HPC Electronic Ignition Flame Control System Safety Manual

Available in “hi/lo” and “on/off” models
Hide thumbs
Table of Contents

Advertisement

Quick Links

Select Models
Certified to
ANSI Z21.97-2014
CSA 2.41-2014
WARNING
•Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Read the installation, operating and maintenance instructions thoroughly before installing or
servicing this equipment.
WARNING
•Do not store or use gasoline or other flammable vapors and liquids in vicinity of this or any other
appliance.
•An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
DANGER
If you smell gas:
1) Shut off gas to appliance.
2) Extinguish any open flame.
3) If odor continues, keep away from appliance and immediately call gas supplier or fire
department.
8/17/2016
Electronic Ignition Flame Control
System Safety Manual
Available in "Hi/Lo" and "On/Off" Models
Installation & Operation Instructions
Commercial and Residential Use
WARNING: FOR OUTDOOR USE ONLY
Record and keep for your records: You may
remove the label from the package and tape here.
Model #:
Serial #:
BTU:
850-EI
Voltage:
Attention:
Hi/Lo Only
For the App, the default
security code is 2345
Installation
We suggest that our products be
installed by professionals that are
locally licensed by the authority having
jurisdiction in gas piping.
Service
We suggest that our products
be serviced by a professional
certified in the US by the
National Fireplace Institute
(NFI) as NFI Gas Specialists.
INSTALLER:
Leave this
manual with the appliance.
CONSUMER: Retain this
manual for future reference.
.
