function can be used to limit the output current
(rms) to a fixed value to perform continuous operation. Continuity
tests on electrical equipment (such as switchboards, breakers,
and wiring devices) can be performed under stable conditions.
• Power management function (power saving function)
A sleep function, which turns the power units off to reduce power
consumption when output is not generated for the specified
length of time, and a power-saving function, which operates the
power units at the bare minimum settings as required by the sup-
ply load, are available.
• Memory function
Up to 99 entries of output frequency, voltage (AC or DC), and
waveform bank settings can be saved to the internal memory.
The contents of internal memory, panel settings, power line ab-
normality simulations, sequence data, and waveform bank data
can be saved to a USB memory device.
• External communications
The PCR-LE2 Series can be controlled remotely through its
RS232C interface. If an optional interface board is used, the
PCR-LE2 Series can be controlled remotely through USB, GPIB,
and LAN interfaces.
• External analog signal control (optional)
The EX05-PCR-LE/EX06-PCR-LE option enables you to control
the PCR-LE2 Series output using external analog signals.
