J4076-01
SAS/SATA JBOD
User's Manual
UM_J4076-01_v6.1_082417

Advertisement

Table of Contents
loading

Related Manuals for AIC J4076-01

Summary of Contents for AIC J4076-01

  • Page 1 J4076-01 SAS/SATA JBOD User's Manual UM_J4076-01_v6.1_082417...

  • Page 2: Table Of Contents

    CONTENTS PREFACE �������������������������������������������������������������������������������������������������������� i SAFETY INSTRUCTIONS ��������������������������������������������������������������������������������� ii Chapter 1� Prodcut Introduction �������������������������������������������������������������1 1�1 Box Content ������������������������������������������������������������������������������������������������������ 1 1.2 Specifications ��������������������������������������������������������������������������������������������������� 2 1�3 General Information ����������������������������������������������������������������������������������������� 3 1.4 8644 with Zoning Configuration and 8644 port definition ����������������������������� 6 Chapter 2� Hardware Installation ����������������������������������������������������������11 2�1 Removing and Installing Top Cover �������������������������������������������������������������...
  • Page 3 4�9 Firmware safety mode ����������������������������������������������������������������������������������� 99 Chapter 5� Technical Support��������������������������������������������������������������104 contents...
  • Page 4 Copyright © 2016 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.

  • Page 5: Preface

    AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS • Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components.
  • Page 7 • product, voltage and current marked on the product’s electrical ratings label. The voltage and current rating of the cord should be greater than the voltage and current rating marked on the product. • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.

  • Page 8: Chapter 1� Prodcut Introduction

    • Enclosure (Power supply, fan, 76 HDD tray included) • RS232 cable x 1pcs • Power cord x 2pcs • Screws kit x 1set • Mounting Optional Slide Rail x 1set If any items are missing, please contact your authorized reseller or sales representative. J4076-01 User's Manual...

  • Page 9: Specifications

    : 23.74 x 43.11 x 16 Redundancy Platinum Standard Slide rail Power Entry Dual AC inlet Expander Modules Dual expanders (Optional) Option Cable management kit Mounting For North America, 20” tool-less rail is the standard. Adjustable plate is not included. J4076-01 User's Manual...

  • Page 10: 1�3 General Information

    Chapter 1 Product Introduction 1�3 General Information J4076-01 is a 4U rackmount chassis with 60 x 3.5” HDDs hot swap bay / 16 x 2.5'' HDDs hot swap bay and dual expander module JBOD, which is a high performance, high density, scalable storage product.
  • Page 11 Chapter 1 Product Introduction • Rear Expander Panel SFF 8644 wide port Console port Identify LED Debug port BMC LAN port BMC console port J4076-01 User's Manual...

  • Page 12: Rear Panel

    Chapter 1 Product Introduction • Rear Panel 16 x 2.5’’ rear drives 1400W 1+1 hot-swap redundant power suppl y SECONDARY PRIMARY 2 x 8038 hot-swap fans Mini SAS HD J4076-01 User's Manual...

  • Page 13: 8644 With Zoning Configuration And 8644 Port Definition

    Before you begin, your JBOD must be equipped with HUB/EDGE setting. Refer to 3.2 Connect Host to JBOD via RS232 Refer to 3.5.2 How to configure T10 zoning SMART PORT (CONSOLE PORT) SMART PORT(CONSOLE PORT) J4076-01 User's Manual...
  • Page 14 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4076-01 User's Manual...
  • Page 15 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 GROUP1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4076-01 User's Manual...
  • Page 16 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4076-01 User's Manual...
  • Page 17 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 J4076-01 User's Manual...

  • Page 18: Chapter 2� Hardware Installation

    Chapter 2 Hardware Installation Chapter 2� Hardware Installation This chapter provides detailed instructions on hardware installation. 2�1 Removing and Installing Top Cover Pushing release button on both side and slide forward the top cover to open cover. J4076-01 User's Manual...

