SYN10 S 220 07/09
(
Mounting Instructions
SYN10 T 400 05/07/09
q
M4
3xø4.5
)
See NOTE
Dimension
Model
S220 07/09 e T400
Dimension
Model
S220 07/09 e T400
NOTE: For safety reason, we strongly recommend
users to remove the M4 grounding screw
then screw the enclosed "metal frame
grounding terminal" on the same location to
make a grounding bar to ensure good earth
protection.
20
20
Unit :mm
A
B
C
D
143.1 127.5
140
8.0
E
F
G
171.7
108
118
