4. If either of following situations should develop, the auto restart times will be reset:
(1) No additional malfunction (in operation or stop) occurs within 10 minutes.
(2) Press RESET button.
F_25: Return to Factory Pre-Settings
= 010: Constants initialization to 50Hz system
= 020: Constants initialization to 60Hz system
1. When F_25 is set to 010, all parameters are restored to factory settings. The settings of F_05 =1
and F_06 = 50. F_25 is restored back to 000 after the reset process is complete. (50Hz
operation)
2. When F_25 is set to 020, all parameters are restored to factory settings. The settings of F_05 =4
and F_06 = 60. F_25 is restored back to 000 after the reset process is complete. (60Hz operation)
F_26: SP2(1~200Hz) , Multi-speed2 (Reference to F_19 & F_20)
F_27: SP3(1~200Hz) , Multi-speed3 (Reference to F_19 & F_20)
F_28: Direct start
= 0 : Direct start enable when remote Run command on
= 1 : Direct start disable when remote Run command on
When F_28 = 1 and control mode is remote control (F_10 = 1), Inverter can not start if RUN switch is
ON when power is engaged, Must be turned the RUN switch OFF and turned ON again, Then
Inverter can start.
F_29: CPU program version
F_30: Last three faults
1. Last three faults: indicate the sequence of the occurrence of malfunctions by the location of
decimal point. x.xx indicates a recently happened malfunction. xx.x indicates the last
malfunction that happened. xxx. Indicates the earliest malfunction in the record.
2. After entering the F_30 function, the x.xx trip record will be displayed first. After that, press
button and you can read activity in a chronological order. xx.x  x xx.  x .xx
3. After entering F_30 function, if the RESET button is pressed, the trip record will be cleared.
Indication display
4. When the content of trip indicates O.CC, it will indicate the latest trip code is OC-C and so on.
-.--, --.- ---.
, and
42
42
,,, consecutively.