  • Page 19: 2�2 Removing/Installing A Drive Tray/ Hard Drive/ Drive Slot Map

    Insert the drive carrier into its bay. Push the tray lever until it clicks. Make sure the drive tray is correctly secured in place when its front edge aligns with the bay edge. (follow the reverse order) J4076-01 User's Manual...
  • Page 20 • Directly place HDD into tool-less HDD tray until it snaps. Please check if the screw holes on HDD match the dimples on HDD tray. • HDD can also be screwed on HDD tray by fastening two screws as picture showed. J4076-01 User's Manual...
  • Page 21 Chapter 2 Hardware Installation 2.2.4 Drive Slot Map The drive slot map follows. Left Edge Center Edge Right Edge J4076-01 User's Manual...
  • Page 22 Chapter 2 Hardware Installation The drive slot map follows. MegaRaid / HBA Card 61 62 63 64 65 66 67 68 71 72 73 74 75 76 77 78 J4076-01 User's Manual...

  • Page 23: 2�3 Removing And Installing A Psu Module

    • Pushing the latch then hold the tray handle tab. Then pull the PSU module gently until it slides out of the JBOD. 2.3.2 Installing a PSU Module • Slide in PSU module. • Make sure the latch on the module is fully hooked onto the PSU housing. J4076-01 User's Manual...

  • Page 24: 2�4 Removing And Installing A Fan Module

    • Pull the fan module gently and firmly until it clears the enclosure chassis. 2.4.2 Installing a Fan Module • Align the fan module with the opening in the enclosure. • Insert the fan module into JBOD. J4076-01 User's Manual...

  • Page 25: 2�5 Removing And Installing External Expander Module

    • Align the expander module with the opening in front of the enclosure, and insert it into the enclosure firmly. • Close the lever and secure the retaining screw. Secondary Edge Expander Board Secondary Edge Expander Board Primary Edge Expander Board Primary Edge Expander Board J4076-01 User's Manual...

  • Page 26: 2�6 Removing And Installing The Hdd Backplane Module

    • Slide the HDD backplane module into JBOD and close the lever. • Cover JBOD with LED front board and screw both sides. warning : before you pull out the hdd backplane, must remove all the hdd trays and expander modules first. J4076-01 User's Manual...

  • Page 27: 2�7 Installing Slide Rail

    2.7.1 Installing slide rail To install the slide rail, please refer to the manual in the slide rail kit. Option 1: AP61-843 Slide Rail Screw Sack User’s Manual Option 2 : AP61-920 J4076-01 User's Manual Slide Rail Screw Sack User’s Manual...

  • Page 28: Chapter 3. Sub-System Configuration Setup

    : To have multiple host access support (the host number can be up to the number of wide ports on each AIC 12G Expander Controller), only the following drives are supported for shared access: 1. SAS drive / nearline sas drive 2.

  • Page 29: 3�2 Connect Host To Jbod Via Rs232

    Chapter 3 Sub-System configuration Setup 3�2 Connect Host to JBOD via RS232 Use a RS-232 DB9 cable to connect the console port of JBOD with host's PC COM port (see figures below for DB9 RS-232 cable and SAS expander COM port). J4076-01 User's Manual...

  • Page 30: 3�3 Utility Set Up On Host

    Step 1: Set up host RS232 connection Set up RS232 connection application into your host as shown in the example process below. For example: OS: Microsoft Windows Server 2008 RS232 connection application: Hyperterminal Step 2: Install HyperTrm.exe J4076-01 User's Manual...
  • Page 31 Step 3: Enter a new name for the icon in the field below and click Step 4: Connect by using selecting an option in the drop down menu circled in red below (we selected COM2 in this example) and click OK. J4076-01 User's Manual...
  • Page 32 None Stop bits: Flow control: None Restore Defaults Cancel Apply Step 6 : After steps 5, you will enter hyper terminal screen and then please press "Enter" key, the screen will appear the cmd line. cmd > J4076-01 User's Manual...

