Specifications

Maximum Axis
Maximum Coordinate Systems
Maximum Motion Programs
Maximum Auxiliary Programs
(minus the number of Motion Programs)
Maximum PLC Programs
Analog Inputs
Eight analog inputs, ±10V, 12 bit, single ended
or 4 differential mode
Encoder Inputs
Standard Inputs
Pre-defined Outputs
Standard Outputs
Pre-defined Inputs
Expanded I/O Banks (Optional)
(32 Inputs/32 Outputs)
Data Highway Plus® (Optional)
Modbus® (Optional)
Stepper Axis (Optional)
Power Requirements
DSP Speed
Communications
(1) 9-pin, D-sub, RS-232C serial port.
(1) RS-232C/422/485 terminal block
38.4k max baud rate
Memory
Noise Immunity
Environmental
Operating Temperature
Relative Humidity
Weight
* Although you can enter up to eight coordinate systems for the AXIMA 2000/4000 controllers, the
AXIMA 2000 will only use the first two coordinate systems and the AXIMA 4000 will only use the
first four coordinate systems.
Feature AXIMA 2000
2
8 *
8
15
8
Yes
Each Axis plus 2
16
7
12
Axis enable - (1) per axis, dry contact
(1) Watchdog timer, dry contact
2
Yes
Yes
2
96 to 264 VAC, 50/60 Hz single phase, 2 Amps max.
50 MHz
Yes
Yes
Yes
128K, 128k Flash
Designed to meet IEC801.2 standard
32° to 133° F (0 to 40° ambient)
0 to 90%, non-condensing
5 lbs
Specifications
AXIMA 4000
4
8 *
8
15
8
Yes
Each Axis
16
13
12
2
Yes
Yes
4
50 MHz
Yes
Yes
Yes
128K, 128k Flash
5 lbs
