AXIMA ID
3
4
5
6
7
8
9
A
B
C
D
E
Reserved
Note
The following procedure is needed if a corrupted program is run on power-up or in making
communications.
The reserved address setting is used for bypassing the flash memory and ignoring the run on
power-up command for programs in the Application. This is needed if the flash memory
becomes corrupted. Corrupted flash can lock-up communications and load the corrupted
program into RAM on power-up. This requires revision A7 or later firmware. The
instructions for using this function are as follows:
1.
Turn the AXIMA 2000/4000 controller power "Off".
2.
Set the DIP switches to the reserved positions. (All switches in the "On" position).
3.
Turn the AXIMA 2000/4000 controller power "On".
4.
Set the DIP switches back to the address being used.
5.
Download the AX-WIN Application.
Multi-Drop Installations
If your application uses more than one AXIMA 2000/4000 controller (up to 15 can be linked
serially), each must have a different ID number. This allows each AXIMA 2000/4000
controller to be addressed individually over the same multi-drop serial cable in the RS422 and
RS485 modes.
Address DIP Switch Settings
OFF
OFF
OFF
ON
OFF
ON
OFF
ON
OFF
ON
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
ON
ON
ON
ON
ON
ON
ON
Connections and Cabling
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
ON
OFF
OFF
OFF
ON
ON
OFF
ON
ON
29