  • Page 33: 3�4 Updating Firmware And Mfg Through Console Port

    Chapter 3 Sub-System configuration Setup 3�4 Updating Firmware and MFG through Console Port Step1：Please input “fdl 0 0” in command line to update the firmware. cmd >fdl 0 0_ Step2：Select the tool bar ''Transfer'' -> ''Send File'' within 10 seconds. J4076-01 User's Manual...
  • Page 34 Chapter 3 Sub-System configuration Setup Step3：Select the Firmware file and set the Protocol type is “Xmodem” and then press the “Send” button. 4U76swap Step4：After finished the FW updated, the screen will show “ Buffer Download Complete”. J4076-01 User's Manual...
  • Page 35 Step6：Go to the Transfer menu, and then select “Send file” within 10 seconds. Step7：Select the MFG file and set the Protocol type is “Xmodem” and then press the “Send” button. Step8：After finished the MFG updated, the screen will show “ Buffer Download Complete”. J4076-01 User's Manual...

  • Page 36: Configure Command Line Interface Operation

    Succeeded to enable zoning cmd >_ cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >phyzone off Succeeded to dissable zoning cmd >_ J4076-01 User's Manual...
  • Page 37 Step 5: Assign the drive on PHY21 of EDGE to be accessed only by the second port of HUB instead of the first port cmd> phyzone 21 9 Step 6: Rest HUB and EDGE for taking effect with the new settings. cmd> reset J4076-01 User's Manual...
  • Page 38 Succeeded to set zone group for the phy cmd >phyzone 21 9 Succeeded to set zone group for the phy cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >reset J4076-01 User's Manual...
  • Page 39 Chapter 3 Sub-System configuration Setup 3.5.3 How to get all revisions in AIC SAS 12G Expander (A) Expander firmware revision cmd> rev (B) Expander configuration revision cmd> showmfg (C) MCU firmware revision or sensor information (MCU firmware revision is reported by Hub only) cmd>...
  • Page 40 Temperature in Celsius(t1=20 C, t2=55 C, Warning=50 C, alarm=55 C) cmd > cmd > cmd > cmd >_ cmd > cmd > cmd > cmd > cmd > cmd >temperature 18 52 48 54 Succeeded to update temperature cmd >reset_ J4076-01 User's Manual...
  • Page 41 >enclosure_addr Enclosure Address: 0x50015B21682C7F3F cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >enclosure_addr 500605B0000272BF Succeeded to set Enclosure address cmd >reset_ J4076-01 User's Manual...
  • Page 42 > cmd > cmd > cmd > cmd > cmd > cmd >standby_timer 10 Succeeded to set standby timer cmd >reset_ WARNING : This function is not recommended to use with RAID card since RAID card limitation. J4076-01 User's Manual...
  • Page 43 This feature is applicable for SAS drives instead of SATA drives. If there is no connection with any active SAS initiator by checking all wide ports, AIC Expander Controller stops all attached SAS drives to save power consumption of SAS drives. Otherwise, AIC Expander Controller starts all attached SAS drives to provide drive access service to any active SAS initiator.
  • Page 44 >check_wide_port on Succeeded to configure checking wide port cmd >reset_ cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >check_wide_port off Succeeded to configure checking wide port cmd >reset_ J4076-01 User's Manual...
  • Page 45 (C) Set both of Expander serial number (421-12021704510010) and Enclosure serial number (526-12071100500088). cmd> serial_number 421-12021704510010 526-12071100500088 cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >serial_number 421-12021704510010 526-12071100500088_ J4076-01 User's Manual...
  • Page 46 3.5.9 How to power off/on all disk drives automatically This feature is applicable for SAS/SATA drives. If there is no connection with any active SAS initiator by checking all wide ports, AIC Expander Controller powers off all attached SAS/SATA drives to save power consumption.
  • Page 47 >edfb on Succeeded to set EDFB cmd>_ (C)Disable the edfb cmd> edfb off cmd > cmd > cmd > cmd >edfb EDFB is OFF cmd >edfb on Succeeded to set EDFB cmd>edfb off EDFB is OFF cmd>_ J4076-01 User's Manual...
  • Page 48 "keep off", "keep on", and "keep last state". The default setting is "keep off". (A) Get the current power setting cmd> power_setting Power setting: keep off (B) Set "keep off" cmd> power_setting keep_off (C) Set "keep on" cmd> power_setting keep_on (D) Set "keep last state" cmd> power_setting keep_last_state J4076-01 User's Manual...
  • Page 49 > cmd > cmd > cmd > cmd >power_setting keep_on cmd > cmd > cmd >_ cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >power_setting keep_last_state cmd >_ J4076-01 User's Manual...
  • Page 50 > cmd > cmd > cmd >zonecount Zone Count 1 cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd > cmd >zonecount 2 Succeeded to set zone count 2 cmd>_ J4076-01 User's Manual...
  • Page 51 (C-4) When Zone Count = 4, T10 zoning is enabled. No disk could be seen if we connect HBA/RAID card with port 5 and 6 of HUB. HUB: Zone # Others Wideport EDGE: Zone # 31~45, 46~60, Slot 1~15 16~30 61~68 71~78 J4076-01 User's Manual...

