Water Basin Insert, With Fire Feature Option
Select Models
Certified to
ANSI Z21.97-2014
CSA 2.41-2014
CSA C22.2 No. 108-01-2010
If your system includes an HPC fire feature you must comply with the instructions
included for the fire feature.
Any system utilizing any fire affect is for outdoor use only and must comply with HPC
clearance and installation instructions for a fire feature. If you are unsure of what these
clearances and instructions are they are outlined in our fire pit instructions which are
available on our website or you can contact your dealer.
This product is not for use inside another body of water.
WARNING: FOR OUTDOOR USE ONLY
WARNING
• Improper installation, adjustment, alteration, service, or maintenance can cause injury or property
damage. Read the installation, operating, and maintenance instructions thoroughly before installing
or servicing this equipment.
7/20/2015
For Outdoor Use Only
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Instructions are also available at
www.HPCfire.com
980
Installation
We suggest that our fire products be
installed by professionals that are
locally licensed by the authority
having jurisdiction in gas piping.
Service
We suggest that our fire
products be serviced by a
professional certified in the
US by the National Fireplace
Institute (NFI) as NFI Gas
Specialists.
1
Advertisement
Table of Contents
Related Manuals for HPC Evolution 360
Summary of Contents for HPC Evolution 360
- Page 1 If your system includes an HPC fire feature you must comply with the instructions included for the fire feature. Any system utilizing any fire affect is for outdoor use only and must comply with HPC clearance and installation instructions for a fire feature. If you are unsure of what these clearances and instructions are they are outlined in our fire pit instructions which are available on our website or you can contact your dealer.
- Page 2 Index: 1) General Information Product Specific Information 2) Selecting the Location 6) Parts List 3) Construction Of The Enclosure 7) Water Basin Operation 4) Installation Of the Water Feature 8) Maintenance 5) Media 9) Troubleshooting 10) Replacement Parts 11) Warranty 12) Clearances, section 12, figure 1&2 13) Electronic ignition fire pit information General Information...
- Page 3 WARRANTY REQUIREMENT: Your location must have sufficient drainage to prevent damage to surrounding surfaces. HPC does not warranty against drips or leaks and is not responsible for any damage. It is the installer’s responsibility to ensure there is enough drainage to allow for maintenance, repair, winterization or leak of the water basin.
- Page 4 WARRANTY REQUIREMENT: Your location must have sufficient drainage to prevent damage to surrounding surfaces. HPC does not warranty against drips or leaks and is not responsible for any damage. It is the installer’s responsibility to ensure there is enough drainage to allow for maintenance, repair winterization or leak of the water basin.
- Page 5 Tower 1. Position the control panel and pump so they can be accessed in the future. 2. Prepare the site. a. Make sure the area is stable and level. b. Ensure adequate drainage to allow for periodic maintenance and winterization that will not result in damage to the surrounding area.
- Page 6 Control Box Wiring Schematic With Fire Feature Option Fuse / Breaker size and type may vary. Refer to product label or consult with HPC customer service. 7/20/2015...
- Page 7 Control Box with optional Fire Feature Bonding lug on valve box with Fire Feature option Bonding lug location for water only applications 7/20/2015...
- Page 8 Onsite Electrical Wiring Options 7/20/2015...
- Page 9 Turn pump on and confirm proper water flow. i. Use level legs for fine tuning water flow. d. HPC does not warranty against minor leaks. Your water feature has been assembled and thoroughly inspected prior to shipping. There are many connections and in some cases handmade water features.
-
Page 10: Operation
Leaves, sticks, wood, paper, clothing, food etc. should always be kept away from the water feature. Apply Start-Up / Shut Down Label near the controls for your feature. EVOLUTION 360 START UP 1. STOP! Read the safety information on “What to Do If Smell Gas” (Pg. 1 section 13 of Fire Pit Instructions When Applicable). -
Page 11: Troubleshooting
Below are some potential causes and countermeasures to the symptoms indicated in bold. If still unable to resolve issue, please contact your retailer or certified technician. WARNING: If your unit is equipped with an optional fire feature refer to HPC fire pit instructions included in section 13. Water will not turn on 1. Not Enough Water. -
Page 12: Replacement Parts
This commences from the date of original sale / shipment from HPC FOB Kettering, Ohio. This warranty is for parts and in-house (HPC) labor. The defective product must be sent back to HPC with a Return Merchandise Authorization (RMA) issued by HPC for that specific product and any other additional information for the nature of the defect or warranty claim. - Page 13 Clearances Figure 1 7/20/2015...
- Page 14 Figure 2 7/20/2015...
- Page 15 Electronic Fire Pit Option Electronic Ignition Fire Pit Insert Installation & Operation Instructions Installation We suggest that our products be Select Models installed by professionals that are Certified to locally licensed by the authority having jurisdiction in gas piping. ANSI Z21.97-2014 CSA 2.41-2014 Service We suggest that our products...
-
Page 16: General Information
Index: 14) General Information 15) Selecting the Location 16) Construction of Enclosure 17) Installation of Fire Pit 18) Media Product Specific Information 19) Parts List 20) Fire Pit Operation 21) Maintenance 22) Troubleshooting 23) Replacement Parts 24) Warranty General Information Instructions are also available at HPCfire.com Please carefully follow the instructions in this manual to prevent personal injury or property loss. -
Page 17: Selecting The Location
Gas pressure and type should be checked prior to use and installation. ● Natural Gas Fire Pit: Supply Pressure: Minimum: 3.5” W.C.; Maximum: 7.0” W.C. Outlet Pressure: 3.5” W.C. ● LP Gas: Supply Pressure: Minimum: 8.0” W.C.; Maximum: 11.0” W.C. Outlet Pressure: 10.0”... - Page 18 Installation We suggest that our products be installed by professionals that are Installation of a Fire Pit locally licensed by the authority having jurisdiction in gas piping. WARNING: We suggest that our products be installed by professionals that are locally licensed by the authority having jurisdiction in gas piping.
- Page 19 Lava Rock & Glass Application Please follow the instructions below to add the finishing touch to your fire pit. Particular attention needs to be on the pilot assembly area. Incorrect media installation will cause the pilot flame to suffocate and turn off pit or delay main burner ignition.
-
Page 20: Parts Lists
Parts Lists 1) Electronic Ignition Fire Pit 3) Cover 2) Lava Rock 4) Instructions Fire Pit Operation WARNING: Before use, be sure to test all gas connections for leaks. Do not use fire pit if there is any evidence of leaking gas. If leaking gas suspected, turn off the main gas supply and repair immediately. -
Page 21: Maintenance
Service Maintenance We suggest that our products be serviced by a professional certified in the US by the WARNING: Any guard or protective device removed for servicing must be replaced prior to National Fireplace Institute operating the fire pit. (NFI) as NFI Gas Specialists. WARNING: We suggest that our products be serviced annually by a professional certified in the US by the National Fireplace Institute (NFI) as NFI Gas Specialists. -
Page 22: Limited Warranty
4. Thermocouple Defective Change Thermocouple. Replacement Parts Please see list below for replacement parts as needed. Please contact your dealer for these parts- if unsure please contact HPC and we will be happy to help you. Common Components: Model #...
