SYNERGY 323
Twin Instructions
Includes:
(1) Twin 20 Unit
(2) S30 Side Panels
(2) S30 Doors

Limited Warranty

For five full years Salamander Designs Ltd. will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any damage to or destruction of other equipment conse-
quential to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the original carton and packing material. Any damage incurred in a shipment not in original packaging
shall be the responsibility of the owner. Warranty repairs will be returned prepaid, via UPS within the continental U.S.A. only.
©2002 Salamander Designs Ltd.

BEFORE YOU BEGIN:

!
!
• Unpack all parts before beginning and refer to the drawing below.
• Shelf pegs and door hinges must slide into the channels of the post in the correct order.
They cannot be removed individually without disassembling the whole unit.
Top Shelf (1)
Shelf Peg
PHK-370 Right (8)
PHK-380 Left (8)
Washer 300-470 (6)
Foot & Nut P-300-350 (6)
Joint Connector Bolt 300-540 (6)
Adjustable Shelf (4)
Door (2)
Bottom Shelf (1)
Salamander Designs Ltd. • 800-535-5659 • www.SalamanderDesigns.com
Sides (2)
Aluminum Post (6)
323 -1/4
Doc No. 500-750/v2.12