  • Page 52: 3�6 Ses Inband Features

    Chapter 3 Sub-System configuration Setup 3�6 SES Inband Features To ensure J4076-01 can work properly and provide high performance, durability. J4076-01 has implemented SCSI Enclosure Services to monitor the status of power supply, system cooling fan and working temperature. It also has the indicators to deliver the status of fail devices such as power supply or cooling fan.
  • Page 53 Threshold control element format BYTE/BIT REQUESTED HIGH CRITICAL THRESHOLD REQUESTED HIGH WARNING THRESHOLD REQUESTED LOW WARNING THRESHOLD REQUESTED LOW CRITICAL THRESHOLD Threshold control element format BYTE/BIT HIGH CRITICAL THRESHOLD HIGH WARNING THRESHOLD LOW WARNING THRESHOLD LOW CRITICAL THRESHOLD J4076-01 User's Manual...
  • Page 54 BYTE/BIT Chassis Number If no chassis number is found, return Status = 1 (failed) only, else return Status=0 (success) followed by chassis number. Chassis Number status format BYTE/BIT Status (0: success, 1: failed) Chassis Number (if success) J4076-01 User's Manual...
  • Page 55 BYTE/BIT Canister Number If no canister number is found, return Status = 1 (failed) only, else return Status=0 (success) followed by canister number. Canister Number status format BYTE/BIT Status (0: success, 1: failed) Canister Number (if success) J4076-01 User's Manual...
  • Page 56 A failure condition is detected RQSTED ON 1: On 0: Off for Disk Power Supply 1: Off for Disk Power Supply 0: On AC FAIL A failure condition is detected DC FAIL A failure condition is detected J4076-01 User's Manual...
  • Page 57 0: Enable the smart fan function IDENT 1: Disable the smart fan function ACTUAL FAN Current fan RPM SPEED The fan RPM can’t be detected or equal to 0. FAIL ACTUAL Speed code level bases on current fan RPM. SPEED CODE J4076-01 User's Manual...
  • Page 58 Temperature has exceeded the failure high threshold value OT WARNING Temperature has exceeded the warning high threshold value UT FAILURE Temperature is below the failure low threshold value UT WARNING Temperature is below the warning low threshold value J4076-01 User's Manual...
  • Page 59 0: Identify LED of Hub is OFF IDENT 1: Identify LED of Hub is solid ON FAILURE Set by the REQUEST FAILURE on Enclosure Control Element REQUESTED WARNING Set by the REQUEST WARNING on Enclosure Control Element REQUESTED J4076-01 User's Manual...
  • Page 60 OVER UNDER VOLTAGE Field Value OK: Everything is Ok ELEMENT STATUS NON-CRITICAL: If either warning limit is exceeded CODE CRITICAL: If either failure limit is exceeded FAIL A warning or failure condition is detected VOLTAGE Voltage reading J4076-01 User's Manual...
  • Page 61 RQST REMOVE Please refer to section “SES Element Control Functions” for details. RQST IDENT Please refer to section “SES Element Control Functions” for details. RQST FAULT Please refer to section “SES Element Control Functions” for details. DEVICE OFF Please refer to section “SES Element Control Functions” for details. J4076-01 User's Manual...
  • Page 62 Set by the RQST REMOVE on Array Device Control Element IDENT Set by the RQST IDENT on Array Device Control Element FAULT REQSTD Set by the RQST FAULT on Array Device Control Element DEVICE OFF Set by the DEVICE OFF on Array Device Control Element J4076-01 User's Manual...
  • Page 63 RQST R/R ABORT Activity Slow Blink RQST ACTIVE Activity DO NOT REMOVE Activity RQST MISSING RQST INSERT Activity Slow Blink RQST REMOVE Activity Slow Blink RQST IDENT Slow Blink RQST FAULT DEVICE OFF PRDFAIL Activity Slow Blink J4076-01 User's Manual...
  • Page 64 We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U76swap: Edge-L 0c08 (B) Get the current state of a slot power.
  • Page 65 We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U76swap: Hub...
  • Page 66 "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U76swap: Hub...
  • Page 67 "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U76swap: Hub...
  • Page 68 0 supports this feature. We use the software package "sg3_utils" on Linux for example, and have a SAS HBA and a cable to connect your host with the expander. (A) Show the device for AIC Expander Controller (canister) $ sg_map -i /dev/sg2 AIC 12G 4U76swap: Hub 0c07 (B) Set "RQST IDENT"...
  • Page 69 Chapter 3 Sub-System configuration Setup REQUESTED SPEED CODE 100% Leave at current speed J4076-01 User's Manual...

