Machine Specifications

Total Weight and Size VR3 Lat Pull 12130 Standard Stack
Weight
540 Lbs 59" L x 55" W x 90" H
245 Kg 149 cm L x 140 cm W x 230 cm H
Total Weight and Size VR3 Chest Press 12130 Heavy Stack
Weight
620 Lbs 59" L x 55" W x 90" H
280 Kg 149 cm L x 140 cm W x 230 cm H
Maximum User Weight
300 lbs/135 kg

Choosing and Preparing a Site

Before assembling the unit, verify the chosen site meets the following criteria:
Area is well lit and well ventilated.
•
Surface is structurally sound and properly leveled.
•
Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches
•
(0.6 meters).
Adjacent units may share the free area.
•
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
In compliance with the ADA (American Disabilities Act) there must be clear floor space of at least
Cybex Owner's Manual

Assembly

Machine Dimensions at Rest
Machine Dimensions at Rest
Machine Dimensions in Use
Same
Same
Machine Dimensions in Use
Same
Same
Maximum Training Weight
305 lbs/138 kg
