Reflector Mode configuration (optional feature)
Highlight the packet type
select the packet type that the reflector will respond to:
- any packet
- destination MAC is this LinkRunner Pro and the data string
contains a special Fluke Networks byte string (generated by the Fluke
Networks instrument)
- the data string contains a special Fluke Networks byte string
- destination MAC is this LinkRunner Pro
- any non-broadcast packet
Highlight the swap icon
and then use the up or down arrow key to select
whether the source and destination addresses are swapped in the outgoing
packet:
- swaps the source/destination MAC and IP addresses
- swaps the source/destination MAC address only
Blank - no swap; packet is sent out as it was received
The factory default conditions for your LinkRunner Pro are:
Match – FLUKE and Swap - MAC and IP
You can also use the LinkRunner Connect PC application to configure the
Reflector.
Firmware update
Allows you to download the latest LinkRunner Pro firmware through the
LinkRunner Connect PC application. Firmware updates can be downloaded
from
www.flukenetworks.com/linkrunnerpro.
product page and follow the links for downloads and updates.
Press the right arrow to update. Use the LinkRunner Connect PC application to
download the update files.
Exits out of Configuration menu and back to the Home screen.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
and then use the up or down arrow key to
Navigate to the LinkRunner Pro