  • Page 70: Chapter 4. Bmc Configuration And Settings

    Open a web browser, enter default IP http://192.168.11.11 and press Enter. When the login window appears, set the user name and password to ''admin''. Click Log In to continue. Type the default account and password Account:admin Password:admin J4076-01 User's Manual...

  • Page 71: 4�2 Sensor's Location For Fan & Temperature

    Chapter 4 BMC Configuration and Setting 4�2 Sensor’s location for Fan & Temperature EXP: expander chip J4076-01 User's Manual...

  • Page 72: 4�3 Utility Setup On Host

    Type command for login the interface. #[sys pwd –u admin admin ] It will response [OK] Type command for check BMC default IP. #[30 0 2 1 3 0 0] It will response [34 00 02 00 11 C0 AB 0B 0B] J4076-01 User's Manual...
  • Page 73 Get LAN static IP /DHCP: 01 is static IP, 02 is DHCP� The red box is hexadecimal, according to the left picture, the IP is 16*12 + 0 = 192, 16*10 + 8 = 168, 16*5 + 8 = 88, 16*6 + 11 = 107, It is 192�168�88�107 J4076-01 User's Manual...
  • Page 74 The blue text can change the value what you want, if you want to change the IP address, must set the LAN status to static. When you use BMC firmware 4U76 JBC040040 or later version, here is a default IP 192.168.11.11 can be used. J4076-01 User's Manual...

  • Page 75: Bmc Led Signal

    Chapter 4 BMC Configuration and Setting 4.5 BMC LED signal There are have two LEDs under the BMC console. Blue LED Light- Identify LED. Red LED Light- When the light keep blinking, means BMC got error.     J4076-01 User's Manual...

