Page 1: User Guide
Aport-212 Dual-port Modbus Gateway User Guide Version 1.1 Copyright © Artila Electronics Co., Ltd. All Rights Reserved. -
Page 3: Table Of Contents
Master RTU / ASCII Mode ....................8 S2E Gateway ........................8 Install Manager Utility Software ................9 Broadcast Search........................ 9 Configure Aport-212 ......................9 Basic Setting ........................10 UART Operation Mode ..................... 11 Slave RTU or ASCII Mode ....................11 Master RTU or ASCII Mode .................... - Page 4 5.11 Web Server Settings ......................14 5.12 TCP Command Settings ....................14 5.13 Serial Console and Debug Port Settings ................14 5.14 Accessible IP Settings ...................... 15 5.15 Alive Check Timeout ......................16 5.16 Quick Command Button ....................16 5.17 Web Console ........................17 5.18 Login with Password ......................
-
Page 5: Introduction
Aport-212 User Guide 1. Introduction 1.1 Features Gateway of Modbus TCP to Modbus RTU/ASCII Two Configurable RS-232/422/485 serial ports Each serial port can be configured as Modbus Master or Modbus Slave mode Each serial port supports up 16 Modbus TCP master ... -
Page 6: Packing List
Aport-212 User Guide Operating Temperature: 0~60°C Storage Temperature: -20~85°C 1.3 Packing List Aport-212 Modbus Gateway 1.4 Optional Accessory CB-RJ2CON-100 (91-RJCON-100): Console Cable (RJ45 to DB9 Female, 100cm) DK-35A (36-DK35A-000): DIN RAIL Mounting Kit PWR-12V-1A (31-62100-000): 110~240VAC to 12VDC 1A Power Adaptor... -
Page 7: Layout
Aport-212 User Guide 2. Layout Power TB Ethernet Power Jack Serial Console Serial Port 1 Serial Port 2 ‧3‧... -
Page 8: Pin Assignment And Definition
Aport-212 User Guide 3. Pin Assignment and Definition 3.1 Power Connector Connecting 9~40VDC power line with the Aport-212 terminal block or the power jack. If the power is properly supplied, the Power LED will keep solid yellow color. 3.2 Serial Port Connector... - Page 9 Aport-212 User Guide Web console: http://192.168.2.127:5003 Telnet console: telnet 192.168.2.127 5001 ‧5‧...
-
Page 10: Modbus Gateway Operation
Slave devices. Maximum 64 Master TCP request can be buffered and Unit ID (UID), which is used to address the serial device, can tell Aport-212 which serial port to send the command. In figure slave RTU shown as follow data with UID 1 to 123 will go to port 1 and 124 to 247 will use port 2. -
Page 11: Tcp Exception
Aport-212 User Guide 4.3 TCP Exception The function allows Aport-212 to send the exception code to remote TCP devices. Currently two exception code is supported: Exception code: 0x0A 1. Unknown UID 2. TCP request overflow Exception code: 0x0B 1. Serial slave device time out Slave RTU/ASCII Block Diagram ‧7‧... -
Page 12: Master Rtu / Ascii Mode
When Modbus Master are serial devices, up to 32 TCP slave devices can be accessed by a serial Modbus Master. Aport-212 uses UID to decide the IP address and port of the TCP slave device to connect to. Except function is also available to serial Master when there is unknown TCP slave or connection is not established. -
Page 13: Install Manager Utility Software
Aport-212. To install the Manager Utility, please find the ManagerUtilitysetup.exe as shown following. 5.1 Broadcast Search Once start Manager utility, you can click telescope icon to search the Aport-212 in the network. 5.2 Configure Aport-212 Once Aport-212 is discovered, Manager will show following information. -
Page 14: Basic Setting
Aport-212 User Guide Double click the Aport-212 to configure, you will see following screen. 5.3 Basic Setting Basic Setting is read only. ‧10‧... -
Page 15: Uart Operation Mode
Modbus command in time. TCP Exception: Enable or disable the TCP exception function. Idle Timeout: Allow Aport-212 to disconnect the TCP section if there is no data traffic and timeout. ‧11‧... -
Page 16: Master Rtu Or Ascii Mode
Serial exception: Enable or disable serial exception. Idle Timeout: Allow Aport-212 to disconnect the TCP section if there is no data traffic and timeout. 5.7 TCP Server Mode When you use TCP server mode, you can select Listen port and Idle Timeout as followed. -
Page 17: Tcp Client Mode
Aport-212 User Guide 5.8 TCP Client Mode When you use TCP client mode, you can select Remote IP, Port, when to connect and Idle Timeout as followed. 5.9 UART Data Packing When choosing TCP server or TCP client mode, you can decide how to pack your serial data before sending them to TCP port. -
Page 18: Advanced Options
Aport-212 User Guide 5.10 Advanced Options Advanced options is used to select following settings. 5.11 Web Server Settings Enable: Enable and Disable Web server. Listen Port: Web server port number (default web server is 80, if you use port 6060, you can add port number at the end of the IP such as http: //192.168.2.127:6060. -
Page 19: Accessible Ip Settings
5.14 Accessible IP Settings You can limit the user IP to access Aport-212 by the Accessible IP settings. Aport-212 will check if the remote IP comes from the allowed IP address. If not, it will deny the connection. 0.0.0.0 stands for no restriction in access. -
Page 20: Alive Check Timeout
Aport-212 User Guide 5.15 Alive Check Timeout This setting allows user to configure the Alive Timeout settings for UART1 and UART2. 5.16 Quick Command Button Upgrade Firmware: Use this button to upgrade Aport-212 firmware if necessary. ‧16‧... -
Page 21: Web Console
Disconnect: This button can use to stop the serial UART operation, TCP console or Web Console. 5.17 Web Console Web console allows user to use web browser to configure Aport-212. To open the web console, enter the IP address and port number as http://192.168.2.127:5003. -
Page 22: Login With Password
Password: (your password) to start the web console 5.19 Command Line Interface Aport-212 supports Command Line Interface (CLI) configuration. Users can use CLI in Telnet console port and serial console to write their own manager utility software. Make sure the Command option is Enable in TCP Command Setting and Serial Console setting.