  • Page 76: 4�6 Web Ui

    A graphical representation of all events incurred by the various sensors and % occupied/available space in logs. If you click on the color- coded rectangle in the Legend for the chart, you can view a list of those specific events only. J4076-01 User's Manual...
  • Page 77 • Product Part Number • Language • Product Version • Manufacture Date Time • Product Serial Number • Board Manufacturer • Asset Tag • Board Product Name • FRU File ID • Board Serial Number • Product Extra J4076-01 User's Manual...
  • Page 78 Icon status Green: This slot inserted HDD and power on. Blue: This slot inserted HDD and power off. Red: This slot inserted HDD and got error. Gray: This slot not inserted HDD. Orange: This slot is rebuilding. J4076-01 User's Manual...
  • Page 79 Turn On or Off the live widget for this sensor. This widget gives a dynamic representation of the readings for the sensor. View this Event Log Click this button to go the event log page for the viewed sensor. J4076-01 User's Manual...
  • Page 80 Event Log. Clear All Event Logs Clear All Event Logs option will delete all existing records for all sensors. Save All Event Logs Save All Event Logs option will save all existing records for all sensors. J4076-01 User's Manual...
  • Page 81 LAN channels. Domain Name It displays the domain name of the device if Auto is selected. If the Domain setting is chosen as Manual, then specify the domain name of the device. Domain Name Server Configuration J4076-01 User's Manual...
  • Page 82 • IPv4 Address format. • IPv6 Address format. Save Click ‘Save’ to save any changes made. You will be logged out of current UI session and will need to log back in. Reset Reset the modified changes. J4076-01 User's Manual...
  • Page 83 • An IP Address consists of 4 sets of numbers separated by dots as in “xxx.xxx.xxx.xxx”. • Each set ranges from 0 to 255. • The first Number must not be 0. IPv6 Configuration It lists the IPv6 configuration settings. J4076-01 User's Manual...
  • Page 84 Save Click ‘Save’ to save any changes made. You will be prompted to log out of the current UI session and log back in at the new IP address. Reset Click ‘Reset’ to reset the modified changes. J4076-01 User's Manual...
  • Page 85 Link speed will list all the supported capabilities of the network interface. It can be 10/100/1000 Mbps. Duplex Mode Select any one of the following Duplex Modes. - Half Duplex - Full Duplex Save Click 'Save' to save the settings. Reset Click 'Reset' to reset the modified changes. J4076-01 User's Manual...
  • Page 86 Specify the NTP Server for the device. Check the ‘Automatically synchronize’ option to configure the NTP Server. The NTP Server will support the following: • IP Address (Both IPv4 and IPv6 format). • FQDN (Fully qualified domain name) format. J4076-01 User's Manual...
  • Page 87 Check this option to automatically synchronize Date and Time with the NTP Server. Refresh Click ‘Refresh’ to reload the current date & time settings. Save Click ‘Save’ to save any changes made. Reset Click ‘Reset’ to reset the modified changes. J4076-01 User's Manual...
  • Page 88 You can modify or add new LAN destination entries here. A maximum of 15 slots are available Send Test Alert Select a configured slot in the LAN Destination tab and click ‘Send Test Alert’ to send a sample alert to the configured destination. J4076-01 User's Manual...
  • Page 89 Alternatively, double click on a free slot. Modify Select a configured slot and click ‘Modify’ to modify that entry. Alternatively, double click on the configured slot. Delete Select the desired configured slot to be deleted and click ‘Delete’. J4076-01 User's Manual...
  • Page 90 • An IP Address is made of 4 numbers separated by dots as in “xxx.xxx.xxx.xxx”. • Each Number ranges from 0 to 255. • The first Number must not be 0. The server address will support the following: • IPv4 Address format. • IPv6 Address format. J4076-01 User's Manual...
  • Page 91 It lists the Secondary SMTP Server configuration. It is an optional field. If the Primary SMTP server is not working, then it tries the Secondary SMTP Server configuration. Save Click ‘Save’ to save the new SMTP server configuration. Reset Click ‘Reset’ to reset the modified changes. J4076-01 User's Manual...
  • Page 92 This page displays the device's current date & time. It can be used to configure dates within a week or specific a date to power on/off the device. If you want to change the device date & time, please go to the NTP page� J4076-01 User's Manual...
  • Page 93 Check a action to do power on/off for the device. Set days for action Setting dates within a week to do power on/off for the device. Date Specify a date for the device. Time Specify a time for the device. J4076-01 User's Manual...
  • Page 94 Alternatively, double click on a free slot to add a user. Modify User Select a configured slot and click ‘Modify User’ to modify that user. Alternatively, double click on the configured slot. Delete User Select the desired user to be deleted and click ‘Delete User’ J4076-01 User's Manual...
  • Page 95 Power On Storage Select this option to power on the storage. Power Cycle Storage Select this option to first power off, and then reboot the system (cold boot). Perform Action Click ‘Perform Action’ to perform the selected option. J4076-01 User's Manual...
  • Page 96 Choose an expander that can use smart console in Java SOL. note : A compatible JRE must be installed in the system prior to the launch of the JNLP file. Volatile-Bit-Rate Please set 38.4K Non-Volatile-Bit-Rate Please set 38.4K This function can connect to expander command line mode. J4076-01 User's Manual...

  • Page 97: 4�7 Firmware Update

    4.7.2 Web update 1. Check the BMC IP is valid. 2. Open a browser, type in the BMC IP, it will show the BMC web UI, type the default account, or have administrator privileges account. Username: admin Password: admin J4076-01 User's Manual...
  • Page 98 Chapter 4 BMC Configuration and Setting 3. This is login main page. 4. Click the “Firmware Update”, it will pop a drop-down menu, click the “Firmware Update” J4076-01 User's Manual...
  • Page 99 5. This page will show the update warning, if you really want to update BMC firmware, click the “Enter Update Mode” button. 6. Wait few minutes, it will pop a window, click the “Select file” to upload firmware file that you want update. J4076-01 User's Manual...
  • Page 100 Chapter 4 BMC Configuration and Setting 7. Wait a minutes, it will pop a window for check update section, just check the “Check this option to do all full firmware flash” option. 8. Click “OK” the firmware will started update operation. J4076-01 User's Manual...
  • Page 101 9. In the update processes, it will take 3~5 minutes. Caution: Please do not close this webpage!! Or it will let the firmware death 10. When show the “Device has been reset” window, it means firmware update successful, wait 90 seconds for BMC restarted. J4076-01 User's Manual...

  • Page 102: Expander Firmware Update

    Chapter 4 BMC Configuration and Setting 4.8 Expander firmware update 1. Click the “Firmware Update”, it will pop a drop-down menu, click the “Expand Update” 2. Chose the expander firmware file that want to update. J4076-01 User's Manual...
  • Page 103 Chapter 4 BMC Configuration and Setting 3. Chose the expander firmware file then click the “upload” button. 4. Click the ''Proceed'' button. J4076-01 User's Manual...
  • Page 104 Chapter 4 BMC Configuration and Setting 5. Processing 6. Update successful J4076-01 User's Manual...
  • Page 105 Chapter 4 BMC Configuration and Setting 7. If the update processes not success, please check the expander firmware is currently version or the system is already power off. J4076-01 User's Manual...
  • Page 106 1. If you saw the sensor name, status LED and ID LED are abnormal, the LEDs are cross blinking, it means firmware is in safety mode, in safety mode some function will be useless! J4076-01 User's Manual...
  • Page 107 Chapter 4 BMC Configuration and Setting     J4076-01 User's Manual...
  • Page 108 Chapter 4 BMC Configuration and Setting 2. Please clear browser cookies, and re-start browser, BMC web UI will refresh web page object. J4076-01 User's Manual...
  • Page 109 Chapter 4 BMC Configuration and Setting 3. Click the “BMC Reset” button, into the reset page 4. Select the “BMC reset”, and Click the “Perform Action” button. J4076-01 User's Manual...
  • Page 110 5. The page will show “Requesting” status, because reset BMC, this web page will be invalid, wait 90 seconds and clear browser cookies, re-login web UI again. 6. If still see the safety mode page, please follow section 4.5 web update to do firmware update. J4076-01 User's Manual...
  • Page 111 Chapter 1 Product Introduction Chapter 1 Product Introduction Chapter 5� Technical Support www�aicipc�com • TAIWAN Tel: +886 3 433 9188 Fax: +886 3 287 1818 Email : sales@aicipc�com�tw • CHINA Tel: +86�21�54961421, +86�21�54961422 Fax: Extension: 608 Email Technical Support: support@aicipc�com •...
